C20.0046: Database Management Systems Lecture

1
C20.0046 Database Management SystemsLecture 1

• Matthew P. Johnson
• Stern School of Business, NYU
• Spring, 2004

2
Personnel

• Instructor Matthew P. Johnson
• KMEC 8-176, mjohnson_at_stern.nyu.edu
• Office hours KMC 8-176, Th 1215-215
• please visit!

• Tutor/TF/grader Matthew P. Johnson!

3
Communications

• Web page http//www.columbia.edu/mpj9/dbms
• syllabus
• course policies
• may move in the future
• Blackboard web site
• Some materials will be available here
• Discussion board
• send general-interest messages here to benefit
  all!
• Go to http//sternclasses.nyu.edu
• Click on C20.0046

4
Acknowledgements

• Thanks to Ramesh, Ullman, et al., Raghu and
  Johannes, Dan Suciu, Arthur Keller, David Kuijt
  for course materials
• See classpage for other related, antecedent DBMS
  courses

5
What Is a Database?

• A very large, integrated collection of data.
• Models real-world enterprise.
• Entities (e.g., students, courses, instructors,
  TAs)
• Relationships (e.g., Joe is taking C20.0046)
• George is currently taking C20.0046
• Dick is currently teaching C20.0046
• Condi is currently TA-ing C20.0046 but took it
  last semester
• A Database Management System (DBMS) is a software
  package designed to store and manage databases.

6
Databases are everywhere

• Example Ordering a pizza
• Databases involved?
• Pizza Huts DB
• stores previous orders by customer
• stores previous credit cards used
• Credit card records
• huge databases of (attempted) purchases
• location, date, amount, parties
• phone companys records
• Local Usage Details (Pull his LUDs, Lenny.)
• Caller ID
• ensures reported address matches destination

7
Your wallet is full of DB records

• Drivers license
• Credit cards
• NYUCard
• Medical insurance card
• Social security card
• Gym membership
• Money (serial numbers)
• Maybe even photos

8
Databases are everywhere

• Q Websites backed by DBMSs?
• retail Amazon, etc.
• data-mining Page You Made
• search engines Google, etc.
• directories Internic, etc.
• searchable DBs IMDB, tvguide.com, etc.
• Q Non-web examples of DBMSs?
• criminal/terrorist TIA
• airline bookings
• NYPDs CompStat
• all serious crime stats by precinct
• Retailers Wal-Mart, etc.
• when to re-order, purchase patterns, data-mining
• Genomics!

9
Example of a Traditional DB App

• Suppose we are building a system
• to store the information about
• checking accounts
• savings accounts
• account holders
• state of each of each persons accounts

10
Can we do it without a DBMS?

• Sure we can! Start by storing the data in files
• checking.txt savings.txt
  customers.txt
• Now write C or Java programs to implement
  specific tasks

11
Doing it without a DBMS...

• Transfer 100 from Georges savings to checking

Write a C program to do the following
Read savings.txt Findupdate the record
George balance - 100 Write savings.txt Read
checking.txt Findupdate the record
George balance 100 Write checking.txt
12
Problems without an DBMS...

• 1. System crashes
• Q What is the problem ?
• A George lost his 100
• Same problem even if reordered
• 2. Simultaneous access by many users
• George and Dick visit ATMs at same
• Lock checking.txt before each use what is the
  problem?

Read savings.txt Findupdate the rec
George. Write savings.txt Read
checking.txt Findupdate the rec George Write
checking.txt
CRASH !
13
Problems without an DBMS...

• 3. Large data sets (say 50GB)
• Why is this a problem?
• No indices
• Finding George in huge flatfile is expensive
• Modifications intractable without better data
  structures
• George ? Georgie is very expensive
• Deletions are very expensive

14
Problems without an DBMS...

• 5. Security?
• File system may be insecure
• File system security may be coarse
• 6. Application programming interface (API)?
• suppose need other apps to access DB
• 7. How to interact with other DBMSs?

15
General problems to solve

• In building our own system, many Qs arise
• how do we store the data? (file organization,
  etc.)
• how do we query the data? (write programs)
• make sure that updates dont mess things up?
• leave the DB consistent
• provide different views on the data?
• e.g., ATM users view v. bank tellers view
• how do we deal with crashes?
• Too hard! Go buy a DBMS!
• Q How does a DBMS solve these problems?
• A See third part of course

16
Big issue Transaction processing

• Grouping of several queries (or other database
  actions) into one transaction
• ACID properties
• Atomicity
• all or nothing
• Consistency
• constraints on relationships
• Isolation
• concurrency control
• Simulated solipsim
• Durability
• Crash recovery

17
Atomicity Durability

• Saw how George lost 100 with makeshift DBMS
• DBMS prevents this outcome
• xacts are all or nothing
• One idea Keep a log (history) of all actions in
  set of xacts
• Durability Use log to redo or undo certain ops
  in crash recovery
• Atomicity dont really commit changes until end
• Then, all at once

18
Isolation

• Concurrent execution is essential for
  performance.
• Frequent, slow disk accesses
• ? dont waste CPU keep running
• Interleaving actions of different user programs
• ?can lead to inconsistency
• e.g., two programs simultaneously withdraw from
  the same account
• DBMS ensures such problems dont arise
• users can pretend they are using a single-user
  system.

