HLA Ab, Donor Reactivity and Risk of Rejection
and Graft Loss
Ronald H. Kerman, PhD The University of Texas
Medical School Houston, TX Division of
Immunology and Organ Transplantation
2

• Allograft Rejection

Type Hyperacute Accelerated Acute Chronic
Mediated by Abs Abs/cells Cells/Abs Abs/cells/?
Time 0-48 hrs 5-7 days Early/delayed gt60 days
3
Responsibilities of the Histocompatibility
Laboratory

• To identify clinically relevant recipient IgG HLA
  antibodies

4

• Positive crossmatches, due to Abs or other
  factors not impacting on graft outcome, should
  not influence the donor-recipient pairing for
  transplantation.

5
Detection of Recipient Sensitization

• Screen sera for reactivity vs target cells by
  cytotoxicity/fluorescence readouts.
• Use the most informative sera when performing the
  recipient vs donor crossmatch (historically most
  reactive, current and pretransplant sera).

6
Detection of Immunoglobulin Reactivity

• NIH-CDC
• AHG-CDC
• Flow cytometry
• Membrane-dependent assays

7
Complement-dependent Cytotoxicity NIH Assay
8
Complement-dependent Cytotoxicity NIH Assay
9
Complement-dependent Cytotoxicity NIH Assay
10
Anti-human Globulin (Enhancement) Assay
11
Anti-human Globulin (Enhancement) Assay
12
Anti-human Globulin (Enhancement) Assay
13
Flow Cytometry Assay NIH - CDC Negative AHG
CDC Negative Now measuring binding of IgG
(absent C)
14
Cadaveric Renal Allograft Survival Among 1o
CsA-Pred Recipients at 12 months
NIH Neg. n166 81 (134/166)
AHG Neg. Pos. n151 n15 82 67
(124/151) (10/15)
Plt0.01
Kerman et al, Transplantation 51316, 1991
15
Cadaveric Renal Allograft Survival Among 1o
CsA-Pred Recipients at 12 months
AHG Pos. n15 67 (10/15)
DTE-AHG Neg. Pos. n12 n3 83 0
(10/12) (0/3)
Plt0.01
Kerman et al, Transplantation 51316, 1991
16
Cadaveric Renal Allograft Survival Among 1o
CsA-Pred Recipients at 12 months
DTE/AHG XM Neg. n166 81
FCXM Neg. Pos. n130 n36 81 81

Kerman et al, Transplantation 51316, 1991
17
Neg-NIH Extended XM FCXM Study
T-FCXM Pos. n148 75
T-FCXM Neg. n693 82
Plt0.01
Ogura et al, Transplantation 56294, 1993
18

• Could Ron Kerman have been wrong about his
  crossmatch results and interpretation?

19
IgG FCXM Renal Allograft Study Frequency of
Rejection in a Single Center
Rejection
Kerman et al, Transplantation 681855, 1999
20

• Could Ron Kerman have been wrong about his
  crossmatch results and interpretation?

I dont think so!
21
The Cell Surface Is a Jungle
HLA
22
Membrane-dependent Assays

• NIH-CDC
• AHG-CDC
• Flow cytometry

Detection of membrane receptors may not be
related to HLA!
23
Membrane-independent Assays

• ELISA-determined IgG HLA Abs vs MHC-I (pooled
  platelets)
• ELISA-determined IgG HLA Abs vs MHC-I/II (PBL
  cultures)
• Flow bead PRA-determined IgG HLA vs I/II (soluble
  HLA I/II antigens on microbeads measured by
  cytometry)

24
PRA by Different Methodologies
Type CDC AHG-CDC ELISA Flow
Positive 102 116 127 139
Negative 162 148 137 125
Gebel Bray, Transplantation 691370, 2000
25
AHG-PRA vs Rejection 493 Consecutive CAD
Recipients
AHG-PRA
Rejection YES NO
lt10 134 159
?10 100 100
PNS
26
ELISA-PRA and Rejection
ELISA-PRA
Rejection YES NO
lt10 38 168
?10 117 63
Plt0.001
27
Correlation Between ELISA-PRA and Graft Survival
ELISA-PRA
Graft Survival (months) 12 24 36
lt10 (n312) 85 82 81
gt10 (n181) 74 70 67
Plt0.01
Plt0.01
Plt0.01
28

• Sensitivity and sensitization, defining the
  unsensitized patient
• Application of membrane-independent assays to
  identify HLA antibodies

Gebel Bray, Transplantation 691370, 2000
29
Correlation of Pre-transplant Abs Detected by
Flow PRA with Biopsy-documented Cardiac Rejection
Tambur et al, Transplantation 701055, 2000
30
IgG FCXM Renal Allograft Study Frequency of
Rejection in a Single Center
Were positive crossmatches due to HLA Abs?
Rejection
Kerman et al, Transplantation 681855, 1999
31
Immunosuppressive Menu

• Neoral - CsA
• Steroids
• Prograf - FK506
• Cellcept - MMF
• Rapamycin - Sirolimus
• Thymoglobulin
• OKT3, anti-IL-2R, FTY720

32

• If new immunosuppressive therapies reduce the
  incidence of acute rejection, are pre-Tx HLA
  antibodies clinically relevant?

