Overview of Current Communications Systems

1
Overview of Current Communications Systems
2
Growth of cellular telephone subscribers
throughout the world
1000
100
10
Worldwide subscribers (millions)
1
0.1
1985
1990
1995
2000
3
Second generation (2G) cellular methods
400
300
200
Subscribers Using Technology (millions)
100
0
1st Generation Analog
GSM
IS-136 PDC
IS-95 CDMA
4
2G systems

• Most of todays cellular methods use second
  generation or 2G technologies
• While first generation systems relied on FDMA/FDD
  and only FM, second generation standards use
  digital modulation and TDMA/FDD or CDMA/FDD

5
Most popular systems

• GSM (Global System Mobile)
• IS-136 (NADC) (North American Digital Cellular)
• PDC (Pacific Digital Cellular)
• IS-95 CDMA

6
Key Specifications of leading 2G technologies
7
. . . Key specifications of leading 2G
technologies
8
. . . Key specifications of leading 2G
technologies
9
2.5G Mobile radio networks

• Evolution from 2G ? 2.5G required to support
  increased data rates for modern Internet
  applications.
• 2.5G are new data-centric standard that can be
  overlaid on existing 2G technologies
• 2.5G supports new web browsing format language
  called WAP (Wireless applications Protocol)

10
2.5G Mobile radio networks

• WAP enables standard web pages to be viewed in a
  compressed format ? suitable for small portable
  hand-held wireless devices.
• First developed in Japan by NTT-DoCoMo ? I-mode
  for PDC network - supports games, color graphics
  and interactive web pages using 9.6 kbps
• 25 million Japanese subscribers in 2001

11
2.5G TDMA standards

• HSCSD (High Speed Circuit Switched Data) for
  2.5G GSM
• Allows a single mobile user to use more than one
  specific time slot as in GSM TDMA
• Increases application rate from 9,600 bps (2G
  GSM) to 14,400 bps (2.5G GSM)
• Ideal for streaming internet access or real-time
  interactive web sessions.
• Can be implemented by a software change at
  existing GSM base stations.

12
. . . 2.5G TDMA standards GPRS (General Packet
Radio Service)

• GPRS for 2.5G GSM and IS-136
• Packet based data network suited for non-real
  time internet usage
• E-mail retrieving, faxes and where download ?
  upload
• GPRS can support more users that HSCSD, but in a
  bursty manner.

13
. . . 2.5G TDMA standards EDGE (Enhanced Data
Ration for GSM or Global) for 2.5G GSM and
IS-136

• More advanced upgrade to GSM standard
• Regains additional hardware/software at existing
  base stations
• New digital modulation format (8-PSK/octal PSK)
• Raw data rate of 547.2 kbps possible with 8 GSM
  slots of a GSM channel are allowed for each user.

14
2.5G CDMA standards

• IS-95B for 2.5G CDMA
• Medium data rate (MDR) service with throughput of
  115.2 kbps per user (8 x 14.4 kbps)
• Advanced handoff procedures allows mobiles to
  search different radio channels independently

15
Third generation 3G wireless methods

• Unparalleled wireless access
• Multi Mbps Internet access using VoIP (Voice
  Over Internet Protocol), voice activated calls
• Ability to receive live music, interactive web
  sessions, voice and data access with multiple
  features at the same time, at all times

16
. . . Third generation 3G wireless methods

• ITU (International Telecommunications Union)
  proposed
• A global frequency band in 2000 MHz range
• Single wireless communications standard for all
  countries in the world IMT-2000.
• World community remains split between
  GSM/IS-136/PDC and CDMA
• www.gsmworld.com
• www.edg.org

17
2G - 3G evolution
GSM
IS-136 PDC
IS-95
GPRS
IS-95B
HSCSD
HSCSD
cdma2000-1xRTT
W-CDMA
Cdma2000-1xEV, DV, DO
EDGE
3GPP2
TD-SCDMA
cdma2000-3xRTT
3GPP
18
3G CDMA standards

