Title: Next Generation SONET Protection Schemes


1
Next Generation SONET Protection Schemes
  • Bobby Scharmann
  • Shilpa Choudhary
  • July 27 2005

2
Overview
  • Background Information
  • SONET Details
  • Protection/Restoration Schemes
  • OPNET
  • DARPANET/NSFNET
  • Results
  • Summary/Conclusions

3
Network
  • A network is simply a group of devices connected
    to share resources.
  • Centralized vs. Distributed

4
Network Topologies
  • Mesh Topology
  • Star Topolgy
  • Ring Topology

5
Mesh Topology
  • Advantages
  • Few Traffic Problems
  • Robust to Failures
  • Privacy and Security
  • Disadvantages
  • Cabling is Expensive
  • Figure from http//www.webopedia.com/TERM/t/topol
    ogy.html

6
Star Topology
  • Advantages
  • Less Expensive (Cabling)
  • Robust to Link Failures
  • Disadvantages
  • Less Secure
  • Central Point of Failure (Hub)
  • Figure from http//www.webopedia.com/TERM/t/topol
    ogy.html

7
Ring Topology
  • Advantages
  • Simplicity
  • Disadvantages
  • Lack of topological node degree
  • Figure from http//www.webopedia.com/TERM/t/topol
    ogy.html

8
Flow Control
  • Flow Control Procedure to ensure the transmitter
    does not overload the receiver
  • Stop and Wait
  • Sliding Window

9
Routing Data Across a Network
  • Circuit Switching
  • Packet Switching
  • ATM/Frame Relay

10
Circuit Switching
  • Dedicated communications path is created through
    the nodes of a network
  • Advantages
  • Network Resources are Static (Dedicated)
  • Disadvantages
  • Network Resources Wasted
  • Initial Overhead

11
Packet Switching
  • Data traverses nodes in the network from the
    source node to the destination node.
  • Advantages
  • Network resources can be shared
  • Simpler and no call setup
  • Disadvantages
  • Greater delay in getting from source to
    destination
  • Overhead for error-checking

12
Asynchronous Transfer Mode (ATM)/Frame Relay
  • ATM Similar to packet switching without the
    overhead, but data is broken up into fixed length
    packets (called cells) (53 bytes 48 bytes for
    data 5 bytes header)
  • Frame Relay Similar to packet switching without
    the overhead, but data is broken up into variable
    length packets called frames

13
Multiplexing Techniques
  • Time Division Multiplexing (TDM)
  • Statistical Time Division Multiplexing (STDM)
  • Frequency Division Multiplexing (FDM)

14
Time Division Multiplexing (TDM)
15
Statistical Time Division Multiplexing
  • Essentially a special case of TDM where if one
    input isnt sending data another input can send
    data

16
Frequency Division Multiplexing (FDM)
17
Overview
  • Background Information
  • SONET Details
  • Protection/Restoration Schemes
  • OPNET
  • DARPANET/NSFNET
  • Results
  • Summary/Conclusions

18
SONET/SDH
  • Synchronous Optical Network /Synchronous Digital
    Hierarchy
  • SONET /SDH, a high speed transmission technology
    designed to send traffic over fiber optical cable
  • Standard for optical telecommunications transport
    of TDM data
  • Network Styles
  • Expected standard for next two decades

19
SONET Specification
  • STS-1 Synchronous Transport Signal-1 -
    Electrical rate used within specific hardware
  • OC-1 Optical Carrier
  • - Optical equivalent for transmission across
  • fiber

20
The SONET/SDH Digital Hierarchy
21
SONET FRAME
  • SONET frame is a block of 810 bytes put out every
    125 microsec.
  • Described as a rectangle of bytes which consist
    of 90 columns and 9 rows.
  • There are 3 basic parts to each frame The
    section overhead, the line overhead and the
    synchronous payload itself.

