ORAP New User Orientation

1

• ORAP New User Orientation

Carlos Garcia Strategic Power Systems, Inc.
March 4, 2007
2
Who is Strategic Power Systems (SPS)?

• Information Technology and Reliability
  Engineering Co.
• Compiling Reliability, Availability and
  Maintainability (RAM) data
• Focus
• Gas and Steam Turbine Plants
• Power Generation
• Oil and Gas
• Industry Methodology
• Common coding structure (EBS KKS)
• IEEE and ISO standards
• NERC and WEC compliant
• Strong support from EPRI

3
SPS WTUI
SPS notetakers at WTUI
4
Base ORAP

• Proprietary database
• Operating and maintenance information on total
  plant equipment
• Benchmarking
• Customer and market reports
• Participants submit data on a monthly basis
• Quarterly reports provided to participants

5
Data Requirements

• Event Data
• - Begin Date/Time/End Date
• - Outage Type (Forced, Scheduled, Unscheduled,
  Derating)
• - Component (Equipment that caused the Event)
• - Outage Mechanism (Failure or Maintenance
  Reason)
• - Detailed Narrative (Symptom, Corrective Action
  Performed
• and Root Cause of Outage)
• Operational Data
• - Service Hours
• - Reserve Hours
• - Attempted and Successful Starts
• - MW Hrs Generated or Hp, ETC
• Counter Reading Data
• - Total Service Hours
• - Factored Hours/Equivalent Hours
• - Total MW Hrs Generated
• - Total Starts, ETC

6
Data Output
Compares plant component data on a yearly basis
Compares all your unit(s) maintenance factors and
on a per year basis
RAM Benchmarking
7
ORAP Benefits

• Preventative Maintenance
• Trends across the Fleet
• Breakdown by components and sub-components (total
  plant)
• Availability
• Reliability
• Service Factor
• Starting Reliability
• Outage Factors
• Mean Time Values
• Benchmarking
• Your unit vs. total Fleet in ORAP
• Your unit vs. Best in Class Performers in ORAP
• Forecasting e.g. Hot Section Overhauls

8
Revenue Opportunity

• Extended Intervals Between Maintenance Engine
  Removals
• Determine Source of Downtime Frequency
  Duration
• Define Parts Life Limits Empirically
• ORAP Provides Critical Information That Helps You
  Better Understand Your Business
• ORAP Will Help Your Business Be Profitable
• Industry Expectations Return on Investment Must
  Result In
• 5 reduction in inventory
• 5 reduction in planned maintenance
• 25 reduction in unreliability
• 10 reduction in RO costs

9
Who Uses ORAP Just a Sample
10
Why ORAP?

• Largest and Most accurate RAM database
• All OEM Gas and Steam Turbines
• All markets
• Benchmarking
• Your unit vs. the Fleet and Best in Class
• Close Relationship with OEMs
• ORAP supports design and quality efforts with
  many OEMs
• Customer Focus
• Value-added service supporting participants and
  OEMs
• Open minded

11
Questions?
www.spsinc.com
12
Visit our Booths! 517 616
100 American Express Gift Card

• Register to WIN an Apple iPod Nano and a AMEX
  gift Card!
• Join ORAP here at WTUI
• We will send everything you need to your email

13
Detailed ORAP Screenshots
14
Event Data
15
Input - Events Screen
16
Input Counter Data
17
Input Operational Data