• 3G W-CDMA (UMTS - Universal Mobile
  Telecommunications System)
• Packet based wireless service which enables
  computers, entertainment devices, telephones to
  connect to internet anytime, anywhere.
• Packet data rates up to 2.048 Mbps per
  stationary user
• Broadcasting, VHE (Virtual Home Entertainment)
  m-commerce (mobile commerce), games, interactive
  video, virtual private technology - all possible
  from small portable wireless device

19
. . . 3G CDMA standards

• 3G cdma2000 or cmda2000 IX
• New high data rate internet access with backward
  compatibility to IS-95 and IS-95B systems - 1.25
  MHz bandwidth
• Instantaneous data rate of 307 kbps in packet
  mode
• Both FDD (mobile radio) and TDD (in-building
  cordless) applications

20
3G TDMA standards

• 3G TD-SCDMA (Time Division Synchronous Code
  Division Multiple Access)
• Developed by CATT (Chinese Academy of
  Telecommunications Technology) and Siemens.
• Adopted by ITU as one of 3G options in 1999
• Existing GSM - 3G evolution through additions of
  high data rate equipment in each GSM station -
  1.6 MHz bandwidth
• Utilizes smart antennas, spatial filtering and
  joint detection technologies

21
Broadband wireless services

• Wireless Local Loop (WLL)
• Demand for broadband internet and computer
  access from businesses and homes
• Fixed wireless equipment have advantages such as
  fixed path between T-R
• Microwave or millimeter radio frequencies used
  gt28GHz - wave length is very small - small high
  gain antennas.
• Especially useful in developing nations with less
  telecommunications setup.

22
Emerging applications and markets for broadband
services
Fiber Large business in high-density urban areas
Central Office
Backbone Network
Wireless Mid-market business outside the urban
core
Central Office
Copper/xDSL Small business
OC-3
Cable Residences
DAX
ISP
23
Broadband wireless spectrum world-wide
24
. . . Broadband wireless services

• Wireless Local Area Networks (WLANS)
• UNII (Unlicensed National Information
  Infrastructure) hand allocated by FCC for low
  power spread spectrum
• 5.150 - 5.35 Ghz, 5.725 - 5.825 GHz (1997)
• 902-928 Mhz, 2400-2483.5Mhz, 5.725-5.825 MHz
  (1980s end)
• IEEE 802.11 (1997) standard and (IEEE 802.11b)
  approved to provide guidelines for WLAN
  manufacturers

25
IEEE 802.11 Wireless LAN
IEEE 802.11
2.4 GHZ
850 TO 950 NM
FHSS
DSSS
Diffuse IR
1 MbpsDBPSK
2 MbpsDQPSK
2 Mbps4GFSK
1 Mbps2GFSK
IEEE 802.11bExtension
11 MbpsDQPSK--CCKBPSK--PBCC
5.5 MbpsDQPSK--CCKBPSK--PBCC
26
IEEE 802.11b Wireless LAN
27
High Performance Radio Local Area Network
(HIPERLAN)

• Europe standard to provide similar capability to
  IEEE 802.11
• 5.2 GHz and 17.1Ghz frequency lands
• Up to 20 Mbps data rate at 50m range and vehicle
  speeds of 35km/hr
• Advanced standards include Europes ETSI-BRAN
  (Broadband Radio Access Network) and HIPERLAN/2.

28
Personal Area Networks

• Ability to replace cables between devices with
  wireless short range connection
• Bluetooth operates in 2.4GHz ISM band
  (2900-2483.5MHz) with 1 MHz channel bandwidth
• Uses FH-SS TDD scheme with 1600 hps
• 1Mbps symbol rate using GSFSk modulation
• IEEE 802.15 sttandards committee is our
  international forum for developing Bluetooth and
  other PANS

29
PAN Bluetooth standard
