ARM

1
ARM

• UNCA ECE 406
• April 6, 2007

2
Acorn Computers

• Early builder of microcomputers
• BBC Micro
• First ARM-like designed by Sophie Wilson
• Math undergraduate at Cambridge
• Based on a 1977 cow feeder
• Steve Furber implemented as ARM

3
Apple

• Invested in ARM for Apple Newton
• First PDA
• But with handwriting recognition problems
• Advanced RISC Machines
• Acorn spin-off with Apple support

4
ARM

• IP cores
• Intellectual properties
• Building blocks of ASIC
• Mostly purchased as code
• At a high price
• Cirrus Logic makes ARM processor chips

5
Many uses

• PDAs, cell phones
• MP3 players, satellite radio
• Smart cards
• GPS
• Calculators
• Routers
• Disk drive controllers

6
ARM7DMI

• ARM core 7
• JTAG debug
• Fast multiply
• EmbeddedICE macrocell
• For breakpoints
• Popular low-power implementation
• iPod, Nintendo DS

7
StrongARM

• DEC and ARM build a faster processor
• Used in Apple Newton
• DEC sold to Intel
• Part of settlement of DEC/Intel patent suit over
  the patent use in Pentium

8
Intel XScale

• Successor to StrongARM
• Used in PDAs
• BlackBerry, Dell Axim, Zaurus
• Used in some media players
• Intel sold XScale to Marvell
• Monahans is the latest

9
Significant versions

• ARM 32 bit
• Thumb 16 bit
• Jazelle Java bytecode
• Used in 3G cell phones
• DoCoMo (HUGE)
• fully synthesizable

10
Programming

• Generally in C or C
• With assembly for higher performance
• Public domain compilers exists
• But generally ARM users can afford expensive
  computers
• Linux hobbyists may not

11
ISA 32 bit version

• 16 Registers
• R13 Stack pointer
• R14 Link register
• R15 Program counter
• CPSR
• N, Z, C, V bits and more
• Some registers can be banked
• In fast interrupt, 7 registers are banked

12
Instructions

• Execute
• All versions add, subtract, and, or, not
• Some versions
• Multiply
• Saturated add and subtract
• CLS (count leading zeros)
• Compare instructions
• Load/Store
• Branch
• OS control

13
Execute example

• ADD r7, r5, r3
• r7 r5 r3
• ADDS r7, r5, r3
• Also sets condition bits
• MOV r7, r5
• r7 r5
• MOV r7, 100
• r7 100

14
Barrel shifting

• MOV r3, r2, LSL 3
• r3 r2 ltlt 3
• MOV r3, r4, RSL r5
• R3 r4 gtgt r5
• Arithmetic shift is allowed
• Limited circular shift is allowed

15
Jumping around

• Branch
• Branch and link
• For subroutine calls
• Branch and execute
• To execute Thumb subroutines

16
Example program

• while (a ! b)
• if (agtb) a - b else b - a
• Example 3.35 in ARM System Developers Guide by
  Sloss, Symes and Wright

17
ARM assembly

• gcd
• CMP r1, r2
• BEQ complete
• BLT lessthan
• SUB r1, r1, r2
• B gcd
• lessthan
• SUB r2, r2, r1
• B gcd
• complete

18
With conditional execution

• gcd
• CMP r1, r2
• SUBGT r1, r1, r2
• SUBLT r2, r2, r1
• BNE gcd

19
Array load and store I

• int r7
• int r2
• r7 (r2)
• LDR r7, r2, 4!
• r7 (r2)
• LDR r7, r2, 4

20
Array load and store II

• int r7
• int r2
• r7 r2
• LDR r7, r2
• r7 (r21)
• LDR r7, r2, 4

21
Array load and store III

• int r7
• int r5
• int r2
• r7 r2r5
• LDR r7, r2, r5, LSR 0x2

22
Memory support

• Caches
• Explicit cache control
• Protected memory
• Paging

23
Example programs
