Crash Recovery

1
Crash Recovery
2
Review The ACID properties

• A tomicity All actions in the Xaction happen,
  or none happen.
• C onsistency If each Xaction is consistent, and
  the DB starts consistent, it ends up consistent.
• I solation Execution of one Xaction is
  isolated from that of other Xacts.
• D urability If a Xaction commits, its effects
  persist.
• CC guarantees Isolation and Atomicity.
• The Recovery Manager guarantees Atomicity
  Durability.

3
Why is recovery system necessary?

• Transaction failure
• Logical errors application errors (e.g. div by
  0, segmentation fault)
• System errors deadlocks
• System crash hardware/software failure causes
  the system to crash.
• Disk failure head crash or similar disk failure
  destroys all or part of disk storage

• The data we will lose can be in main memory or in
  disk

4
Storage Media

• Volatile storage
• does not survive system crashes
• examples main memory, cache memory
• Nonvolatile storage
• survives system crashes
• examples disk, tape, flash memory,
  non-volatile (battery backed up) RAM
• Stable storage
• a mythical form of storage that survives all
  failures
• approximated by maintaining multiple copies on
  distinct nonvolatile media

5
Recovery and Durability

• To achieve Durability Put data on stable
  storage
• To approximate stable storage make two copies of
  data
• Problem data transfer failure

6
Stable-Storage Implementation

• Solution
• Write to the first disk
• Write to the second disk when the first disk
  completes
• The process is complete only after the second
  write completes successfully
• Recovery (from disk failures, etc)
• Detect bad blocks with the checksum (e.g. parity)
• Two good copies, equal blocks done
• One good, one bad copy good to bad
• Two bad copies ignore write
• Two good, unequal blocks?

Ans Copy the second to the first
7
Recovery and Atomicity

• Durability is achieved by making 2 copies of data
• What about atomicity
• Crash may cause inconsistencies

8
Recovery and Atomicity

• Example transfer 50 from account A to account B
• goal is either to perform all database
  modifications made by Ti or none at all.
• Requires several inputs (reads) and outputs
  (writes)
• Failure after output to account A and before
  output to B.
• DB is corrupted!

9
Recovery Algorithms

• Recovery algorithms are techniques to ensure
  database consistency and transaction atomicity
  and durability despite failures
• Recovery algorithms have two parts
• Actions taken during normal transaction
  processing to ensure enough information exists to
  recover from failures
• Actions taken after a failure to recover the
  database contents to a state that ensures
  atomicity, consistency and durability

10
Background Data Access

• Physical blocks blocks on disk.
• Buffer blocks blocks in main memory.
• Data transfer
• input(B) transfers the physical block B to main
  memory.
• output(B) transfers the buffer block B to the
  disk, and replaces the appropriate physical block
  there.
• Each transaction Ti has its private work-area in
  which local copies of all data items accessed and
  updated by it are kept.
• Ti's local copy of a data item X is called xi.

• Assumption each data item fits in and is stored
  inside, a single block.

11
Data Access (Cont.)

• Transaction transfers data items between system
  buffer blocks and its private work-area using the
  following operations
• read(X) assigns the value of data item X to the
  local variable xi.
• write(X) assigns the value of local variable xi
  to data item X in the buffer block.
• both these commands may necessitate the issue of
  an input(BX) instruction before the assignment,
  if the block BX in which X resides is not already
  in memory.
• Transactions
• Perform read(X) while accessing X for the first
  time
• All subsequent accesses are to the local copy.
• After last access, transaction executes write(X).
• output(BX) need not immediately follow write(X).
  System can perform the output operation when it
  deems fit.

12
buffer
input(A)
Buffer Block A
X
A
Buffer Block B
Y
B
output(B)
read(X)
write(Y)
disk
x2
x1
y1
work area of T2
work area of T1
memory
13
Recovery and Atomicity (Cont.)

• To ensure atomicity, first output information
  about modifications to stable storage without
  modifying the database itself.
• We study
• log-based recovery
• Database
• Files storing the actual data
• Log
• Another file storing the actions of transactions

14
Log-Based Recovery

• Simplifying assumptions
• Transactions run serially
• logs are written directly on the stable stogare
• Log a sequence of log records maintains a
  record of update activities on the database.
  (Write Ahead Log, W.A.L.)
• Log records for transaction Tj
• Two approaches using logs
• Deferred database modification
• Immediate database modification

15
Log example
Log 2050
Transaction T1 Read(A) A A-50
Write(A) Read(B) B B50 Write(B)
16
Deferred Database Modification

• Write the modifications to a log
• And Defer execution of write operations till
  database commits
• Example
• Ti starts write a record to log.
• Ti write(X)
• write to log V is the new value for
  X
• The write is deferred
• Note old value is not needed for this scheme
• Ti partially commits
• Write to the log
• DB updates by reading and executing the log

17
Deferred Database Modification

• How to use the log for recovery after a crash?
• Redo if both and are
  there in the log.
• Ignore otherwise.
• Crashes can occur while
• the transaction is executing the original
  updates, or
• while recovery action is being taken
• REDO should be idempotent (i.e., executing
  several times should be the same as once)
• example transactions T0 and T1 (T0 executes
  before T1)
• T0 read (A) T1 read (C)
• A - A - 50 C- C- 100
• Write (A) write (C)
• read (B)
• B- B 50
• write (B)

18
Deferred Database Modification (Cont.)

• Below we show the log as it appears at three
  instances of time.

