Beer and Loafing NHC 2004 Las Vegas, NV

1
Beer and LoafingNHC 2004Las Vegas, NV

• Brewing Water, Residual Alkalinity, and Mash pH

2
The First Rule

• Know what your local water chemistry is!

3
The Second Rule

• Know WHY you want to adjust your water!

4
The Third Rule

• If its not broken,

Dont Fix It!
5
Local Water And Beer

• Beer Styles came from local brewing water

• Burton Ale came from hard, high carbonate water

• Vienna Lager came from hard, medium carbonate
  water

• Guinness Stout came from medium hard, high
  carbonate water

• Oktoberfest came from medium hard, medium
  carbonate water.

• Pilsner came from very soft, low carbonate water

6
Hard vs. Soft Water

• Hard water refers to the scale that forms on
  pipes, and being hard for soap to lather.
• Hardness is a function of Calcium, Magnesium,
  Iron, Mangenese, etc.

• Soft just means that there is low Calcium and
  Magnesium.
• Hard and Soft are only half the story, the other
  half is the Alkalinity.

7
Reading a Water Analysis

• Table 1 - Water Report for Las Vegas Valley WD
  (2003)
• (All values, except pH, in parts per million
  (ppm) (1 ppm 1 mg/l)
• 17 ppm 1 grain of hardness/gallon (gpg)

• Moderate Bicarbonate
• Moderate Hardness
• High Sulfate
• Moderate Sodium
• Moderate Chloride

8
Famous Brewing Waters
These Numbers are Annual AVERAGES! The averages
are probably not representative of real ratios.
9
Mash pH Ions

• Calcium (Ca) 50-150 ppmImportant for most
  brewing biochemical reactions.
• Magnesium (Mg) 10-30 ppmAn essential nutrient,
  but usually not deficient. Acts similar to
  calcium.
• Bicarbonate/Carbonate 0-50 ppm for pale
  beers 50-150 for amber beers 150-250 for dark
  beersBalances the natural acidity of the malt.

10
Flavor Ions

• Sodium (Na) 0-150 ppmAccentuates the sweetness
  of the malt. Excess can cause harsh bitterness
  w/sulfate.
• Chloride (Cl) 0-250 ppmRounds out the maltiness.
• Sulfate (SO4) 50-150 ppmAccentuates the hop
  bitterness, makes it crispier. Excess causes
  harsh bitterness.

11
Water Adjustment for Extract Brewing

• Pre-treatment
• Odors/tastes Chlorine, Iron, Sulfur, metallic,
  etc.
• Carbon Filters, Campden Tablets, Water Softeners,
  Green Sand
• Flavor Tweaking
• Sulfate for hop bitterness
• Sodium/Chloride for Malt accentuation
• Fermentation Issues (Rare)
• Zn, Ca, Mn, Mg Yeast Nutrition, Beer Haze
• 30 Years ago, malt extract was for baking
• Now, mineral levels for mash chemistryfermentabil
  ity have been done for you.

12
Water Adjustment for Steeping

• (Na, Cl, SO4) Same as for Extract
• (Ca, Mg, HCO3) Steeping pH
• If your water is very high in bicarbonate, you
  may need calcium.
• Use a steeping ratio similar to mash 2-4 qts/lb.
• Ratio can be more dilute with darker malts
• Astringency is usually due to being too hot.

13
Water Adjustment for All-Grain

• (Ca, Mg, HCO3) Mash pH
• Calcium, Magnesium, and Bicarbonate control the
  Residual Alkalinity.
• Residual Alkalinity combines with the grain bill
  to determine the mash pH
• Mash pH determines fermentability, clarity,
  flavor, etc.
• (Na, Cl, SO4) Same as for Extract Brewing

14
Residual Alkalinity

• Mash pH is the net effect of the hardness,
  alkalinity, and the grainbill.
• Residual Alkalinity alkalinity - (Ca/3.5
  Mg/7)
• High RA means you should brew dark beers
• Low RA means you should brew light beers

15
Residual Alkalinity NomographDetermine your Base
Malt Mash pH
16
Raising RA with Bicarbonate
Add 140 ppm HCO3
17
Lowering RA with Calcium
Add 190 ppm Calcium
18
Neutralizing Alkalinity
Neutralize 225 ppm Alkalinity as CaCO3
19
Neutralizing Alkalinity cont

• Alkalinity can also be neutralized by adding acid
  to the mash.
• Lactic Acid (88 soln.) 11.8 mEq/ml
• Sulfuric Acid (96 soln.) 35 mEq/ml
• Phosphoric (86 soln.) 30 mEq/ml
• Divide Alkalinity As by 50 to get mEq/L
• 225 mg/L 50 4.5 mEq/L
• If mash water volume is 4 Gal (15 L), then 15 x
  4.5 67.5 mEq of acid are needed.
• Using Lactic acid 67.5/11.8 (6) ml of Lactic
  Acid
• Read New Brewing Lager Beer pp. 60-73 for more
  info

20
Acidifying the Sparge

• Usually Unnecessary!
• Malts have a lot of buffering power, which lasts
  until runnings fall below 1.008
• Acidifying the the mash water or sparge to 5.5 or
  6 pH can cause the mash pH to be less than 4.5,
  which inhibits beta amylase and will affect the
  taste.
• Batch Sparge and No-sparge techniques can ensure
  that runnings never fall below 1.016

21
Summary

• You can adjust your brewing water chemistry if
• You know where you are
• You know where you are going
• You know how to get there
• For more info, see
• How To Brew (Palmer) Chapter 15
• New Brewing Lager Beer (Noonan) Chapter 3
