GNSS Test for Automotive Industry and beyond

1
GNSS TestforAutomotive Industryand beyond

• darren.fisher_at_spirent.com

2
Spirents Unique Position within the GNSS
Community

• Worlds Leading GPS/GNSS Test Solution Provider
• 23 year legacy of design effort as Global Leaders
  in the GPS Simulation field
• Worlds only commercial GLONASS Simulator
• Delivered Galileo Simulators as ESA Supplier of
  choice to all official Galileo development
  programs.

3
A Few Spirent Customers
4
GPS is simple isnt it?

• Q. Can I buy a GPS chip and expect it to just
  work in my device?
• A. Yes, but.
• Need to test in your device, with tests and
  specifications designed for your application.
• GPS test is needed at every stage of design and
  manufacture process.
• Traceability important for your suppliers and
  customers.
• Cost of failure is high.
• There is a lot to consider when developing a GPS
  device

5
Expansion of key signals

• 2007
• GPS L1 C/A and P
• GPS L2 P
• GLONASS L1
• WAAS

• 2012
• GPS L1 C/A, P, C
• GPS L2 C, P
• GPS L5
• GLONASS L1, L2
• Galileo L1, E5ab, E6
• Open Service
• Commercial Service
• Safety of Life
• Public Regulated Service
• Compass
• QZSS
• EGNOS
• WAAS
• MSAS

• Augmentation
• IVNS
• Inertial Sensors
• A-GPS
• LAAS
• Pseudolite
• WiFi triangulation
• Wireless Basestation Triangulation
• DGPS

6
In Vehicle NavigationSystems (IVNS)
7
IVNS Applications
Many services and Users require high accuracy,
rapid first fix and guaranteed position despite
tunnels and urban canyons to unlock demand.

• Route planning
• Congestion avoidance
• Traffic flow management
• Theft Recovery
• Local service finder
• Automatic Vehicle Location
• Road User Charging
• Speed limiter
• Emission control
• Fleet Management
• Advanced Driver Assistance Systems (ADAS)
• Pay as you drive Insurance
• Insurance premiums set by driving style

8
Automotive Industry

• Demanding User
• 100 availability
• High accuracy
• Fast Fix
• Poor availability, difficulty to re-acquire
• Inaccuracies of several hundred metres common in
  severe environments
• Potentially poor continuity
• Multipath problems
• Choice of Handheld PND or Integrated devices
  available

9
In Vehicle Navigation System

• Hybrid systems combine the great accuracy of GPS
  with the dependability of low cost DR sensors.

E
S
Continuous position data from sensors allows
system to paint through gaps in GPS coverage
Constant position updates via GPS enables the
calibration of low cost Dead Reckoning sensors
10
IVNS Testing Challenges

• Synchronised generation of all sensor outputs
• RF signal corruption consistent with chosen
  environment
• Repeatable, controllable, meaningful, accurate
• Vehicle motion model which adequately matches
  target vehicle dynamics
• Availability of accurate truth data

11
IVNS Test Parameters

• Typical Parametric Figures of Merit
• Sensitivity Ability to reliably track low-power
  signals
• Carrier-to-Noise ratio A measure of how well
  the receiver has correlated with the coded signal
• Dynamic tracking Ability to maintain signal
  tracking as the users platform rapidly moves or
  changes orientation
• Time-to-First-Fix (TTFF) How long after a cold
  or warm start does it take to obtain the first
  position solution?
• Re-acquisition time (REAC) How long does it
  take the receiver to track a signal again after
  the signal has been obscured for a given
  period?
• Accuracy Compared to truth in ideal conditions

12
How can I answer these questions

• A development tool that
• Provides all available SIS and Augmentation
  services
• Lacks ambiguity
• Gives me a High degree of control
• Has Inherent repeatability to see my improvements
  perform
• Great flexibility to allow for global testing
• Allows me to stress my product/application in a
  controlled environment where I can put the errors
  in
• Allows me to be fully aware of the complete test
  environment, and control it.

13
My own Satellite Navigation System
Your GNSS system, under your control, for your
specifics test needs
14
Why Simulate?

• If a fully operational constellation exists
  (GPS/GLONASS)
• You have no control over it
• It is always changing
• There are many, unknown errors
• It is never repeatable
• Atmospheric conditions change
• Satellite orbits change
• High cost of field test
• Or if no constellation exists (Galileo)
• A lack of real signals prevents testing
• Evaluation limited to software modelling only
• No confidence in the system performance of a
  receiver
• No way of conducting dynamic testing

15
Application Areas

• Civil Aviation
• Commercial Aviation, light aircraft
• Space
• LEO (space station, shuttle), GEO (Satellite TV,
  WAAS, Communications), HEO, polar (Experimental,
  deployment)
• Military
• Aircraft, munitions, missiles, vehicles, marine,
  communications
• Marine
• Warships, tankers, collision avoidance, pleasure
  craft, port entry
• Land
• Automotive, Rail, Agriculture, Wireless and LBS,
  Personal devices, Survey, Public
  Safety/Certification

16
Summary - Benefits of Simulation

• Repeatable, Controlled testing environment
• Lower costs compared to numerous field tests
• Test beyond real world conditions
• Reduced time to market
• Prove system to your customers
• Evaluate your Suppliers

17
Multi-system, Multi-frequency, Multi-service
receiver development

• Increasing requirements for gt1 GNSS test
  configurations
• GPS/Galileo
• GPS/GLONASS
• GPS/Galileo/GLONASS
• QZSS, SBAS, GRAS, LAAS, Inertial
• High sensitivity requirements
• Interference effects

Spirent Simulators are now commercially
available for all combinations of Systems,
Frequencies, Services and Augmentation
GSS7900 GPS/Galileo Simulator
18
Please visit our Stand in the Exhibition
Halldarren.fisher_at_spirent.com