(a)
commit (b)
commit
(c)
- Only new values of an item are recorded in the
log (old values can be omitted). - At partial
commit time, after the log records are on stable
storage, the items are written to the database.
19
Immediate Database Modification

• Allow database modifications to be OUTPUT to the
  database before transaction commits.
• Tighter logging rules are needed to ensure
  transaction are undoable
• Write records must be of the form Vnew
• Both old and new values
• Log record must be written before database item
  is written/output
• Output of DB items can occur
• Before or after commit
• In any order
• But Log record should be written prior to Output
  of an item to database

20
Immediate Database Modification Example

• Log Database
• A 950
• B 2050
• C 600

21
Immediate Database Modification (Cont.)

• Recovery procedure
• Undo is in the log but
  is not. Undo
• restore the value of all data items updated by Ti
  to their old values, going backwards from the
  last log record for Ti
• Redo and are both in the
  log. Redo
• sets the value of all data items updated by Ti to
  the new values, going forward from the first log
  record for Ti
• Both operations must be idempotent even if the
  operation is executed multiple times the effect
  is the same as if it is executed once
• Undo operations are performed first, then redo
  operations. Why?

22
I M Recovery Example
2050 600 (c)
2050 600 (b)
2050 (a)

• Recovery actions in each case above are
• (a) undo (T0) B is restored to 2000 and A to
  1000.
• (b) undo (T1) and redo (T0) C is restored to
  700, and then A and B are
• set to 950 and 2050 respectively.
• (c) redo (T0) and redo (T1) A and B are set to
  950 and 2050
• respectively. Then C is set to 600

23
Checkpoints

• Problems in recovery procedure as discussed
  earlier
• searching the entire log is time-consuming
• we might unnecessarily redo transactions which
  have already output their updates to the
  database.
• How to avoid redundant redoes?
• Put marks in the log indicating that at that
  point DB and log are consistent. Checkpoint!

24
Checkpoints

• At a checkpoint
• Output all log records currently residing in main
  memory onto stable storage.
• Output all modified buffer blocks to the disk.
• Write a log record onto stable
  storage.

25
Checkpoints (Cont.)

• Recovering from log with checkpoints
• Scan backwards from end of log to find the most
  recent record
• Continue scanning backwards till a record start is found.
• Need only consider the part of log following
  above start record. Why?
• After that, recover from log with the rules that
  we had before.

26
Example of Checkpoints
Tc
Tf
T1
T2
T3
T4
checkpoint
system failure
checkpoint

• T1 can be ignored (updates already output to disk
  due to checkpoint)
• T2 and T3 redone.
• T4 undone

27
Recovery With Concurrent Transactions

• To permit concurrency
• All transactions share a single disk buffer and a
  single log
• Concurrency control Strict 2PL i.e. Release
  eXclusive locks only after commit. Why?
• Logging is done as described earlier.
• The checkpointing technique and actions taken on
  recovery have to be changed (based on ARIES)
• since several transactions may be active when a
  checkpoint is performed.

28
Recovery With Concurrent Transactions (Cont.)

• Checkpoints for concurrent transactions
• L the list of transactions
  active at the time of the checkpoint
• We assume no updates are in progress while the
  checkpoint is carried out
• Recovery for concurrent transactions, 3 phases
• Analysis Construction of Undo, Redo-Lists
• Perform Undo
• Perform Redo

29
Recovery With Concurrent Transactions (Cont.)

• 1. ANALYSIS Construction of Undo,
  Redo-lists
• a. Initialize undo-list and redo-list to empty
• b. Scan the log backwards from the end, stopping
  when the first record is found.
  For each record found during the backward scan
• if the record is , add Ti to redo-list
• if the record is , then if Ti is not
  in redo-list, add Ti to undo-list
• c. For every Ti in L, if Ti is not in
  redo-list, add Ti to undo-list
• ? This will add txns to undo-list that started
  prior to L but did not commit

ANALYSIS
30
Recovery With Concurrent Transactions

• Perform UNDO
• Scan log backwards
• Perform undo(T) for every transaction in
  undo-list
• Stop when reach for every T in
  undo-list.
• Perform REDO
• Locate the most recent record.
• Scan log forwards from the record
  till the end of the log.
• perform redo for each log record that belongs to
  a transaction on redo-list

UNDO
REDO
31
Example of Recovery

• Go over the steps of the recovery algorithm on
  the following log

Redo-listT3 Undo-listT4, T1, T2
Undo Set C to 10 Set C to 0 Set B to 0
Redo Set A to 20 Set D to 10
DB A B C D Initial
0 0 0 0 At crash 20 10 20
10 After rec. 20 0 0 10
32
Recovery Summary

• Durability
• Duplicate copies
• Ensuring Atomicity
• Deferred Logging --- Only Redo
• Immediate Logging -- Undo and Redo
• Checkpoints to limit log size
• Recovery of concurrent txns with checkpoints
• 3 phases

33
What we covered

• Relational model - SQL
• Formal commercial query languages
• Functional Dependencies
• Normalization
• Interfacing with Databases PL/SQL, JDBC
• Physical Design
• File storage
• Indexing
• Query Processing and Optimization
• Txns
• Concurrency Control
• Recovery

34
(No Transcript)
