Civil engineering,

1
HR Wallingford

• Civil engineering,
• environmental hydraulics, and
• water resources management

2
Flood Forecasting and Warning UK and Overseas
Experience
James Dent Technical Director - HR Wallingford
Ltd
3
Synopsis

• Examination of steps and sources of forecast
  material
• Information used to link rainfall and flood
  forecasts and warnings
• European research projects in flood forecasting
  and warning
• Bangladesh the first full-time flood forecasting
  and warning service

4
How do we forecast?

• Using weather forecasts, weather radar and
  satellite imagery
• Rainfall-runoff model (using radar or raingauge
  data)
• River level-to-level correlations using upstream
  gauging stations
• Time of travel relationships
• Real time hydraulic river model (ISIS model)

5
Types of weather forecast

• Seasonal/monthly too generalised
• Medium range,5 - 10 days. ECMRWF numerical
  weather forecasts, global model
• 2 - 5 day forecasts. Global model, daily weather
  charts
• 6hrs - 2-days. Mesoscale model charts and
  quantitative precipitation forecasts (QPF)
• 0 - 6hrs. Nowcasts mesoscale model and radar for
  QPF

6
Weather forecasts for the Environment Agency

• - Daily Weather Forecast
• Days 1 and 2 sub-daily periods, 6 or 12 hours
• Quantity as a most likely maximum point fall
• Indication of confidence as or high, medium or
  low
• On area basis
• Days 3-5 24 hour totals Area or Region
• - Heavy Rainfall Warning
• Forecast for 12-24 hours ahead, on Area basis
• pre-set triggers on accumulations or intensities
• total accumulation
• peak intensity and timing of heaviest rainfall
  period

7
Environment Agency river forecasts

• Flood Watch flooding from any river in a
  catchment is possible
• - use Met Office forecasts - particularly Heavy
  Rainfall Warnings
• - add value with knowledge of catchment
  conditions
• (Severe) Flood Warning flooding from a river is
  expected
• - river levels expected to reach a threshold when
  flooding to properties will commence
• - forecast of time when a given level will be
  reached
• - can be applied to a river reach or area

8
FORECASTING PRECIPITATION FROM THE FLOOD
HYDROLOGISTS PERSPECTIVE
9
(No Transcript)
10
Issues and Problems

• Definition in time and space
• Scale differences the mesoscale QPF model grid
  and the catchment size are seldom compatible
• How to apply QPF figure to a model lumped or
  distributed
• Accuracy the need for a consistent method in
  verification and assessment
• Operational limitations when and to what purpose
  can a QPF be applied?

11
The next steps

• Achieve a high degree of consistency across
  Regions
• Clearer identification of purpose
• Match QPF information with flow forecast model
  requirements
• Apply QPF at various stages during the
  forecast/warning operation to establish benefits
• Implement an agreed method of verification and
  assessment

12
Flood warning in Europe

• Catchments are considerably larger than UK. Time
  of travel models are effective.
• Problems of upper reaches within major
  catchments two tiers of flooding
• Trans-border rivers
• - data acquisition and sharing
• - compatibility of forecast methods
• - establishment of river basin management units
• - European Commission Research

13
European Flood Forecasting System

• European flood forecasting system with 4-10 days
  lead time
• 1 km grid square basis
• Model small and large river basins
• Develop a large scale hydrological model
• Include uncertainties in the discharge forecast
• Set-up a prototype system
• Explore dissemination of results

14
MITigation of Climate induced Hazards

• Concerted Action to cluster FP4 results (Jan 2001
  - May 2003)
• Floods, droughts and landslides
• Four workshops
• Climate change, forecasting, planning
• Emergency management in summer 2002 floods
• www.mitch-ec.net

15
AChieving Technological Innovation in Flood
Forecasting

• Integrating results from several EC research
  projects
• Promotion of sustainable development reducing
  economic loss
• Improved public safety by non-structural methods
• Interdisciplinary links between meteorology,
  hydrology, hazard managers and users
• Forecast dissemination requirements

16
Flood Forecasting and Warning in Bangladesh

• The author gratefully acknowledges Executive
  Engineer, Mr Salim Bhuiyan and his staff at the
  Bangladesh Flood Forecasting and Warning Centre
  for permission to use slides and material from
  their programme

17
Features of flood forecasting in Bangladesh

• Floods happen every year, and are a significant
  feature of national activity
• Flood generating catchments lie 90 outside the
  country
• Time of travel and area inundation models
  (MIKE11/12)
• Rainfall flooding high volume, high intensity
• Radar rainfall and satellite imagery for QPF

18
72 HOURS(11,12,13 August)CUMULATIVE RAINFALL
SURFACE MAP
19
Features of flood forecasting in Bangladesh

• Dhaka local model - detailed monitoring and
  management
• Boundary conditions from main river model
• Sub-daily time steps
• Un-protected areas outside main flood embankment

20
DHAKA CITY EXPERIMENTAL FLOOD MAP
21
Features of flood forecasting in Bangladesh

• Extensive public dissemination
• Reporting network also serves as warning network
  to local authority
• Daily bulletin to high level government
  administration
• Web-site, giving tabular and graphical reports
  (hydrographs)
• Situation and seasonal review reporting

22
ddd

23
The Flood Forecasters dream

• An isohyetal map of total and short period
  accumulations over catchment areas
• A set of limited area hyetographs at short time
  steps
• Accuracy within /- 2-5mm or /- 15?
• A full flood hydrograph
• These match the methods which a hydrologist would
  use in calculating a design flood.

24
HR Wallingford
Knowledge to shape solutions