33

• RAPA-CsA-Pred treated primary recipients of CAD
  renal allografts experience fewer acute
  rejections vs CsA-Pred recipients.
• We therefore tested their pre-Tx sera for the
  presence of HLA Abs and correlated the results to
  the occurrence of rejection during the first 12
  months post-transplant.

34

• 147 RAPA-CsA-Pred recipients were studied
• 48 patients were chosen specifically
  because they had a
  rejection episode.
• 99 patients were chosen because they had not
  experienced a rejection episode during the first
  year post-transplant.

35

• PRA Testing
• Anti-human globulin (AHG)
• ELISA (One Lambda, Inc. LAT)
• Flow PRA (One Lambda, Inc.)

36
Results

• AHG-PRA detected 18 reactive sera
• ELISA-PRA detected 25 reactive sera (11 vs HLA
  class I, 3 vs II, 11 vs I/II)
• Flow PRA detected 59 reactive sera (31 vs HLA
  class I, 9 vs II, 19 vs I/II)

37

• There was no significant correlation between
  AHG-PRA, ELISA-detected HLA Abs, and Flow PRA HLA
  class II Abs and rejection.

• AHG vs Rejection PNS
• LAT-I vs Rejection PNS
• LAT-II vs Rejection PNS
• LAT-I/II vs Rejection PNS
• F-II vs Rejection PNS

38
Flow PRA-1
Rejection NO YES
lt5 76 21
?5 23 27
X215.7 Plt0.001
39
Day of 1st Rejection 57 34
Flow PRA 0
FCXM Pos. Neg. 2 8
No grafts lost () FCXM vs non-HLA Ab
40
Day of 1st Rejection 55 31
Flow PRA 13 9
FCXM Pos. Neg. - 30
No grafts lost.
41
Day of 1st Rejection 32 15
Flow PRA 28 9
FCXM Pos. Neg. 12 13
() HLA Ab and (-) FCXM rejection, no grafts
lost. () HLA Ab and () FCXM rejection, 58
(7/12) grafts lost.
42
Day of 1st Rejection 17 12
Flow PRA 48 31
FCXM Pos. Neg. 8 7
() HLA Ab and (-) FCXM rejection, no grafts
lost. () HLA Ab and () FCXM rejection, 63
(5/8) lost to AMR.
43
Day of Rejection 57 34 55 31 32 9 17
12
PRA 0 13 9 28 9 48 31
Rejection 5 (4/75) 13 (4/32) 100 100
N 75 32 25 15
44
1. Assays that measure binding of
immunoglobulin to targets may not
represent HLA Ab reactivity. 2. The AHG-XM
protects RAPA-CsA-Pred recipients from
hyperacute rejection. 3. The Flow PRA assay
detects clinically relevant HLA Abs
associated with rejection and/or graft loss.
45
4. How many antibodies are present may be
clinically relevant. 5. The antibody titer may
also be important. 6. Patients with pre-Tx ()
HLA Abs and () donor reactivity ( FCXM)
are at risk for graft rejection and loss.
46
We have performed heart transplantation following
a negative AHG-XM. We evaluated the clinical
relevance of FCXM for heart recipients.
47
FCXM Results Heart Recipient
IgG FCXM Neg. 1YGS 86
IgG FCXM Pos. 68
Plt0.02
Of the 22 IgG FCXM-Pos. Recipients 7 grafts
were lost 15 grafts were successful WHY?
48
We Flow PRA Tested the IgG FCXM-Pos. Sera

• 5 sera tested from lost grafts
• All 5 sera were Flow PRA reactive vs MHC I
  (Flow PRAs of 36, 52, 68, 50 and 49)
• 11 sera tested from successful recipients
• All 11 sera were Flow PRA non-reactive

49
FCXM () Flow PRA I/II ?51 55 (5/9)
FCXM (-) Flow PRA I/II ?51 100 (13/13)
Graft Survival 12 mo.
89 (8/9)
31 (4/13)
Rejection 0-12 mo.
Both comparisons plt0.01
50
HLA Ab and Donor Specific Reactivity Rank Order
of Risk
1. HLA Ab negative, FCXM negative (at risk
for reversible, cellular rejection) 2. HLA Ab
negative, FCXM positive (non-HLA allo-Ab -
at risk for reversible, cellular
rejection)
51
HLA Ab and Donor Specific Reactivity Rank Order
of Risk
3. HLA Ab positive, FCXM negative (at risk
for reversible, cellular,
/- HLA Ab, rejection) 4. HLA Ab positive, FCXM
positive (at risk for humoral/cellular
rejection and graft loss)
52
To transplant or not to transplant, that is the
question! Whether it is nobler in the minds of
transplant surgeons to treat with thymoglobulin,
OKT3, Plasmapheresis, IVIg, or the
kitchen sink!
53
Applications
1. Pre-transplant identification of
immunologically high risk patients.
Consideration of induction and/or
maintenance immunosuppression. 2. Clarify the
role of HLA antibody in rejection episodes
(including the role of C4d ).
54
Applications
3. Transplantation of highly sensitized and/or
positive crossmatch recipients. 4. Long
term monitoring of the presence
of HLA antibody and graft outcome.
55

• I have never let my schooling interfere with my
  education.
• -Mark Twain