22
Limitation of SONET
  • SONET traffic is carried in fixed bandwidth
  • groups
  • SONET has no built-in capability of
  • dynamically shifting bandwidth usage

23
DWDM
  • Dense wavelength division multiplexing
  • A form of frequency division multiplexing.
    Divides bandwidth of an optical fiber into many
    non-overlapping ?s
  • Cost Effective
  • Scalability

24
Next Generation SONET
  • New development of SONET/SDH Next generation
    SONET/SDH (NGS)
  • Next-generation SONET is the evolution and
    enhancement of existing SONET networks that sets
    a new economic level for network efficiency while
    increasing broadband service potential.

25
Enhancements in SONET
  • Enhancements include
  • Virtual concatenation (VCAT)
  • An inverse multiplexing technique
  • Link capacity adjustment scheme (LCAS)
  • Dynamically add/remove VCG members

26
VCAT
  • Virtual Concatenation allows number of small
    containers (e.g. STS-1) can be concatenated and
    assembled to form a larger sized container.

27
Virtual Concatenation
No Concatenation
VCAT
28
Inverse Multiplexing
  • A single "pipe" or data stream is split apart
    into multiple T-1 or E-1 data streams and then
    recombined to form the original stream.

29
Overview
  • Background Information
  • SONET Details
  • Protection/Restoration Schemes
  • OPNET
  • DARPANET/NSFNET
  • Results
  • Summary/Conclusions

30
Protection/Restoration Schemes
  • Protection (Pre-provisioned) to resolve a
    conflict due to a failure prior to the failure
    occurring
  • Restoration (Post-provisioned) to resolve a
    failure only once the failure has occurred
  • Types of Protection
  • 11 (Full)
  • MN (N number of working lines, M number of
    protection lines)
  • Tiered (Partial)

31
Protection Illustration
32
Restoration Illustration
33
11 Protection (Full)
  • Protection Essentially providing a dedicated
    line as backup in case the primary line fails

Primary
Backup
34
MN Protection
  • Protection Essentially providing M lines of
    backup for every N primary lines

35
Tiered Protection
  • Protection Essentially a partial protection
    scheme whereby only a certain ratio (?
    protection factor) of the lines are protected.
    Primarily for NGS VCAT inversed-multiplexed
    networks
  • Network protection as opposed to link protection

36
Tiered Protection
37
Overview
  • Background Information
  • SONET Details
  • Protection/Restoration Schemes
  • OPNET
  • DARPANET/NSFNET
  • Results
  • Summary/Conclusions

38
OPNET ModelerTM Tool
  • Convenient graphical editors
  • Easy to use point n click functions
  • Complete C/C interface for detailed coding

39
Workflow for Modeler
  • In this workspace, you can create a network
    model, collect statistics directly from each
    network object or from the network as a whole,
    execute a simulation, and view results.

40
Network Model
  • The project editor develops the network model,
    which comprised of a subnet and its nodes

41
Node Model
  • Define the behavior of each network Object
  • A single network object is typically made up of
    multiple modules defining its behavior

42
Process Model
  • The process model allows one to define the
    different protocol states used in the discrete
    event simulation.
  • The process model allows one to use C/C to
    program the functionality of the node modules

43
Simulation Sequence Editor
  • Control the simulations run-time characteristics

44
Overview
  • Background Information
  • SONET Details
  • Protection/Restoration Schemes
  • OPNET
  • DARPANET/NSFNET
  • Results
  • Conclusions

45
NSFNET DARPANET
46
Overview
  • Background Information
  • SONET Details
  • Protection/Restoration Schemes
  • DARPANET/NSFNET
  • OPNET
  • Results
  • Summary/Conclusions

47
Results
48
Results
49
Results
50
Results
51
Results
52
Overview
  • Background Information
  • SONET Details
  • Protection/Restoration Schemes
  • DARPANET/NSFNET
  • OPNET
  • Results
  • Summary/Conclusions

53
Summary
  • Literature Review
  • OPNET Tutorials
  • Simulations

54
Conclusions
  • The less protection offered the greater the
    carried load
  • The lower the node degree the greater the
    blocking probability
  • The higher the node degree the greater the
    availability

55
Acknowledgements
  • Dr. Ghani and Dr. He
  • National Science Foundation and Electrical
    Engineering Department
  • Murali Hari
  • Joseph Ayeleso
  • Gary and Karthik

56
THANK YOU!
