Products Overview

1
Products Overview

• FSS-103

2
Agenda

• Common receiver types.
• Basic, DVR, HD, ViP, Dual-tuner Multi-room,
  Dual-tuner Single-room.
• LNBF types.
• Single, Dual, Twin, Quad
• Switch types.
• 21, 34, 44, 64

3
Vocabulary Bingo

• Listen for one of your words
• Mark it on your sheet.
• When you get a full row vertically, horizontally,
  or diagonally. Yell BINGO.
• Smile and be happy.

4
Receiver Types
5
Basic Receiver

• The following are examples of basic receivers
  111, 301, and 311.

6
Digital Video Recorder (DVR) Receiver

• DVR receivers include the 501, 508, 510, 522,
  625, 721, 921, and 942 model receivers.

7
High Definition Receiver

• 411, 811, 921, and 942 are examples of HD
  receivers.

8
ViP Receiver

• The ViP211 is the first.
• Receives both Standard and High definition.

9
Dual-tuner Multi-room Receiver

• Dual-tuner Multi-room receiver models are the
  322, 522, 625, and 942

10
Dual-tuner Single-room Receiver

• Dual-tuner Single-room receiver models are the
  721, and 921.

11
Low Noise Blocking Feedhorn (LNBF) Types

• Single LNBF
• Dual LNBF
• Twin LNBF
• Quad LNBF

12
Single LNBF

• One orbital location to one receiver.
• Generally used for International programming or
  other programming on the 148 or 61.5 locations.

13
Dual LNBF

• One orbital location to up to two receivers.
• Generally used for International programming or
  other programming on the 148 or 61.5 locations.

14
Twin LNBF

• Receives two orbital locations spaced 9 apart.
  It is typically used for the 119 and 110
  orbital slots.
• Built-in switch to allow for switching between
  the 119 and 110 orbital slots.

15
Quad LNBF

• Receives two orbital locations spaced 9 apart.
  It is typically used for the 119 and 110
  orbital slots.
• Built-in switch to allow for switching between
  the 119 and 110 orbital slots.

16
Switch Types

• 21 Two inputs and one output.
• 34 Three inputs and four outputs.
• 44 Four inputs and four outputs.
• 64 Six inputs and four outputs.

17
DISHPro vs. Legacy

• DISHPro - Equipment with new technology to help
  reduce cabling.
• Legacy - Older DISH Network Equipment.

18
DISHPro 21 Switch

• Connects two LNBFs to one receiver
• May be connected to DISHPro Single, Dual, Twin,
  or Quad LNBFs
• A.K.A. DP21

19
Legacy 21 Switch

• Connects two LNBFs to one receiver
• May be connected to Legacy Single, Dual, Twin, or
  Quad LNBFs
• A.K.A. SW21

20
DISHPro 34 Switch

• Connects up to 4 tuners to up to 3 Orbital
  locations
• May be connected to DISHPro Single, Dual, Twin,
  or Quad LNBFs
• May be trunked to additional 34 switches for more
  tuners
• A.K.A. DP34

21
DISHPro Plus 44 Switch

• Connects up to 4 tuners to up to 4 orbital
  locations
• May be connected to DISHPro Single, Dual, Twin,
  or Quad LNBFs
• May be trunked to additional 44 switches for more
  tuners
• Requires a power inserter
• A.K.A. DPP44

22
Legacy 44 Switch

• Connects up to 4 tuners to up to 2 orbital
  locations
• Needs two cables from LNBF to switch for each
  orbital location.
• May be connected to Legacy Dual or Legacy Quad
  LNBFs
• Requires a power inserter
• A.K.A. SW44

23
Legacy 64 Switch

• Connects up to 4 tuners to up to 3 orbital
  locations
• Needs two cables from LNBF to switch for each
  orbital location.
• May be connected to Legacy Dual or Legacy Quad
  LNBFs
• Requires a power inserter
• A.K.A. SW64

24
Knowledge Check

• Which two LNBF types can receive signals from two
  orbital locations approximately 9 apart?
• Single LNBF
• Dual LNBF
• Twin LNBF
• Quad LNBF

25
Knowledge Check

• Which receiver type allows you to record, pause,
  rewind, and fast forward live TV?
• Dual-tuner
• High Definition
• DVR
• ViP

26
Knowledge Check

• Which switches require the use of a power
  inserter?
• 21
• 44
• 34
• 64

27
Summary

• Common receiver types.
• Basic, DVR, HD, ViP, Dual-tuner Multi-room,
  Dual-tuner Single-room.
• LNBF types.
• Single, Dual, Twin, Quad
• Switch types.
• 21, 34, 44, 44