19
Isolation

• Contrast with a file in two Notepads
• Strategy ignore multiple users
• whichever saves last wins
• first save is overwritten
• Contrast with a file in two Words
• Strategy blunt isolation
• One can edit
• To the other its read-only

20
Consistency

• Each xant (on a consistent DB) must leave it in a
  consistent state
• can define integrity constraints
• checks the defined claims about the data remain
  true

21
Data Models

• Any DBMS uses a data model collection of
  concepts for describing data
• Schema description of partic set of data, using
  some data model
• Relational data model most widely used (by far)
  data model
• Oracle, DB2, SQLServer, other SQL DBMSs
• main concept relation table of rows columns
• a rels schema defines its fields

22
Example university database

• Conceptual schema
• Students(ssn string, name string, login
  string, age int, gpa real)
• Courses(cid string, cname string, credits int)
• Enrolled(sidstring, cidstring, grade string)
• Physical schema
• Relations stored as unordered text files.
• Indices on first column of each rel
• External Schema (View)
• Course_info(ssn string, name string)
• My_courses(cname string, grade string)

23
How the programmer sees the DBMS

• Start with DDL to create tables
• Continue with DML to populate tables

CREATE TABLE Students ( Name CHAR(30) SSN
CHAR(9) PRIMARY KEY NOT NULL, Category
CHAR(20) ) . . .
INSERT INTO Students VALUES(Howard, 123456789,
undergraduate) . . . .
24
How the programmer sees the DBMS

• Tables
• Still implemented as files, but behind the scenes
  can be quite complex

Takes
Students
Courses
data independence separate logical view from
physical implementation
25
Querying Structured Query Language

• Find all the students who have taken C20.0046
• SELECT SSN
• FROM Takes
• WHERE CIDC20.0046
• Find all the students who C20.0046 last fall
• SELECT SSN
• FROM Takes
• WHERE CIDC20.0046 AND SemesterFall, 2003
• Find the students names
• SELECT Name
• FROM Students, Takes
• WHERE Students.SSNTakes.SSN AND
• CIDC20.0046 AND SemesterFall, 2003
• Query processor does this efficiently.

26
Database Industry

• Relational databases are a great success of
  theoretical ideas.
• based on most theoretical type of math there
  is set theory
• DBMS companies are among the largest software
  companies in the world.
• Oracle, IBM (with DB2), Microsoft (SQL Server,
  Microsoft Access), Sybase.
• Also opensource MySQL, Postgres, etc.
• 20B industry.
• XML (semi-structured data) also important
• New lingua franca for exchanging data

27
The Study of DBMS

• Several aspects
• Modeling and design of databases
• DBMS programming querying and update
• DBMS implementation
• This course covers all three
• though more time on first two
• Also will look at some more advanced areas
• XML, data-mining, LDAP?

28
Databases are used by

• DB app programmers
• desktop app programmers
• web developers
• Database administrators (DBAs)
• design schemas
• security/authorization
• crash recovery
• tuning
• better paid than programmers!
• Everyone else (perhaps indirectly)

29
Course outline

• Database design
• Entity/Relationship models
• Modeling constraints
• The relational model
• Relational algebra
• Transforming E/R models to relational schemas
• SQL
• Views and triggers

30
Outline (Continued)

• Connecting to a database from a programming
  language
• Storage and indexing
• Transactions
• XML
• Advanced topics
• May change as course progresses
• partly in response to audience

31
Textbook

• Database Systems The Complete Book
• Hector Garcia-Molina, Jeffrey D. Ullman, Jennifer
  D. Widom
• 1st Edition (2001)
• Available
• NYU bookstore
• Amazon/BN (direct links on classpage)
• Amazon.co.uk (total is/was about 20 less)
• First two chapters in PDF on classpage

32
SQL Readings

• Optional reference SQL in a Nutshell
• Online (free) SQL tutorials include
• A Gentle Introduction to SQL (http//sqlzoo.net/)
• SQL for Web Nerds (http//philip.greenspun.com/sql
  /)

33
Grading

• Prerequisites Programming experience
• presumably C/C/Java
• Work Grading
• Homework 30 O(4)
• Project 30 - see below.
• Midterm (closed book/notes) 15
• Final (closed book/notes) 20
• Class participation 5
• Stern Curve
• Class attendance is required
• Absences will affect your total grade

34
The Project design end-to-end DB app

• data model
• Identify entities (and fields), relationships
• Identify resulting relations (tables)
• creation of DB in Oracle
• Insertion of real(alistic) data
• (web) app for accessing/modifying data
• Identification of interesting questions to ask
• Production of DBMS interface
• Work in pairs (start forming now)
• Choose topic on your own previous e.g.s online
• Start forming your group today!

35
Collaboration

• Homework and exams done individually
• Project done with your team members only
• Non-cited use of others problem solutions, code,
  etc. plagiarism
• See Sterns stern academic honesty policy
• Contact me if youre at all unclear before a
  particular case
• Cite any materials used if youre at all unclear
  after a particular case

36
On-going Feedback

• Dont wait until the end-of-semester course evals
  to complain or give feedback on how to improve
  course. (Its too late for you then!)
• Come see me early on during my office hours
• or send me email with your concerns
• Were in touch, so you be in touch.

37
Summary

• DBMS used to maintain, query large datasets.
• Benefits include recovery from system crashes,
  concurrent access, data integrity, security, and
  quick application development.
• Database skills are critical in financial
  services, marketing and other business areas!

38
So what is this course about, really ?

• A bit of everything !
• Languages SQL, XPath, XQuery
• Data modeling
• Some theory!
• Functional dependencies, normal forms
• e.g., how to find most efficient schema for data
• Algorithms and data structures (in the third
  part)
• e.g., indices make data much faster to find but
  how?
• Lots of implementation and hacking for the
  project
• Business DBMS examples/cases
• Most importantly how to meet real-world needs

39
For next time

• Get the book
• Read chapters 1, 2.1-2.2

40
For right now written survey

• name
• previous cs/is/math/logic courses
• previous programming experience
• career plans programmer, DBA, MBA, etc.
• why taking class
• any religious holidays during class
