Physics 212 Lecture 23, Slide 1

1
Physics 212 Lecture 23
2
Music

• Who is the Artist?
• Sarah Vaughn
• Billie Holiday
• Dinah Washington
• Nina Simone
• Ella Fitzgerald

Why? Some time back you picked her when I
played Chet Baker. I promised Id play her some
day and here it is. A true
classic.. dramatic, defiant, and
uncategorizable Important figure in the 60s
If you havent heard her before, you really
should
3
(No Transcript)
4
Things you identified as difficult
I'm having a lot of trouble with circular
polarization. What does any of this achieve?
Polarizing radiation, what does that accomplish?
I thought finding the intensity and knowing if
it is right or left polarized was confusing.
What are the answers to the next test?
5
More Physics Haiku
Exams, Homework, Labs Quizzes, Lectures, and
Preflights My brain is on fire
Begin the machine Double E's love of
circuits Life integrated
6
So far we have considered plane waves that look
like this
7
(No Transcript)
8
This rotation does not change the intensity
9
Polarizers
The molecular structure of a polarizer causes the
component of the E field perpendicular to the
Transmission Axis to be absorbed.
10
(No Transcript)
11
(No Transcript)
12
There is no reason that f has to be the same for
Ex and Ey
Making fx different from fy causes circular or
elliptical polarization
13
Right Handed Circular Polarization
This modification does notchange the intensity
either
14
Q How do we change the relative phase between
Ex and Ey? A Birefringence
This changes linear to circular polarization
and is called a quarter wave plate
15
Q What happens when circularlypolarized light
is put through apolarizer along the x (or y)
axis ?
A You kill either Ey (or Ex), so you loose half
the intensity!
X
16
Q What happens when circularly polarized light
is put through apolarizer along some arbitrary
axis in the x-y plane?
A Same thing - you loose half the intensity!
17
Executive Summary
18
1) An EM wave is passed through a linear
polarizer. The component of the E-field
which is absorbed is A) perpendicular to the
transmission axis B) parallel to the
transmission axis C) both components are
absorbed
19
3)  An EM wave polarized along the y-axis, is
incident on two orthogonal polarizers. .
What percentage of the intensity gets
through both polarizers? A) 50 B) 25 C) 0
20
A quarter wave plate does not change the intensity
21
A quarter wave plate changes linearlypolarized
light into circularly polarized light
22
Calculation
Light is incident on two linear polarizers and a
quarter wave plate (QWP) as shown. What is the
intensity I3 in terms of I1?
fast
45o
y
x
slow
60o
I1
I2
z
I3

• Conceptual Analysis
• Linear Polarizers absorbs E field component
  perpendicular to TA
• Quarter Wave Plates Shifts phase of E field
  components in fast-slow directions
• Strategic Analysis
• Determine state of polarization and intensity
  reduction after each object
• Multiply individual intensity reductions to get
  final reduction.

23
Calculation
Light is incident on two linear polarizers and a
quarter wave plate (QWP) as shown. What is the
intensity I3 in terms of I1?
fast
45o
y
x
slow
60o
I1
I2
z
I3
24
Calculation
Light is incident on two linear polarizers and a
quarter wave plate (QWP) as shown. What is the
intensity I3 in terms of I1?
fast
45o
y
RCP
E
x
slow
Ex
Ey
60o
I1
l/4
I2
z
I3

• What is the intensity I2 of the light after the
  QWP?

(A) I1 (B) ½
I1 (C) ¼ I1
AFTER
No absorption Just a phase change !
Intensity lt E2 gt
25
Calculation
Light is incident on two linear polarizers and a
quarter wave plate (QWP) as shown. What is the
intensity I3 in terms of I1?
fast
45o
y
RCP
E
x
slow
Ex
Ey
60o
I1
l/4
I2 I1
z
I3
BEFORE
AFTER
Intensity lt E2 gt
26
Calculation
Light is incident on two linear polarizers and a
quarter wave plate (QWP) as shown. What is the
intensity I3 in terms of I1?
fast
45o
y
RCP
E
x
slow
Ex
Ey
60o
I1
l/4
I2 I1
z
I3
Absorption only passes components of E parallel
to TA (q 60o)
27
Calculation
Light is incident on two linear polarizers and a
quarter wave plate (QWP) as shown. What is the
intensity I3 in terms of I1?
fast
45o
y
RCP
E
x
slow
Ex
Ey
60o
E3
I1
l/4
I2 I1
z

• What is the intensity I3 of the light after the
  60o polarizer?

(A) I1 (B) ½
I1 (C) ¼ I1
Ey
E3
3
NOTE Does not depend on q !!
60o
Ex
28
Follow Up 1
Replace the 60o polarizer with another QWP as
shown.
fast
45o
y
slow
RCP
E
x
slow
Ex
Ey
fast
I1
l/4
I2 I1
I3
z
Easiest way Efast is l/4 ahead of Eslow
29
Follow Up 2
Replace the 60o polarizer with another QWP as
shown.
fast
45o
y
slow
RCP
E
x
slow
Ex
Ey
E3
fast
I1
Ex
Ey
l/4
I2 I1
z

• What is the intensity I3 of the light after the
  last QWP?

(A) I1 (B) ½
I1 (C) ¼ I1
AFTER
No absorption Just a phase change !
Intensity lt E2 gt
