Title: University of Minnesota Poultry Research DDGS


1
University of MinnesotaPoultry Research - DDGS
  • Sally Noll
  • Animal Science Department

2
What is DDGS?
  • Co-product of the dry-milling ethanol industry
  • Corn (maize) DDGS - Midwestern US
  • Official definition
  • 75 of resultant solids condensed dried
  • Wheat DDGS - Canada
  • Sorghum (milo) DDGS - Great Plains US
  • Barley DDGS - Spain

3
(No Transcript)
4
Considerations in Feeding DDGS to Poultry
  • Product quality and variability
  • Amino acid digestibility
  • Feeding recommendations for broilers, layers and
    market turkeys
  • Diet levels
  • Amino acid balance
  • Metabolizable energy content
  • Source of xanthophylls
  • Phosphorus availability or digestibility

5
Nutrient CompositionNew Generation DDGS
  • Sally Noll, Turgay Ergul, and Chikako Abe
  • University of Minnesota
  • Bonnie Walters
  • University of Wisconsin, River Falls
  • Carl Parsons and C. Martinez-Amezcua
  • University of Illinois

6
Nutrient Characteristics
  • Survey and Collection of Samples
  • Chemical analyses
  • Amino Acid Digestibility
  • Relationships to dAA
  • Color
  • IDEA (Novus) values

Noll and Parsons, 2003
7
Sample Collection
  • 7 Ethanol Plants
  • 4 samples/plant taken periodically during Spring
    02 and in 2003
  • Feed mills (6) collected samples from incoming
    lots (28 samples total)
  • ID by feed mill, plant source, date of sample

8
Sample Analyses
  • Chemical analyses
  • Amino acids
  • Proximates
  • Minerals
  • Sugar and Starch
  • Amino acid digestibility (IL, chickens)

9
(No Transcript)
10
(No Transcript)
11
Total Lysine Content as Affected by Production
Source
CV 4.6 3.3 5.6 3.8
5.6 13.8 3.4
12
Other Quality Measurements
  • Color (Minolta Chromameter, B. Walters UW-River
    Falls, T. Ergul, UM)
  • L (lightness)
  • b (yellowness)
  • IDEA (C. Schasteen, Novus)

13
Measuring Color
  • The La b color space (CIELAB) is one of the
    most popular color space for measuring color of
    various objects-assigning a numerical value
  • The letter represents a color solid, where L
    lightness or darkness, a redness, -a
    greenness, b yellowness and b blueness
  • Hunterlab L a b readings

14
Color and SBM quality
  • Color changes in ingredients when heated have
    been observed (browning reaction)
  • McNaughton et al. (1981) indicated that color
    (Hunterlab) is a quick and reliable method of
    determining soybean meal quality.
  • Additional heating of soybean meal resulted in
    higher a color scores and poorer broiler
    performance.

15
Color and Nutritional Value of DDGS
  • Cromwell et al. (1993)
  • Beverage and fuel derived DDGS
  • Lys ranged from .43 to .89
  • Samples scored for color and with Hunterlab
    readings
  • DDGS were fed in a chick performance assay

16
Color Score and Chick Wt Gain
Cromwell et al., 1993
17

OBJECTIVES
  • To determine amino acid digestibility of corn
    derived dried distillers grains with solubles
    (CDDGS)
  • To determine if any correlation exists between
    the color and amino acid digestibility

18
Color Measurement
  • Minolta Chroma Meter CR-300
  • CDDGs placed in Petri dish
  • Color (L, a, and b values) readings taken at
    five locations on the horizontal surface
  • Color readings averaged across location
  • Experimental Design and Statistical Analysis
  • One way Analysis of Variance (ANOVA) for source
    differences Least Significant Difference (LSD)
    (P
  • Regression analyses and correlation coefficients

