C for Java Programmers

1
C for Java Programmers

• Lecture 13
• Vectors, Maps Lists

2
Last term in CFJ

• waaay back last week we discussed
• Template Functions
• Template Classes
• The Standard Template Library
• String Class
• Documentation
• Coursework 2

3
Todays action

• To start with were just going to get up to
  speed
• Templates
• The Standard Template Library
• Containers, Algorithms and Iterators
• And then look in much more detail at some vital
  structures
• Vectors
• Lists
• Maps
• The Short Answer Test

4
1. Templates Refresher

• Templates are somewhere near the peak of Object
  Orientation because they allow you to create
  completely reusable code
• Pretty novel but now completely standard in the
  C world.
• Remember templates are used for creating generic
  functions and classes.
• We tell the template what type of data to use
  when we create an instance of it and we can
  feed it anything.

5
Class Templates

• Remember the syntax for a template class
• template ltclass Xgt class sausage
• //everything you would have in a normal
  class
• //but using X to declare data with
• Then to create a specific instance of this class
  use the form
• sausage ltintgt mySausage
• Now when we look back at the template class we
  can substitute every use of class X for an
  integer and know this is how the class will work
  for mySausage.

6
Example Template Class
Code for our template class

• template ltclass Xgt class Couple
• public
• string name
• X value
• Couple(string n, X v) name n value v
• void double() value value value
• int main()
• Couple ltfloatgt decimal(Pi, 3.14)
• Couple ltstringgt text(Pie, Steak and Kidney)
• decimal.double()
• text.double()

Double works differently in each case. but works
7
Use Templates

• Templates can be incredibly useful
• You can create frameworks that you can apply and
  reapply. (E.g. sorting classes)
• Once theyre working they become the most
  re-usable code you will write.
• The idea of Templates has proven to be so good
  that there is a whole library of pre-written
  templates in C. This is the Standard Template
  Library.

8
Standard Template Library

• STL gives you huge flexibility and is extremely
  popular in professional programming circles.
• Its popular because its good Java has borrowed
  a lot of ideas from it.
• Dont be put off using them they are here to
  make your life easier.
• The vital point is just picking the right
  template for the problem in hand.

9
STL fundamentals

• At the core of the STL are three conceptual
  items, that allow us to use create usable
  objects
• Crucially these combine together. You use
  algorithms and iterators on the container you
  have chosen.

containers
algorithms
iterators
10
Types of Containers

• Remember that there are 3 types of Containers

Linear Lists Examples are Vector class List
class String class
Sequences
Paired containers Examples are Map
class multiset class Multimap class
Associative
Adapted from other containers queue class stack
class priority_queue
Adapted
11
Algorithms

• Every class in the STL has common features.
• Because of this there are special algorithms that
  you can use on lots of different template
  classes.
• Lots of generic algorithms are available in
  ltalgorithmgt - there are in fact more than 70 in
  the library.
• Examples are min(), max(), search(), sort()

12
Iterators

• An iterator is a kind of generalised pointer that
  we can used to traverse the elements of a
  container.
• At any point in time an iterator is positioned at
  exactly one place in a collection, and will
  remain there until moved.
• These iterators are vitally important for moving
  around your container. Not only that, the STL
  Algorithms almost all use these special pointers
  too. For example
• min_element() - returns an iterator to the min
  element in a range

13
Remember Strings are in the STL

• A String class was grudgingly implemented into
  the STL its a type of list and hence is a
  Sequence Container.
• This was because that although using null
  terminated string makes you a good person, they
  do have their weaknesses.
• You Have to use strcpy all the time and cant use
  simple operators. You can easily run into bugs
  too String objects add safety to your coding.

14
STL Strings mean we can use

• Assignment
• Concatenation
• Concatenation Assignment
• Equality
• ! Inequality
• lt Less than
• lt Less than or equal
• gt Greater than
• gt Greater than or equal
• Subscripting
• ltlt Output
• gtgt Input

Remember any class you write you can overload
these operators use the friend facility
15
Methods now Available

• append() - concatenate more text to the string
• substr() - cut out a substring of some size
• insert() - add some text into the string
• replace() - replace part of a string
• erase() - delete part of a string
• assign() - flexible way of assigning text
• compare() - lexically compare two stings
• find() - search for some text in the string
• rfind() - find some text - backwards
• c_str() - return the null-terminated version

16
2. Okay back at the ranch

• The three most important templates that you need
  to be aware of are
• vectors
• lists
• maps
• These dont necessarily work how you might expect
  and are quite different to their counterparts in
  Java.
• We will consider these popular templates, how we
  could use them, and how we can apply algorithms
  to them.

17
Vectors

• The Vector Class is the dominant list
  representation and housed in the ltvectorgt
  library.
• lt is essentially a dynamic array and very
  similar to the Java Vector object.
• It provides four constructors for defining a list
  of elements
• default constructor for an empty vector
• A copy constructor to copy and existing vector
• A constructor with a parameter telling us the
  lists initial size
• A constructor with two parameters the size of
  the vector and the value that its data is
  initialised with.

