PHD Virtual Update:

1
PHD Virtual Update Introducing esXpress v3.5 for
Best-in-Class VMware Data Protection
2
PHD Virtual Our Focus
PHD Virtual provides industry-leading virtual
data protection and data recovery solutions for
VMware
esXpress enables companies to perform autonomous,
fault-tolerant backup and restoration of an
entire virtual environment in less time at lower
cost using virtual backup appliances(VBA's).
These small virtual machines can be deployed in
minutes on an ESX server to autonomously conduct
hot full or virtual full backups of virtual
machines.
3
Select esXpress Customers
4
The esXpress Backup Difference
Service Console Backup
VCB Backup
VBA Backup

• Additional hardware and software required
• Two-step restore
• Limited by of proxy servers
• Single point of failure
• Increase storage requirements
• Single user

• Server needed to control backups. Central point
  of failure
• Backups impact service console resources
• Backups impact LAN
• Not scalable limited CPU memory
• Single user

• Uses virtual backup appliances (VBA) small VMs
  to conduct hot full or virtual full backups of
  all VMs
• Operates outside of ESX console
• Requires no VM client agent or VCB
• No additional hardware software
• Block level image backup
• Multiple user

5
Anatomy of a VBA
A VBA (Virtual Backup Appliance) is a small Linux
Virtual Machine

• Turnkey turned off when not running
• New VBA is created for each backup
• Backs up one VMDK at a time
• Up to 16 VBAs can run on one host
• VBAs can be put into resource pools to control
  memory and CPU
• I/O can be controlled with innovative disk
  throttling
• Maintenance and patch free

VBA - OFF
VBA - ON
0M RAM 1G of disk space
256M RAM 3G of disk space
6
VBA Backup - Unmatched Benefits
High Performance Scalability

• Up to16 concurrent backup streams per ESX host
• Delta backups
• Block and File-level restore
• VBAs automatically added to meet backup
  requirements, no individual jobs needed
• Full VM recovery without using esXpress or other
  VM infrastructure (self-restore)
• Source-side global de-duplication across an ESX
  farm
• Fault-tolerant - VMware DRS/HA aware and
  VMotion compatibility

Cost Effective

• Per Host licensing with unlimited sockets
• Hardware-free growth/ scalability
• Software-free restore
• Built-in replication for DR

7
esXpress v3.5 New Release Capabilities

• Web-based management console
• Easy deployment Implementation
• Multi-user hierarchical configuration
• Policy-driven hierarchy for central configuration
• Source-side global de-duplication across entire
  ESX farm
• Greatly reduce LAN traffic and disk space usage
• Use any VMWare supported datastore and external
  NFS server for scalability
• Storage agnostic
• Advanced file-level restore
• Web-based multi-user compressed data instantly
  available

1
2
3
4
8
esXpress v3.5 GUI Web-Based Interface
Multi-user Hierarchy
1
Web-based Management Console
2
Multi-user Hierarchical Configuration

• Multi-user web-based interface allows users to
  administer from anywhere
• Delivered as virtual machine appliance for ease
  of installation and setup
• Virtual machine appliance can be deployed as
  duplication target upon role selection at startup

• Central management console provides one place to
  change all backup settings
• Policy-based hierarchical architecture simplifies
  configuration by using Global and Group-based
  settings
• Central backup target configuration allows choice
  in backup targets

9
esXpress Overview Fault Tolerance

• The Only fault tolerant virtual backup solution
• esXpress operates independently of hosts, as
  VBAs on other hosts in a cluster, automatically
  identify and backup new VMs once VMotioned to the
  new host.

10
esXpress v3.5 Source-side De-duplication
Source-side Global De-duplication
3
Source Base
251 Rate
11
ADVANCED REPLICATION
Change Blocks
Auto Restore
Only Changed Blocks are Replicated
Performs Auto Restore at Recovery Location
12
esXpress v3.5 Advanced File-level Restore
4
Advanced File-level Restore

• Multi-user
• Drill-down interface
• No client software
• Restore to source
• Compressed data

13
Cost-effective Pricing
Two SKUs and simple pricing to assist channel
with margin and sales
esXpress Enterprise
esXpress Pro

• 1,000 per host enabling 4 concurrent backups per
  host
• No additional hardware or software required
• Built-in replication for DR
• Bundled support 9 hr / 5 day week

• 2,000 per host enabling 16 concurrent backups
  per host
• No additional hardware or software required
• Built-in replication for DR
• Bundled support 9 hr / 5 day week

SMB and small installations
Enterprise and large datacenters
14
Diversified Customer Base
North America
EMEA
APAC
62 of Total
29 of Total
7 of Total
Note 2 sales to Rest of World
15
2009 and Beyond
INCREASEMARKET SHARE

• Build out global channel and direct sales
  capabilities, including OEM deals

BUILD NEW FEATURES

• Continued performance enhancements to increase
  technological lead

DEVELOP FOR NEW PLATFORMS

• Develop solutions for Hyper-V and Xen platforms
