Title: IIR IP Multicast


1
(No Transcript)
2
IP Multicast Peering
  • Karl Jeacle
  • kj_at_eircom.net

3
Overview
  • Overview of multicast peering points
  • What, where, who, how?
  • Equipment associated costs
  • Protocol interaction (PIM/MSDP/MBGP)
  • Multicast peering policies
  • Operational best common practice

4
What is a peering point?
  • Peering definition
  • Peering is the arrangement of traffic exchange
    between Internet Service Providers, at public
    exchange points, with zero sum financial
    settlement
  • Note
  • Public exchange points, not private connection
  • Zero sum settlement, no transit charges
  • Multicast and unicast traffic exchanged

5
European exchanges
  • DECIX Frankfurt, Germany
  • INXS Munich, Germany
  • AMSIX Amsterdam, Netherlands
  • NDIX Enschede, Netherlands
  • NETNOD Stockholm, Sweden
  • LINX London, UK
  • LoNAP London, UK
  • MaNAP Manchester, UK
  • XchangePoint - London, UK
  • VIX Vienna, Austria
  • BNIX Brussels, Belgium
  • SFINX Paris, France
  • GIGAPIX Lisbon, Portugal
  • CATNIX Barcelona, Spain
  • SIX Bratislava, Slovakia
  • CIXP Geneva, Switzerland

6
Future exchange trials
  • Most exchanges planning trials in 2003
  • INEX Dublin, Ireland
  • MIXITA Milan, Italy
  • NIX Oslo, Norway
  • SWISSIX - Zurich, Switzerland

7
Who can join?
  • Varies across exchange points
  • Network criteria must be met
  • Typically ISPs only
  • Sometimes content providers
  • Rarely end-users
  • Depends on MoU and TC

8
Exchange equipment
  • Desire to isolate multicast traffic from existing
    production unicast traffic
  • Separate switch used
  • Dedicated connection to multicast switch port
  • LINX Extreme Summit 48
  • Separate VLAN on same switch
  • Dedicated connection to port in multicast VLAN
  • AMSIX Foundry BigIron 8000 15000

9
Exchange equipment
  • Some exchanges do not require an additional
    network connection
  • e.g. FICIX, NETNOD, SIX
  • OK if point-to-point (e.g. ATM)
  • Concern if shared access (e.g. Ethernet)
  • Multicast traffic looks like broadcast traffic
  • Switch will send data out on all ports
  • Bearable if multicast only, unacceptable if
    unicast
  • PIM Snooping or equivalent required

10
PIM Snooping
  • Hosts connected to a switch
  • IGMP snooping prevents unwanted traffic
  • Routers connected to a switch
  • PIM used instead of IGMP
  • Switches do not see PIM messages
  • Traffic will be flooded on all ports
  • Solution
  • Enable PIM snooping on switches so they can
    restrict multicast traffic flows to interested
    parties

11
RGMP
  • Cisco provide RGMP
  • RouterPort Group Management Protocol
  • Proprietary, but submitted as IETF draft
  • Message format resembles IGMP to allow easier
    upgrade of existing switches
  • Unlike PIM Snooping, all devices (i.e. switch and
    routers) must run RGMP

12
Member costs
  • Present for unicast peering already
  • New router is unnecessary
  • Extra port on existing router sufficient
  • Additional rental for multicast port
  • Software upgrades may be required
  • Main cost
  • Staff competence development
  • Depends on commitment to multicast

13
Steps involved
  • Peering agreements
  • Are multicast unicast peers equivalent?
  • Is a (new) peering agreement necessary?
  • Session configuration
  • MBGP / MSDP / PIM-SM
  • RIPE database
  • No specific multicast route entries

14
Protocols required
  • Protocols required for multicast peering
  • MBGP
  • Exchange unicast routes to multicast sources
  • MSDP
  • Exchange Source Active messages (SAs)
  • PIM-SM
  • Allows branches of multicast distribution tree to
    be built between peers across the exchange

15
MBGP
  • Multiprotocol Border Gateway Protocol
  • Not Multicast BGP
  • Multiprotocol extensions allow IPv6 MPLS VPNs
  • MBGP exchanges unicast prefixes of multicast
    hosts, it does not exchange group addresses!
  • MBGP multicast rationale
  • Incongruent routing between unicast multicast
  • Force multicast traffic to take alternative path

16
Incongruent routes
17
MBGP Policies
  • Peering policy
  • Unicast peering has AS path prefix filters
  • Re-use depending on administrative policy
  • Can re-announce other peers prefixes a sort of
    pseudo-transit for multicast
  • Always agree first with peers concerned!

18
MSDP
  • Multicast Source Discovery Protocol
  • Connects PIM-SM domains
  • Allows multicast sources for a group to be known
    across different domains
  • Peers exchange multicast Source Active messages
    (MSDP SAs)
  • SAs carried to PIM Rendezvous Points

19
PIM-SM
  • PIM Sparse Mode
  • Allow PIM neighbours to be established
  • Branches of multicast distribution tree are built
    between peers across the exchange
  • Enable on exchange-facing interface
  • Ideally run natively back to core of network
  • Or tunnel back to multicast-enabled network

20
Best Common Practice
  • Keep local traffic local!
  • Filter traffic SAs with ACLs
  • Private source addresses
  • Private group destination addresses
  • SSM 232/8 space
  • PIM BSR and/or Auto-RP
  • Misc services (e.g. discovery protocols)

21
How active?
  • Participants
  • Usually numerous interested members
  • but typically just 10-20 get up running
  • Traffic
  • Small percentage of unicast ( 1)
  • Efficiency its multicast! ?
  • Lack of content ?

22
Evangelism!
  • If you are an ISP
  • Investigate multicast peering options
  • Start work on enabling native multicast
  • If you are an ISP customer
  • Ask your provider for multicast service
  • Ask them for details on peering presence

23
More information
  • Exchange points
  • http//www.ep.net/
  • http//www.euro-ix.net/ispportal/ixpmatrix.htm
  • BCP ACLs
  • ftp//ftpeng.cisco.com/ipmulticast/config-notes/ms
    dp-sa-filter.txt
  • Sample config
  • http//multicast.eircom.net/

24
Thank you! Questions?