19
(No Transcript)
20
(No Transcript)
21
From Ergul et al., 2003
22
(No Transcript)
23
IDEA testing by C. Schasteen, Novus Digestible
lysine by C. Parsons, IL
24
In Summary
  • Characteristics of corn DDGs were similar to NRC
    (94) with the following exceptions
  • higher fat and lower fiber
  • higher contents of thr, arg, try
  • higher phosphorus availability
  • Several sources high lys digestibility
  • Color (lightness (L) and yellowness (b)) were
    correlated with lys digestibility
  • Dig. ys correlated with IDEA value

25
Survey - Production Source Characteristics
  • Consistent nutrient profile by source
  • Na exception
  • Higher protein and fat contents
  • High amino acid digestibility
  • DDGs with high lys content tended to have high
    amino acid digestibility
  • Quality reflected by color or IDEA value

26
(No Transcript)
27
DDGS and Market Turkey Performance
  • Sally Noll and Jeanine Brannon
  • University of Minnesota

28
DDGs in Market Turkey Diets
  • Early research prior to 1970s turkey poults to
    8 wks
  • Levels of 10 similar or improved growth
  • Levels of 20 increased feed/gain

29
Current Market Turkey Research
  • Roberson, 2003
  • Hen turkeys grow/finish diets
  • Isocaloric digestible amino acids
  • Noll ongoing 4 experiments
  • Tom turkeys grow/finish diets (5-19 wks)
  • Formulation - isocaloric digestible amino acids

30
DDGs and Turkey Hen Diets
Significant Linear Component
From Roberson, 2003
31
Market Tom Trials-Grow/Finish Diets(University
of Minnesota)
Trial weeks of age 15-19 wks 28-19 wks
311-19 wks
32
Market Tom Trials-Level of InclusionUM Trial 4
Noll et al., 2004
33
Amino acid balance
  • Lysine 1st limiting
  • Supplementation with lysine
  • Tryptophan and arginine
  • Tryptophan supplementation (expensive)
  • No commercial arginine supplement

Parsons et al., 1983
34
Study 1. Limiting nature of tryptophan and
arginine in DDGs for turkey toms
  • Corn soy- meat diet
  • Ingredient digestibility
  • Formulated to digestible val (reduced CP)
  • Isocaloric
  • Supplementation with lys, met, thr
  • Test diet with DDGs and canola meal
  • Calculated deficiencies of try, iso, arg

Noll et al., 2001
35
Study 1 contd
  • Treatments
  • 1. Control - corn, SBM, MBM
  • 2. As 1 plus DDGS
  • 3. As 1 plus canola
  • 4. As 1 plus DDGS and canola
  • 5. As 4 plus tryp to Trt 1
  • 6. As 4 plus tryp, iso to Trt 1
  • 7. As 4 plus tryp, iso, arg to Trt 1

36
Study 1. Alternative Ingredients and Amino Acids

Noll et al 2001
37
Limiting nature of tryptophan and arginine in
DDGs for turkey toms
  • Study 2 Lowered protein diet with DDGs
    resulted in poorer feed conversion restored
    with try arg

Noll et al, 2003
38
DDGs in Market Turkey Diets
  • Tryptophan and arginine may become limiting as
    diet protein levels are reduced
  • Inclusion level of 10-20
  • Hens 10
  • Toms 15

39
Metabolizable Energy
  • Importance of energy level
  • Feed conversion
  • Least cost formulation for high energy diets
  • AMEn 2480 kcal/kg, 9 fat (NRC, 1994)
  • Current DDGs
  • 10-11 fat
  • 2570 to 2650 kcal/kg
  • Potter (1966) 2880 kcal/kg (AMEn)

40
Metabolizable Energy Value
  • UM Research trials
  • AMEn 2810 to 2850 kcal/kg
  • Roberson (2004)
  • AMEn Layers 2770 kcal/kg
  • AMEn Turkey poults 2750 kcal/kg
  • Batal and Dale (2004) Chicken TMEn
  • Range 2380 to 3079 kcal/kg
  • Ave. 2831 kcal/kg

41
DDGs Source and TMEn(Turkeys)
  • Sources (5)
  • Samples per source (4)
  • Source Mean
  • 2833 kcal/kg
  • Individual Sample Range
  • 2651 to 3186 kcal/kg


