.NET Framework Performance Tips, Tricks And
Tools Peter Ty Developer Evangelist .NET and
Developer Group
2
Outline

• Performance of .NET Framework for various
  application types
• ASP .NET Apps
• Windows.Forms Apps
• CLR drill down GC, JIT, Transitions..
• Useful Performance Tools/Pointers
• CLR, ASP .NET Performance Counters
• Profilers

3
.NET Framework
Orchestration
.NET Enterprise Servers
Building Block Services
.NET Framework
Windows (CE, ME, 2000, and .NET)
4
Performance Web Apps

• Porting and Measuring Real Customer Applications
• MSN, Dell, US West DSL ordering app, etc.
• Porting/measuring enterprise samples
• FMStocks, Duwamish, IBuySpy, etc.
• Measuring published benchmarks such as Doculabs
  Nile
• Benchmarking against technologies such as JSP

5
Nile Web Application Benchmark
1 Compaq ProLiant 8500 550 Mghtz Application
Server 1.2 gig RAM 1 Compaq ProLiant 8500 8CPU
550 Mghtz Database Server 4 gig RAM
4900
Dynamic Pages Served per Second
8 CPU 4 CPU 2 CPU
4200
3500
2800
2100
1400
700
6
Nile Web Application Benchmark
1 Compaq ProLiant 8500 550 Mghtz Application
Server 1.2 gig RAM 1 Compaq ProLiant 8500 8CPU
550 Mghtz Database Server 4 gig RAM
4900
Dynamic Pages Served per Second
8 CPU 4 CPU 2 CPU
4200
3500
2800
2100
1400
700
7
Web Apps Why The Win?

• Early versus late bound (ASP) environment
• Compiled versus interpreted environment
• Output caching gives big wins in some scenarios
• Highly scaleable Framework and foundation
• CLR (GC, JIT, Threadpool, etc.)
• Efficient ASP.NET HTTP pipeline
• Super efficient data access layer ADO.NET

8
Performance Best PracticesAll Managed Apps
9
Minimize Throwing Exceptions

• Exception handling is fast in managed code
• Throwing exceptions degrades performance
• Perf counters tell you exactly how many your app
  is throwing
• Port Visual Basic 6 OnError/Goto -gt Try/Catch

10
Use Early Binding

• Visual Basic and JScript support early and late
  binding
• Late binding can negate performance
• Late Binding requires work at runtime
• Late Binding (much slower)
• Early Binding (better performance)

Dim ds Ds New DataSet
Dim ds As New DataSet
11
Make Chunky Not Chatty Calls

• P/Invoke
• Interop
• Intra-App Domain
• Remoting (x-proc, x-machine)

12
Use Value Types

• Think OO structs on the stack
• Passed by value (default) and reference
• Use Value Types for small data
• .NET Frameworks primitive types are value types
  (for perf)
• Useful for items like Point (x,y coordinates)

13
Strings

• Use the mutable StringBuilder object when
  stitching together strings
• Strings are immutable i.e. creates a new object
  when using String.Concat
• Dont do (in V1)
• foreach(Char c in str) // use c
• Instead do
• for (int i 0 i lt str.Length i)
• // stri
• Both of the above cases make a big difference in
  large loops

14
Performance Best PracticesASP .NET Apps
15
Design For Caching

• Leverage the built-in ASP .NET caching features
• Output Caching
• Declarative lt_at_ OutputCache gt directive
• Vary by duration, param, header, custom etc.
• Fragment Caching
• Cache regions of a page by using user controls
• Cache API
• System.Web.Caching.Cache class
• Recommendation
• Specifically design your pages around these
  features can lead to massive perf wins

16
Nile Web Application Benchmark
1 Compaq ProLiant 8500 8CPU 550 Mghtz Application
Server 1.2 gig RAM 1 Compaq ProLiant 8500 8CPU
550 Mghtz Database Server 4 gig RAM
4900
Dynamic Pages Served per Second
4200
Output Cache off
Output Cache on
3500
2800
2100
1400
700
Major J2EE App ServerLinux 7.1 Major DB Vendor
ATL ServerWin 2KSQL Server
ASP.NET In Proc Win 2K SQL Server
17
EnableSessionStatefalse

• Session state is enabled out of the box by
  default
• Is an overhead if you dont leverage it
• Recommendation
• Disable session state for all pages that dont
  require/need session data
• Set to readonly if you read but do not update
  session state

18
EnableViewStatefalse

• ASP .NET allows pages/controls to maintain state
  across round trips
• State stored within viewstate hidden field
• Disabled with enableviewstate attribute
• Some downsides
• Increases network payload
• Performance overhead to serialize this
• Recommendation
• Examine your usage of this feature
• Always disable if you are not doing postback

19
Avoid Apartment Transition

• Managed code is free threaded
• Optimized for new .NET Components
• Very sub-optimal for apartment threaded
  components (i.e., STA COM objects)
• Recommendations
• Enable the lt_at_ AspCompattrue gt directive for
  pages that utilize apartment COM objects in ASP
  .NET
• Dont new STA com objects in page constructors
• Windows Forms apps are marked STA
• If possible, upgrade apartment threaded
  components to .NET (VB6-gtVB .NET)
• Always generate early-bound managed wrappers for
  COM components (avoid late bound hit) using
  tlbimp

