Debugging parallel programs

1
Debugging parallel programs
2
Breakpoint debugging

• Probably the most widely familiar method of
  debugging programs is breakpoint debugging. In
  this method, you are allowed to specify locations
  in your program (breakpoints) where the program
  execution will suddenly stop, giving you the
  opportunity to examine the program's state. You
  can then either let the program execute one or
  more instructions at a time, or allow it to
  continue until another breakpoint, and examine
  the state again.
• Breakpoint debugging works very well for serial
  programs that do not interact with any other
  dynamic entities (other programs or real-world
  devices). However, programs in the parallel and
  real-time domains may have their behavior and
  results altered if interrupted by a debugger.
  Events may go undetected, message queues may
  overflow, and moving parts may fail to stop in
  time, causing real-world damage to machines or
  people.
• One solution is to instrument the code, but the
  most frequently used way to do this is to insert
  print statements by hand, which has numerous
  disadvantages and limited power. A tool to
  instrument a program at runtime would need many
  of the capabilities of a debugger and indeed, a
  typical debugger has most of the capabilities
  both to perform the instrumenting, and to help
  analyze the resulting trace data. A debugger
  could easily plant tracing instrumentation in the
  executing program, and just as easily could
  display the values of program data and arbitrary
  expressions collected, together with the
  associated source code and it could do it all
  interactively.
• The Cygnus approach uses the popular GNU
  debugger, GDB, both to set up and to analyze
  trace experiments. In a trace experiment, the
  user specifies program locations to trace and
  what data to collect at each one (using the full
  power of the source language's symbolic
  expressions). A simplified, non-symbolic
  description of the trace experiment is downloaded
  to a separate trace collection program. Then the
  program is run while the specially written trace
  collection program collects the data. Finally,
  GDB is used again to review the traced events,
  stepping from one tracepoint execution to the
  next and displaying the recorded data values just
  as if debugging the program in real time or
  GDB's scripting language is used to produce a
  report of the collected data, formatted to the
  user's specification.
• From http//www.redhat.com/support/wpapers/cyg
  nus/cygnus_heinsenberg/

3
TotalView

• Most of the time MPI programs are debugged using
  print statements.
• The most popular breakpoint debugger is TotalView

4
What is TotalView?

• TotalView is a sophisticated software debugger
  product of Etnus LLC.
• Used for debugging, analyzing, and tuning program
  performance.
• Especially designed for use with complex,
  multi-process and/or multi-threaded applications.

• Has been selected as the Department of Energy's
  Advanced Simulation and Computing (ASC) program's
  debugger.

5
Key Features of TotalView

• Provides source and assembler level debugging for
  serial, parallel, multi-process and
  multi-threaded codes.
• Portable able to be used in a variety of UNIX
  environments, including those with distributed,
  clustered, uniprocessor and SMP machines.
• Supports most popular parallel programming
  models/libraries such as MPI, OpenMP, Threads,
  PVM, SHMEM and hybrid.
• Provides all debugging facilities through easy to
  learn and use Xwindows based Graphical User
  Interface. Also provides a command line
  interpreter for non-GUI debugging.
• Can be used to debug a specified program, an
  unattached running process, or a core file.

6

• On a per process/thread basis, permits you to
  view
• Source code, assembler code, or both
• Source for called functions
• The execution stack trace (procedure calling
  stack)
• Stack variables and registers
• Program data (variables, arrays)
• MPI message queues
• Provides for the insertion and execution of "code
  fragments" within the current process context.
• Provides several types of "action points", as
  well as the ability to set, delete, suppress,
  unsurpress and save them
• process breakpoint - on a source line basis
• multi-process barrier - blocking breakpoint for
  parallel processes
• conditional breakpoint - where breakpoint occurs
  only if a code fragment expression is satisfied
• evaluation points - where code fragments are
  evaluated
• Allows you to easily modify program data
  (addresses, arrays, array slices, variables)
  while debugging
• Provides special features for memory related
  debugging
• Provides graphical visualization of array data
  during debugging session
• Includes an extensive web browser based online
  help system

7
(No Transcript)
8
(No Transcript)
9
Detecting races with trace analysis

• The objective of trace analysis techniques is to
  identify races in parallel programs.
• The strategy consists in (conceptually)
• executing the program,
• generating a trace of all memory accesses and
  synchronization operations
• Building a graph of orderings (solid arrows
  below) and conflicting memory references (dashed
  lines below)
• Detecting races (when two nodes connected by
  dashed lines are not ordered by solid arrows)
• Example Intel Thread Checker

10
Doacross synchronization
11
(No Transcript)
12
(No Transcript)
13
Replay

• Races are possible in MPI programs.
• For debugging we want to keep a history of events
  so that every time we run the program during
  debugging we get the same behavior.
• See Optimal tracing and replay for debugging
  message-pass in parallel programs R. H. B. Netzer
  B. P. Miller Proceedings of the 1992 ACM/IEEE
  conference on Supercomputing Minneapolis,
  Minnesota, United States Pages 502 - 511   Year
  of Publication 1992 ISBN0-8186-2630-5

14
