Title: Products Only For Professionals


1
Products Only For Professionals
The strength to stand alone The insight to
show the way
2
Industry News
The Introduction of Flammable Vapor Ignition
Resistant (FVIR) Gas Water Heaters
3
The Bradford White
TM
Safety System
4
Flammable Vapor Ignition Resistant Residential
Gas Products
  • July 1, 2003 Conventional 30,40,50 gallon models
  • July 1, 2004Power Vent 30,40,50 gallon models
  • July 1, 2005All other gas products 75,000 BTUs
    and less

5
Who is the CPSC ?
  • Independent Federal Regulatory Agency
  • Directed by three commissioners appointed by the
    President and confirmed by the Senate
  • The President designates one of the commissioners
    as Chairman
  • Created in 1972 under the Consumer Product Safety
    Act, To protect the public against unreasonable
    risks of injuries associated with consumer
    products.
  • Information obtained from the CPSC web site
    www.cpsc.gov

6
A Look Back...
  • 1994 - Water Heater Joint Research and
    Development Consortium was formed and begins work
    with the CPSC on a technical solution to
    flammable vapor ignition
  • Source CPSC website www.cpsc.gov

7
Who Oversees the Project?
  • The Gas Research Institute
  • Technical Advisory Group
  • Representatives of the Gas Industry
  • Manufacturers
  • Industry trade associations
  • CPSC staff
  • Information obtained from the CPSC web site
    www.cpsc.gov

8
Is This Change a Federal Requirement?
  • No
  • The industry volunteered to develop a solution
    (and independently fund)
  • The CPSC agreed to postpone the regulatory
    process
  • Information obtained from the CPSC web site
    www.cpsc.gov

9
Flame Arrestor
10
The geometry of the louvers increase the velocity
of incoming air into the combustion chamber.
Arrestor
The combination of high velocity air entering the
chamber and the effect caused by combustion
prevents any flames from traveling backwards and
outside of the water heater.
11
ANSI Standard
  • Design Criteria
  • Gasoline Spill Test

12
Resistance to Lint, Dust and Oil Accumulation
  • The outlined requirement would be considered met
    when
  • The carbon monoxide concentration reaches
    equilibrium
  • The water heater shuts down, and requires a
    manual restart to resume operation.
  • Information obtained from the Addenda to the
    Second Edition of ANSIZ21.10.1-2001 CSA
    4.1-2001 American National Standard/CSA Standard
    for Gas Water Heaters Volume I, Storage Water
    Heaters with Input Ratings of 75,000 BTU per Hour
    or Less.

13
Ignition of Flammable Vapors and Gas Water
Heaters Standard Change
  • ANSI Z21.10.1 will be amended to include testing
    for flammable vapor ignition resistance and the
    accumulation for Lint, Dust and Oil.

14
ANSI Standard
  • Design Criteria
  • Gasoline Spill Test
  • Lint, Dust and Oil

15
How The Safety System Works
  • Should any flammable vapors be present in the
    chamber, the flame arrestor plate prevents the
    flames from traveling backwards and igniting
    vapors outside of the combustion chamber
  • The calibrated, multipurpose re-settable thermal
    switch quickly recognizes this and shuts down the
    pilot and main burner.
  • The switch also deactivates the burner and pilot
    in the unlikely event of restricted airflow
    caused by severe lint, dust or oil accumulation
    on the arrestor plate.

16
Scrubbing the Air
17
Scrubbing the Air
During normal operation, combustion air is drawn
into the water heater through openings in the
jacket.
18
Scrubbing the Air
The combustion air enters through holes in the
very bottom of the chamber.
19
Scrubbing the Air
  • One of the key reasons for minimal, if any,
    routine maintenance on the arrestor is because of
    the many air movement changes through the
    combustion chamber.
  • The Defender Safety Systems unique design causes
    several directional changes to the flow of
    combustion air.
  • This series of diversions is the key to
    scrubbing the air of the majority of lint and
    dust and providing years of trouble-free service.

20
Maintenance FREE!
  • No Regular cleaning of air inlet openings
  • or flame arrestor is required.

21
Cleaning the Arrestor
  • Arrestor can be cleaned with
  • Compressed Air and/or
  • Shop Vacuum

22
Cleaning the Arrestor
  • Even though no regular cleaning is required, the
    ScreenLokTM Flame Arrestor can be cleaned by
    removing the chamber door and blowing air through
    the jacket openings and/or vacuuming clean with a
    shop vacuum.

23
Keys to Safe Operation
  • Seal Integrity
  • There are several screws on the inner combustion
    chamber door. When working on the heater, it is
    important the gasket be intact when reinstalling
    the door and all screws are re-installed.
  • If the gasket is damaged, you must replace it
    with a new one.

24
Design Features
Draft diverter
Hydrojet diptube
Hot water outlet
Temperature and Pressure relief valve
Thermostat and gas valve
Drain valve
Combustion air entry holes
25
Design Features
  • Advanced ScreenLokTM Technology Flame Arrestor
    Design
  • Constructed of 304L stainless steel for
    outstanding impact, heat, crack and corrosion
    resistance.

Combustion air entry holes
26
Design Features
  • Re-settable Thermal Switch
  • Proven, reliable, bi-metallic switch will
    interrupt gas supply to the pilot and main burner.

Sealed inner door
27
Design Features
  • Pedestal Base

28
Design Features
  • Pedestal Base
  • Rugged and durable base allows easy transport and
    positioning. Resists corrosion in harsh
    environments.

