A Differentiated Services Architecture for the Internet

1
A Differentiated Services Architecture for the
Internet

• References
• - K. Nichols, V. Jacobson, L. Zhang
• - D. Clark, J. Wroclawski
• Presented by Liping Zhang

2
Overview

• Introduction
• Two different service types implementation and
  problems
• Two-bit differentiated services architecture
• Problems with end-end bandwidth allocation based
  on level of marked traffic
• Discussion

3
Introduction

• Why do we need differentiated services?
• Different users
• Different applications
• Service allocation
• For example, one goal of assured service is to
  allocate the bandwidth of the Internet to
  different users in a controlled way during
  periods of congestion

4
How to describe a service

• What is provided to the customer
• E.g., 1 Mbps, continuously available
• To where is this service provided
• A single destination
• A group
• All nodes on local provider
• Everywhere
• Level of assurance provided to service
• What level of performance uncertainty can user
  tolerate

5
Two distinct service types

• Assured service
• D. Clark
• Premium service
• V. Jacobson

6
Assured service

• Provide different levels of best-effort service
  at times of network congestion
• Expected capacity
• In packets unlikely to be dropped
• Out packets - no assurance
• Queuing
• Best effort

7
Mechanism for assured service
Counter
Counter
Out- and in- dropper
First-hop
Host
Marking packets according to the service profile
RIO scheme, packets are treated preferentially
8
RIO algorithm

• RED - Random Early Detection
• Packets dropped with low but increasing
  probability as queue grows instead of waiting
  until it is full and dropping all new packets
• RIO
• Run two RED algorithms for in and out with
  different dropping frequencies

9
Premium service

• Fundamentally different Internet best effort
  service - high priority traffic has its own queue
  in routers
• Shaped, hard-limited to provisioned peak rate
• No bursts are injected into net
• Virtual wire, available whenever needed
• Regular flow pattern, no queuing
• Shared, with best-effort

10
Mechanism for premium service
Intra-network
Host
Router
First-hop
H-Q premium, no dropping L-Q best effort,
dropping on congestion
11
Two-bit differentiated services architecture

• Deploying both services
• More bits available in IP header, why not both
• Forwarding path mechanisms
• Leaf routers
• Input interface a traffic profile
• Output interface two queues (HQ, LQ)
• Intermediate routers
• Only have forwarding function
• Border routers
• A Profile Meter at the input interface

12
Traffic flow from end-host to ISP
Company A
Internal Router
Host
2
Border Router
1
First-hop Router
3
ISP
Border Router
13
Forwarding path primitives

• General classifier
• In leaf routers, transport-level signature
  matching
• Bit-pattern classifier
• Performs a two-way decision based on bit-pattern
• Bit setter
• A- and P-bits must be set or cleared in several
  places
• Priority queues
• Shaping token bucket
• At the leaf router for Premium traffic
• Policing token bucket
• At border router, for both P and A services

14
Block diagram of leaf router input functionality
Marker 1
Flow1
Flow N
Arriving packet
Marker N
Forwarding Engine
Packet Classifier
Clear AP bits
Best Effort
15
Markers to implement the two different services
Wait for token
Set P bit
Packet Input
N
Test if token
Set A bit
Packet Input
Y
16
Router output interface for two-bit architecture
P-bit set?
High-priority
No
If A-bit set? Inc a_cnt
Low-priority
If A-bit set? dec a_cnt
RIO queue management
17
Border router input interface Profile Meters
Token available ?
Clear A bit
N
A set
Y
Forwarding Engine
Is packet marked ?
Not marked
Y
P set
N
Token Available
Drop Packet
18
Passing configuration information

• Request to the leaf router
• Average rate, burst, service type (P or A)
• Ways of passing the message
• RSVP, SNMP, network administrator
• Authenticating the sender

19
Architectural framework for marked traffic
allocation

• Preconfiguring of usage profiles is practical
• Paying for level of service that is always
  available
• Allocation follows organizational hierarchies
• Each organization must be responsible for its DM
• Only bilateral agreements work

20
Bandwidth Brokers (BB)

• Roles
• Allocating and controlling bandwidth shares
• Responsibilities
• Parcel out a regions marked traffic allocation
  and set up the leaf routers within the local
  domain
• Managing messages sent across boundaries to
  adjacent region BBs

21
Examples

• A statically configured example with no BB
  message exchanged
• A statically configured example with BB messages
  exchanged
• Dynamic allocation and additional mechanism

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
RSVP and BBs

• Existing bilateral relations between BBs of
  adjacent trust regions are necessary for resource
  allocation
• A few bits in the packet header are used to mark
  the service class
• RSVP resource setup hop-by-hop
• Use RSVP between two adjacent ISPs (BB1/BR1 and
  BB2/BR2)

31
Discussion

• Extensibility of the current 2-bit architecture
• Service allocation for multicast
• Who should request the service
• Sender or receiver
• Deployment issues
• Security issues

32
2-bit differentiated services architecture

• Providing Controlled-Load and Guaranteed service
• P service for C-L service
• A constrained case of C-L service
• P service for G service
• The service model of P service fits G service
  model