20
Performance Best PracticesWinForms Apps
21
Startup Working Set - Model

• Console.Writeline(Hello World)
• 2.5MB
• Winform Empty Form
• 4.7MB
• Winform Form with 100 controls
• 5.6MB
• Once you bring in System.Data
• 1MB

22
Windows Forms Tips

• Use AddRange instead of Add
• All Windows Forms controls provide a method
  called AddRange
• AddRange takes a collection and adds it at once
• Instead of iteratively Adding each item use
  AddRange e.g. treeView1.Nodes.AddRange(treeNodes
  )
• Minimize the of assemblies loaded
• If theres no need for data connection pooling
  dont use it save 1MB

23
Pre-JIT To Startup Faster

• A Pre-JITed Assembly is a persisted form of
  JITed MSIL with class/v-table layout
• Done at install time or on demand
• Reduces start-up time
• SDK contains several Pre-JITed assemblies
• mscorlib, Windows Forms and drawing, etc.
• Native code has version checks and reverts to
  runtime JIT if they fail
• ngen.exe

24
Performance Best PracticeCLR (Common Language
Runtime) Drill down
25
GC Overview

• State of the art Mark and Compact Garbage
  Collector
• Supports pinning and interior pointers
• Two GCs architectures provided
• Server multi-thread, highly-scaleable GC
• Client single-threaded, concurrent GC
• Self tuning

26
GC Details

• Maintains multiple generations
• Based on object lifetime (G0-gtG1-gtG2)
• Cache conscious
• Gen 0 fits in L2 cache
• Low fragmentation, low memory overhead
• Keeps locality of reference intact
• Separate large block heap

27
GC Perf

• Perf of GC allocation similar to Heap allocation

• Limited by PC Bus speed
• Typical Pause time (on a P200)
• lt 1ms for Gen 0
• lt 10ms for Gen 1
• Full GC varies with working set
• Infrequent

28
Transitions (mgd/unmgd)

• Runtime makes it simple to call the OS
• Transitions happen when you call
• Unmanaged code from managed code
• Managed code from unmanaged code
• At a transition, the Runtime
• Performs requested data type marshaling
• Fixes calling convention
• Protects callee saved registers
• Switches thread mode so that GC wont block on
  threads in unmanaged code
• Erects an EH frame on calls in to managed code
  for EH clean up

29
Transition (Fixed Cost)

• Baseline cost
• PInvoke
• As low as 8 instructions if no marshaling
  required
• 31 if marshaling is required
• COM Interop
• About 65 instructions
• SuppressUnmanagedSecurity attribute is set in
  these measurements

30
Transition (Variable Cost)

• Incremental parameter marshaling cost
• Primitives are almost free
• Classes with explicit layout are almost free
• Data transformation (e.g., Unicode -gt Ansi,
  Object-gt IUnknown, etc.) is expensive

31
Just-In-Time Compilation

• All code runs as compiled native code
• No interpretation
• JIT performs standard optimizations
• Method Inlining
• Constant Folding
• Copy Propagation
• Common SubExpression Elimination
• Dead Code Elimination
• Enregistration of locals
• Instruction scheduling
• But, optimizations are limited in order to reduce
  compile time

32
Performance Best Practice Performance Tools
33
Perf Counters Overview

• Perf Counters are metrics about resource usage
  exposed by the .NET Framework
• First line of defense
• Always available
• Can be obtained non-intrusively even in
  production environment

34
Runtime Perf Counters (I)

• Loader
• of Execution Time Loading
• AppDomains, Assemblies, Classes etc.
• Memory
• Time in GC, bytes/sec, heap sizes and various
  metrics related to GC GenX
• Interop
• managed to unmanaged transitions
• Metrics on marshalling, stubs etc.
• Contexts and Remoting
• Remote Calls/Sec, Total Remote Calls
• of Channels, Contexts, Proxies etc.

35
Runtime Perf Counters (II)

• Threads and Locks
• of logical and physical threads
• Contention Rate/sec, Total of contentions
• JIT Compilation
• of time in JIT, of methods JITed, MSIL Bytes
  JITed/sec, etc.
• Others include Exceptions, Security and
  Networking
• All of the above are available through
  System.Diagnostics.PerformanceCounter
• Easy to create new perf counters

36
ASP .NET Perf Counters

• Requests/Sec
• Request Bytes in Total
• Request Bytes out Total
• Requests Executing
• Requests Total
• Application Restarts

37
Profiler Architecture
Console
Program under test
38
Profiling API

• CLR provides a rich set of services to monitor
  the health of your app
• These services expose events as your .NET app
  executes in CLR
• Through two COM interfaces ICorProfilerCallback
  and ICorProfilerInfo

39
Resources

• Intels VTune
• http//msdn.microsoft.com/vstudio/partners/tools/i
  ntel.asp
• Numegas TrueTime
• http//www.compuware.com/products/devpartner/profi
  ler/
• Rationals PurifyPlus
• http//www.rational.com/solutions/solutions_dotnet
  /

40
Summary

• .NET Framework is built for high performance and
  scalability
• With .NET Framework, your app inherits
  high-performance
• Easily leverage rich set of tools and techniques
  to build performant apps
• It is just easier to be faster on the .NET
  Framework