18
Setting up those Vectors

• So all of the following declarations are valid
• const int N20
• const int M40
• int length
• cout ltlt Enter size of vector
• cin ltlt length
• vectorltintgt A(10)
• vectorltfloatgt C(M)
• vectorltintgt D(length)
• vectorltJPPvariablegt E(N)

vector of 10 integers
vector of 40 floats
vector of length ints
20 JPPvariable vector
19
And initialising them too
vector of 10 ints with a value of 2

• vectorltintgt J(10,2)
• vectorltchargt K(5, a)
• Coordinate point new Coordinate(3,3)
• vectorltCoordinategt C(10, point)
• vectorltintgt K(J)
• You can assign one vector to another using the
  operator so long as they are of the same lttypegt.

vector of 5 chars all with a value of a
vector of Coordinates all initialised as (3.3)
Intitialising one vector using another
20
Common Vector Mistake

• Consider the following code. What type of object
  is A?
• vector ltintgt A10
• Object A is not a vectorltintgt object with 10
  elements of type integer.
• Rather, the object A is in fact an array of size
  10, whose elements themselves are vectors.
• The reason is because the 10 is contained within
  square brackets not parentheses. We didnt call
  the vectors constructor at allwe set up an array.

21
Member Functions

• The most commonly used member functions are
• If you are using a vector photocopy the member
  functions from a page in your textbook there
  are lots. It will save you lots of time and make
  your coding much more effective.

size() - returns the vectors current
length begin() - returns an iterator to
the start of the vector end() - returns an
iterator to the end of the vector push_back()
- puts a value on the end of the vector insert()
- inserts an element anywhere in the
vector erase() - Remove an element
22
Overloaded Vector Operators
Assignment Equality !
Inequality lt Less than lt Less than or
equal gt Greater than gt Greater than or
equal Subscripting

• By overloading a template we have a really
  flexible structure which we can now often treat
  in the same way we do a fundamental type.

So even though we have a vector we can access
elements in the same way as an array
23
Another CrAzY Example

• void display(vectorltchargt temp)
• cout ltlt size ltlt v.size() ltlt endl
• for(int i0 ilttemp.size() i) cout ltlt tempi
  ltlt
• int main()
• vectorltchargt v(10)
• for(int i0 ilt10 i) vi i a
• display(v)
• for(int i0 iltv.size() i) v.push_back(i10a
  )
• display(v)
• for(int i0 iltv.size() i) v.itoUpper(vi)

• display(v)

initialise the values
expand the vector
24
Accessing using an Iterator

• When we looked at arrays we saw that we could
  access individual elements through subscripting
  or by using a pointer.
• In just the same way we can access the elements
  of a vector through subscripting or using an
  iterator. To create an iterator we use the
  syntax
• vector lttypegtiterator name
• In practice this looks something like
• vector ltchargtiterator p

25
Iterators in Action

• int main()
• vectorltchargt v(10)
• vectorltchargtiterator p v.begin()
• int i0
• //display the contents of the array
• for(int i0 p ! v.end() p, i) p
  ia
• //display the contents of the array
• p v.begin()
• for( p ! v.end() p) cout ltlt p ltlt endl
• //convert to uppercase
• for(p v.begin() p ! v.end() p) p
  toUpper(p)

26
Inserting and Deleting elements

• insert() and erase() add and remove elements from
  a vector
• vectorltchargt v(10)
• vectorltchargtiterator p v.begin()
• p 2
• v.insert(p , 10, X)
• v.insert(p1 , v2.begin(), v2.end() )
• v.erase (p)
• v.erase (p1 , p5)

insert 10 chars of value X at the 3rd element
insert a whole vector v2 at the 4rd element
removes the element pointed to by p
removes the next 4 elements
27
Storing Class Objects

• Weve only stored elements in the above examples
  of built in types but we can of course use class
  objects.
• All of the commands function in exactly the same
  way for object elements there is no difference
  at all. For example
• vector ltBananagt bunch(7)
• vector ltBananagtiterator b bunch.begin()
• cout ltlt bunch.size ltlt endl
• for( b ! bunch.end() b) cout ltlt b ltlt endl
• bunch.erase( bunch.begin(), 3)
• bunch.pop_back()

28
This is Different to Java

• Straight away it is clear that vectors in C are
  not the same as in Java.
• The primary difference in Java is that the
  contents of a vector must be an object. Because
  of this you often have the hassle of wrapper
  classes.not so in C.
• Another difference is that in C the vectors
  must all be of the same type, which can be
  constrictive.
• So if we are left with the fact that we can only
  put objects of one type in a vectorcan we work
  around it?

29
A solution rears its head.

• There are several ways of getting round this
  problem we could use another container.
• But we can often use a vector full of pointers to
  objects as opposed to the objects themselves.
• Now we can use the rules of inherited classes
• A pointer to a parent class, can also point to a
  derived class.