29
Design Features
  • Piezo Igniter
  • Easy and quick lighting of the pilot burner by
    push button.

30
Design Features
  • Site Window
  • Offers a view into the combustion chamber to view
    pilot and burner operation.

31
Design Features
  • Standard Thermocouple
  • Conventional off-the shelf replacement parts for
    quick service.
  • Controlled Combustion System
  • Added strength with lower noise. Assures
    combustion air is directed through the
    ScreenLokTM Technology flame arrestor.

32
Design Features
  • Proven Burner Design
  • Used for many years to allow off-the-shelf
    replacement if necessary.
  • Low NOx Standard
  • Efficient and clean combustion on all models and
    sizes.
  • Meets or exceeds all air quality emission
    regulations.

33
No Stand Required
  • The National Fuel Gas Code will no longer require
    a water heater stand when a FVIR Heater is
    installed in a garage.
  • Local Codes may still require a stand

34
No Added Height!
  • Same compact and efficient dimensions

35
Clearance to Combustibles
  • Still - Zero Inches
  • on Sides and Rear

36
Components Not Affected
  • Thermocouple
  • Burner
  • Gas Valve/Thermostat

37
The DefenderTM Safety System
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Troubleshooting
43
Robertshaw Residential T-Stat (Approximate
Settings)
  • Warm 120?F
  • Hot 160?F
  • Each Notch is in 10F Increments
  • Temp Tolerance 5-10?F
  • Differential 18?F

44
Time Temperature it Takes to SCALD
  • 125F 1 ½ to 2 minutes
  • 130F-135 F 30 to 10 seconds
  • 140 F- 145F Less than 5 to 3 seconds
  • 150 F- 155F 1 ½ to 1 second
  • 160 F Less than 1 Second

45
Residential Control Valve
  • Pressure Regulation Built-in regulator accepts
    up to a maximum of 14 w.c. (1/2 PSI) of line
    pressure for both Natural and LP Gas and
    regulates down to proper manifold pressure
    (usually 4.0 w.c. for Natural and 10.0 w.c. for
    LP Gas)

Remember! The minimum supply pressure should
be at least 1.0 w.c. above the manifold
pressure.
46
Magnet/Thermocouple
  • A device incorporated with Gas Valve designed to
    operate in conjunction with thermocouple.
  • Thermocouple generates a current that energizes
    the magnet, holding the spring-loaded plunger
    open, to allow gas to pass through to pilot and
    main valve.
  • The magnet requires at least 7 millivolts to
    energize and will generally drop out at 2
    millivolts.
  • Thermocouple will generate 7-15 millivolts in
    closed circuit and 20-30 in an open circuit

47
Magnet Drop-out Test
  • Power up Magnet with a good thermocouple. Once
    pilot has been operating for at least 3 minutes,
    turn off the gas valve.
  • With the gas valve turned off, monitor the time
    it takes until the magnetic plunger assembly
    opens (you will hear a pop sound).
  • The time should be 45 seconds or more. If less
    than 30 seconds, replace gas valve.

48
Combustion Air Supply
  • The flow of combustion air must not be obstructed
  • Providing adequate air for combustion and
    ventilation is very important.
  • Insufficient combustion air will cause
    re-circulation of combustion products resulting
    in contamination that may be hazardous to life.

49
Commonly Asked Troubleshooting Questions
50
Condensation
Definition The change of water from a vapor to a
liquid state.
  • When the products of combustion, which are in a
    vapor state (CO, CO2, NOx, H2O) reach a
    temperature less than the dew point, the vapor
    changes to a liquid.
  • Initial start up of a water heater (Hot flue
    gases cool tank)
  • High Efficiency Water Heaters (85 and greater)

51
Pressure Test for Leaks
  • Install pressure gauge on drain valve, and close
    the cold water inlet to the water heater (make
    sure all faucets are off)
  • Turn thermostat up until main burner fires and
    let the pressure increase 15-20 PSI, then shut
    off heater
  • A sudden pressure drop indicates a tank failure,
    if the pressure holds for 10-15 minutes the tank
    is not leaking

52
Pilot Cannot be Lit
  • No incoming gas
  • Re-settable Thermal Switch has opened due to a
    Flammable Vapor incident or Lint, Dust and Oil
    accumulation
  • Gas control knob in Off position
  • Pilot knob not depressed while lighting
  • Pilot orifice obstructed or pilot tube kinked

53
Pilot Will Not Stay Lit
  • Thermocouple connection loose at valve
  • Thermocouple not being sufficiently heated by
    pilot
  • High draft conditions
  • Defective thermocouple
  • Open E.C.O.
  • Weakened Magnet in Gas Valve

54
Main Burner Will Not Come On
  • Thermostat setting too low for desired
    temperature, tank temperature satisfied
  • Thermostat differential thermostat may be out
    of calibration. Replace gas control valve if
    necessary.
  • Insufficient gas supply
  • Insufficient combustion air supply

55
Not Enough Hot Water
  • Thermostat set to low
  • Cold water inlet water temperature very cold or
    dip tube is defective
  • High demand periods
  • Water heater too small for household demand

56
How It Affects The Trade
  • No dimensional changes
  • No additional installation steps required
  • No water heater stand required for garage
    installations
  • Minimal additional troubleshooting required
  • Additional cost for heater

Local codes may still require stands
57
Youll Have Only Yourself To Blame
58
(No Transcript)
59
Your Future is Our Future
Write a Comment
User Comments (0)
About PowerShow.com
