Office Ergonomics

1
Office Ergonomics
2
Office Work Human/Computer Interactions

• Work station design
• Posture
• Keyboards
• Software/human interactions
• Human Behavior

3
Office Work Human/Computer Interactions

• Early studies 1980s
• Eye problems
• Shoulder problems
• Lower back problems
• Neck strain
• Hand wrist problems

4
Office Work Human/Computer Interactions

• 1991 study of 420 medical secretaries
• 63 reported neck/shoulder pain
• 51 low back pain
• 30 hand/wrist pain
• 15 elbow pain

5
Whos At Risk?

• Nearly everyone, but women report more incidents
  of discomfort
• Low motivation
• Poor workstation design
• Many short term studies, few long term or
  independent studies.

6
Are some people at greater risk than others?

• Some researchers think so.
• Studies quoted on Cornells ergo web site link
  repetitive motion injuries to
• Working with the wrists in deviated postures for
  any reason causes compression of the median
  nerve
• Static postures, especially using a pinch grip to
  hold something in place

7
Some studies have shown greater risks for people
who are

• Pregnant
• Obese
• Lack general physical capabilities, such as
  strength
• People who feel as if they lack control over work
  pace, environment, and communication

8
Prevention is crucial to Cost Containment

• Evaluate all contributing factors
• Hazard Identification

Task/Processes
Environment
Workers
Equipment/Materials
9
Hazard Prevention

• Neutral positioning
• Workstation design
• Work/rest periods
• Task rotation
• Exercise

10
What is neutral positioning?

• Non-stressed postures
• Relaxed, right angles at
• Knees, hips and elbows
• Wrists straight rather than flexed (down) or
  extended (up)
• Lower and upper back supported

11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
Computer Workstations

• Key Elements
• Good Working Positions
• Work Process
• Workstation Environment
• Workstation Components

15
Good Working Postures
16
Work Process

• Task Organization
• Impacts repetition
• Prolonged periods of activity
• Medical awareness training

17
Work Environment

• Lighting
• Glare
• Ventilation
• Noise

18
Workstation Design

• Chairs
• Monitors
• Keyboards
• Pointer/Mouse
• Wrist/Palm Support
• Document Holders
• Desks
• Telephones
• Footrests

19
Elements of good work station design

• Adjustable chairs
• Keyboard height and angle
• Avoid sharp edges
• Monitor height and angle
• Glare, poor contrast, etc. are risk factors

20
Chairs

• Ideas about correct posture go back to 1884
• Upright vs. backward leaning, pressure on disks,
  lower back
• Chair provides support for upper and lower back

21
Chairs

• Need to be adjustable in many different
  directions
• Height
• Tilt of seat pan
• Angle of back
• Provide lumbar support
• Adjustable arms
• Capacity, seat width

22
Ergonomic Chairs
Small Seat Minimal Contour
Seat Height 16.5" - 21.5"Backrest 19.5"W x
22.5"HSeat Size 19"W x 17"D
23
Ergonomic Chairs
Deep Contoured Seat, Knee Tilt Available
Big Tall
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Monitors

• Viewing Distance 20-40
• Viewing Angle 15-20 degrees
• below horizontal
• Viewing Time
• Viewing Clarity

28
Keyboards

• The objective is to keep the hands and wrists in
  as neutral a position as possible
• Adjustments, may include tilting or not tilting
  the keyboard, wrist rests in front of the
  keyboard, and repositioning the entire body
• Alternative shapes of keyboards may help
• Split
• Tented/Angled
• Negative Slope
• Supportive
• Scooped

Keep in mind Keyboard Placement Height
Distance Design Use
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
Pointer/Mouse Interactions

• For CAD operators
• Thumb and forefinger problems
• Change kind of mouse
• Thumb joint pain, switch to Uniball or
  three-finger mouse

Keep in mind Pointer Placement Pointer Size,
Shape, Settings
34
Wrist/Palm Supports

• In general, research supports the idea of resting
  the hands on some kind of a surface during keying
  pauses.
• The use of wrist rests has been associated with
  reduced muscle activity in the arms and
  shoulders, straighter wrist postures, comfort,
  and preference.

35
Wrist/Palm Supports

• Some research suggests that wrist rest users sit
  in a somewhat more reclined posture than people
  without wrist rests, which is known to be
  comfortable and healthy for the back
• However, wrist rests are not without potential
  problems

Caution
36
Wrist/Palm Supports

• Not all studies of wrist rests show positive
  effects
• Use of wrist rest causes the fluid pressure in
  the carpal tunnel to rise, sometimes
  significantly
• Use of convex wrist rests, which concentrate
  pressure in a small area, are less desirable than
  broad, flat ones
• Benign cysts apparently have been caused by
  constant pressure on the wrist
• Typists should use them during keying pauses, not
  during keying, in order to have free hand and arm
  movement and to reduce the amount of time the
  wrist is compressed

37
Document Holder

• Are designed to minimize eye and neck movement by
  keeping your documents at the proper viewing
  level

38
Desks

• Work Surface Depth
• Location of Frequently Used Devices Should be
  Located in Repetitive Access Zone

Recommended Zones for Workplace Components
39
(No Transcript)
40
Telephones

• Head sets can help avoid neck and shoulder strain
  for telephone use.

41
Footrests

• Reduces leg strain and promotes circulation
• Reduces strain on lower back
• Should position your knees to roughly a 90 degree
  angle

42

• Other Considerations

43
Work/rest periods

• An element of a good prevention strategy
• Provide regular breaks by inserting a different
  kind of task into the routine
• Some studies recommend 5 minutes of rest per
  hour of typing
• Other studies recommend 15 minutes of rest per
  four hours of work.

44
Task Rotation

• Alternate other kinds of office tasks, such as
  filing, copying
• Caution May be just as repetitive as typing and
  use the same motions and muscles
• However, more productive and feel less like an
  interruption than just a break

45
Task Rotation Breaks

• Some companies have actually installed software
  that shuts down the system for regular breaks
• Other companies have organized or signaled
  breaks
• These can be aggravating, as they interrupt a
  task in progress

46
Eye Strain

• Eyestrain is the most common complaint from
  computer users
• Intensive use
• Software Interactions
• Inadequate or detrimental lighting and monitor
  conditions
• Distance to monitor
• Ambient lighting
• Glare
• Pre-existing eye conditions, including those you
  may not be aware of
• Stress

47
(No Transcript)
48
Eye Strain

• A study conducted by Cornell University
• Showed that there was an increase in the number
  of cases of repetitive stress injuries after new
  and hard to use software was introduced
• Especially if there were multiple screens or
  fields on the monitor simultaneously

49
Eye Strain

• Prevention
• Task rotation
• Get a professional eye examination
• Control the lights the monitor
• Enough light on documents
• Eliminate glare
• Rearrange the workstation
• Anti-glare screen

50
Solving Office Ergonomic Problems

• Evaluate non-work stressors
• Evaluate work stressors
• Use checklists
• Use workers compensation claim data
• Use personal interviews/discomfort surveys
• Conduct job safety analysis
• Observation
• Measurements
• Implement solutions
• Provide Employee Training

51
Analyze a problem job

• Think about the role behavior plays in ensuring
  proper use and comfort.
• A claim of ergonomic design will not ensure
  improved use or comfort, (or reduced risk
  factors) if behaviors have been ignored
• For instance, if workers will not use the new
  tool, it cannot reduce the risk

52

• Questions?