30
Vector Power
myVector
stack
myVector0
myVector1
myVector2
myVector3
JPPVariable pointers
heap
31
3. Lists

• The list class supports a bi-directional, linear
  list. This is essentially a Linked List.
• Lists only support sequential access.This differs
  greatly to vectors which support random access
  you cannot use subscripting with a list.
• Setting up a list is very similar to a vector
• list ltintgt A(10)
• list ltchargt D(x, a)
• list ltJPPvariablegt E(otherList)

list of 10 integers
list of x floats,set as a
List of JPPvariables, copied from otherList
32
Its all just a linked list
list
stack
Fptr
variable
Bptr
Fptr
variable
null
Fptr
variable
Bptr
null
variable
Bptr
heap
33
Member Functions

• The most commonly used member functions are

size() - returns the lists current
length begin() - returns an iterator to
the start of the list end() - returns an
iterator to the end of the list insert()
- inserts an element anywhere in the
vector erase() - Remove an
element push_back() - puts a value on the end
of the vector push_front() - puts a value on
the start of the vector splice() - Join two
lists together merge() - merges two lists
together
size() - returns the lists current
length begin() - returns an iterator to
the start of the list end() - returns an
iterator to the end of the list insert()
- inserts an element anywhere in the
vector erase() - Remove an
element push_back() - puts a value on the end
of the vector
34
Lets add 100 to numbers

• int main()
• listltintgt myList
• for(int i0 ilt10 i) myList.push_back(i)
• cout ltlt Size ltlt myList.size() ltlt endl
• listltintgtiterator p myList.begin()
• for( p ! myList.end() p) cout ltlt p ltlt

• p myList.begin()
• for( p ! myList.end() p) p p 100
• p myList.begin()
• cout ltlt \n\n
• for( p ! myList.end() p) cout ltlt p ltlt


initialise the values
initialise the values
add 100 to elements
35
A common mistake with End

• As we have seen end() and begin() are extremely
  useful when handling these containers.
• But, a common mistake occurs with the use of end
  it does not point to the last element.
• Rather it points to the element after the last
  element. Hence the last element in a container is
  given by
• myList.end() - 1.
• This may seem a bit odd at first, but it is
  designed to help us add new elements to the end
  of your container.

36
pushing and shoving

• It is important to think about whether you want
  your most recent elements at the front or back of
  a list.
• Do you want to use push_front() or push_back()?
• It is often vital to make the right choice as it
  can quite significantly change the efficiency of
  your program -do you want your most recent
  additions more readily accessible or your oldest?
• Remember too that the insert() method can put an
  element anywhere in the list.

37
Sorting

• Forget your Bubblesorts these containers have
  methods for organising the data. You can use the
  sort() member function to sort a list
• int main()
• listltintgt myList
• for(int i0 ilt10 i) myList.push_back(rand())

• myList.sort()
• listltintgtiterator p myList.begin()
• while( p!myList.end() ) cout ltlt p ltlt endl

38
4. Maps

• Maps are quite different from vectors and lists
  they are an example of an Associative container.
• In this structure unique keys are mapped with
  values. Once stored the values can then be
  retrieved by using the key.
• map ltkey_type, value_typegt name
• In a map only unique keys are allowed (To use
  nonunique keys you would have to setup another
  associtaive container called a multi-map.)

39
Pairs

• Inside the map itself we have these key-value
  pairs, and these are stored as objects of type
  pair
• template ltclass Ktype, class Vtypegt struct pair
• typedef Ktype first_type
• typedef Vtype second_type
• Ktype first
• Vtype second
• pair()
• pair(const Ktype k, const Vtype v)
• templateltclass A, class Bgt pair(constltA, Bgt ob)

in the STL a pair is a struct template
3 ways of setting up the pair
40
Adding Pairs to the Map

• When we are constructing a map we need these
  pairs to fill it with. The syntax for this is as
  follows
• map ltint, stringgt m
• m.insert(pairltint, stringgt(1,Beckhams left
  foot))
• You can also can also construct a pair using the
  make_pair() function. The advantage of this is
  that you dont need to specify the types its
  automatically worked out for you by the compiler
• m.insert( make_pair ( 2,Dirty argies) )

41
Map Functions
size() - returns the no. of elements in the
map insert() - inserts a pair into the
map begin() - returns an iterator to the
start of the map end() - returns an
iterator to the end of the map clear() -
removes all elements from the map find() -
Returns an iterator to the specified
key count() - Returns the no. of time a key
occurs

• You can also use subcripting returns a
  reference to the elemnt specified by i. If the
  element doesnt exist it is inserted.

42
Sorting through a Map find()

• int main()
• map ltchar, intgt m
• for(int i0 ilt26 i0)
• m.insert( make_pair( pair ltchar,intgt (Ai,
  65i) )
• / Or m.insert( make_pair( pair ltchar,intgt
  (Ai,Ai) /
• char ch
• cout ltlt Enter a key
• cin gtgt ch
• map ltchar, intgtiterator p
• p m.find(ch)
• cout ltlt The ASCII value of
• cout ltlt p-gtfirst ltlt is ltlt p-gtsecond

find locates the key we are looking for
now we use the iterator to access the first and
second (key and value) properties
43
Exercise of the day

• Write a function that reads an undefined number
  of person data from standard input and prints
  them out sorted on age.
• Transform your function into a template such that
  it can read any kind of data, and sort it on any
  field.