Noll et al., 2004
42
Metabolizable Energy Value
  • Noll 2004 Turkey TMEn (20 samples)
  • Range 2651 to 3186 kcal/kg
  • Mean 2833 kcal/kg
  • Roberson 2004
  • AMEn 2756 kcal/kg
  • Batal and Dale 2004 Chicken TMEn
  • Range 2380 to 3079 kcal/kg
  • Ave. 2831 kcal/kg

43
DDGs and Energy Level
44
Recommendations for Use of DDGs
  • Corn DDGs (to 15) can be fed to chicken layers
    and broilers Turkeys - to 20 of diet (cool
    season growing)
  • Formulate with minimums for tryptophan and
    arginine, especially as diet protein is decreased
  • Formulate on basis of digestible amino acid
    content
  • Consider AMEn value of 2750 to 2850 kcal/kg
  • Increase available phosphorus (higher than NRC
    94) 65

45
HYDROLYZED DISTILLERS GRAIN STUDY
  • Chikako Abe¹, S.L. Noll¹, N. Nagle²,
  • C. Parsons³, and J. Brannon¹
  • ¹University of Minnesota
  • ² National Bioenergy Center
  • ³ University of Illinois

46
Hydrolyzed Distillers Grain (HDG)
  • National Renewable Energy Laboratory (NREL)
  • Seeking ways to increase the protein content and
    quality of DG to stabilize prices and increase
    the market share
  • New technology with the fiber and starch
    conversion process
  • HDGs protein content (57) is twice as much as
    DDG of NRC (1994)

47
Production of HDG
Ethanol Plant
Ethanol
Ethanol
Cellulose Hemicelluloses
C6 Sugars
Pretreatment
DDG
Fermentation
Sulfur Dioxide
Steam
Centrifuge
HDG
National Renewable Energy Laboratory
48
OBJECTIVES
  • To determine the potential feeding value of HDG
    through chemical analysis and in vivo tests for
    DAA and TME
  • To evaluate feeding value of the HDG by inclusion
    into turkey poults starter diets

49
METHODS
  • Nutrient Analysis
  • Chemical Characterization
  • True Amino Acid Digestibility Assay
  • True Metabolizable Energy Assay
  • Feeding Study
  • Diet Formulation
  • Management of Turkeys
  • Observations
  • Opportunity Cost Calculation

50
I. Nutrient Analysis
  • 1. Chemical Characterization
  • 2. Amino Acid Digestibility
  • (Parsons, U of IL)
  • AA digestibility method (Shirley and Parsons,
    2001)
  • 3. True Metabolizable Energy (TME)
  • TME bioassay using growing turkeys (Sibbald,
    1982)

51
II. Feeding Trial
  • 1. Diet
  • TRT 1- Control diet. A corn-soybean meal based
    diet with meat and bone meal
  • TRT 2- Control HDG5
  • TRT 3- Control HDG10
  • TRT 4- Control HDG15
  • TRT 5- Control HDG20
  • HDG replaced some corn
  • and soybean meal

5
10
15
20
52
RESULTS Comparison of corn and corn co-product
(NRC vs. HDG)
As is basis
53
Comparison of amino acid composition as of
protein (NRC vs. HDG)
As is basis
54
Comparison of amino acid digestibility
coefficients (NRC vs. HDG)
As is basis
55
Level of HDG and Poult Average Daily Gain
a
ab
bc
bc
c
  • a-C means with no common superscript differ
    significantly (P

56
Level of HDG and Relative Organ Weight
a
a
b
ab
b
a
ab
ab
bc
c
  • a-c means with no common superscript differ
    significantly (P

57
HDG Opportunity Cost Calculation (Scenario
1,without thr supplement)
58
CONCLUSIONS
  • HDG nutrient value (compared to DDG)
  • Higher protein concentration As a protein
    source
  • Lys, Trp, and Arg appear more limiting
  • Effect of heat, steam, acid?-Dark color,smoky
    smell
  • Lower P Could be positive contribution to
    manure management

59
CONCLUSIONS
  • Up to 10 of HDG can be included in poult
    starter diet, although higher level might be
    possible after 2 weeks of age
  • Good source of threonine compared to corn and SBM
    when HDG priced cheaper than 5.84/CWT

60
University of MinnesotaDDGS Webpage
  • www.ddgs.umn.edu

61
AcknowledgmentsUM Turkey Research Program
  • University of Minnesota staff-Jeanine Brannon,
    Fred Hrbek, Sheila Groth
  • MTGA Nutrition Subcommittee- Virgil Stangeland,
    George Speers, Jim Halvorson, Gary Johnson, Dick
    Nelson, Greg Engelke
  • University of Illinois Carl Parsons
  • Funding Minnesota Turkey Research Promotion
    Council, ADM, Heartland Lysine, Minnesota Corn
    Growers, Midwest Ethanol Cooperative DakotaGold

62
Acknowledgements Dr. Sally Noll Dr. Jerry
Shurson Dr. Chuck Clanton Dr. Jacquie
Jacob Jeanine Brannon Office mates Student
workers My friends and family
63
(No Transcript)
64
DDGs in Chicken Broiler Diets
  • Adjustment for lysine and energy level
  • Inclusion level of 15-25 possible
  • Starter diets 6
  • Grower/Finisher 10

65
Physical Characteristics of New Generation DDGS
  • Bulk density (16 new generation plants)
  • 35.7 2.79 lbs/ft3
  • Range 30.8 to 39.3 lbs/ft3
  • Particle size (16 new generation plants)
  • 1282 305 microns
  • Range 612 to 2125 microns

66
Samples of New Generation DDGS from Various
Ethanol Plants
VeraSun - Aurora, SD CVEC - Benson, MN
Al-Corn - Claremont, MN MGP Lakota, IA
CMEC - Little Falls, MN Agri-Energy -
Luverne, MN LSCP - Marcus, IA
DENCO Morris, MN
67
Ingredient Amino Acids ( of Protein)
NRC, 1994
68
Mycotoxins
  • Risk of mycotoxin contamination in new
    generation DDGS is very low
  • Poor quality corn poor ethanol yields
  • Corn supplied to ethanol plants is produced
    locally
  • Corn produced in upper Midwest is has a low risk
    for mycotoxins
  • Must use thin layer chromatography (TLC) or HPLC
    for testing mycotoxins in DDGS
  • ELISA and other methods result in false positives

69
Fat Stability of DDGS(Shurson, 2003)
  • Limited data
  • Mexico
  • DDGS monitored during transit and storage for 16
    weeks in a commercial feed mill in Jalisco,
    Mexico
  • Temperature ranged from 2 to 28 degrees C
  • Average high temperature 25 degrees C
  • Average low temperature was 8.4 degrees C
  • No rancidity was detectable

70
Fat Stability of DDGS in Taiwan(Shurson, 2003)
  • Study conducted at Lin-Fong-Ying Dairy Farm
  • a commercial dairy farm located about 20 km south
    of the Tropic of Cancer
  • DDGS was shipped from Watertown, SD to Taiwan in
    a 40 ft. container
  • upon arrival in Taiwan, DDGS was re-packaged in
    50 kg feed bags with a plastic lining
  • DDGS bags were stored in a covered steel pole
    barn for 10 weeks during the course of the dairy
    feeding trial

71
Fat Stability of DDGS in Taiwan
Peroxide values acceptable for fat quality and there is no
oxidative rancidity.
72
Lysine Digestibilityas Affected by Production
Source
73
DDGs Nutrient Characteristics
Noll Parsons, unpublished data
74
DDGs Nutrient Characteristics
Noll Parsons, unpublished data
75
DDGs Nutrient Characteristics
Noll and Parsons, unpublished data
76
Economics and DDGs Quality
77
Comparison of DDGS Total Amino Acids
(Digestible)
78
Influence of digestible lysineon value of DDGs
(/cwt)
Write a Comment
User Comments (0)
About PowerShow.com
