NINJA

1
NINJA
2
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Project
of UC Berkeley Computer Science Division Paper
The Ninja Architecture for Robust
Internet-Scale Systems and Services

http//ninja.cs.berkeley.edu/
People Eric Brewer ,David Culler, Anthony
Joseph , Randy Katz ,Steven
Gribble, Matt Welsh
3
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices

• Points to be covered
• Goal The end goal of the Ninja project is to
  enable the
• development of a menagerie of Internet-based
  services
• which are interoperable and immediately
  accessible
• across the spectrum of user devices ranging from
  PCs
• and workstations to cellphones and Personal
  Digital
• Assistants.
• Examples of Applications of Ninja Vision
• Sanctio
• Juke Box

4
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
5

The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices

• Components of Ninja Architecture
• Building Robust services
• Scalability
  Availability
• Fault-Tolerance
  Consistency
• Persistence
• All this in under the Growing Traffic Load
• Concept of Base Cluster of Workstations
• Concept of vSpace Cluster based software
  Platform

6

The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices

• Device Diversity Concept of Units
• Adaptation by Active proxies Concept of
  Distillation
• Computational power
• Network Connectivity
• Interface Capabilities of
  devices
• e.g. Wireless Base stations, Network gateways ,
• Firewalls , Gateways .
• 4) The Composition of Services Composition of
  services into a PATH as well as adaptation along
  that PATH.
• SDS (Service Discovery
  Service )

7
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Bases Scalable Platforms for internet Services
Concept of Conditioning the Service Graceful
operation during the bursts A
programming Model Splitting
a Service into Stages e.g. web server
service reading retrieving return
Design Patterns
1.Wrap 2. Combine
3. Pipeline 4. Replicate Java Based
I/O Substrate Implementation Jaguar (Java
Access to generic Underlying Architectural
Resources ) Extension to the
Java Environment
8
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
vSpace Cluster based execution environment for
Replication
Load balancing Fault Tolerance
Concept of Worker fixed
size thread pool methods
Service definition set of workers
Service Publication freezing of the code
Clone replication of the workers
along various other
nodes Clone Group set of
worker clones
9
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Distributed Data Structures Normal D.S.
Like Binary tree, Hash Table etc. Properties
Expected High
throughput High Concurrency
Availability Strictly Consistent
in Nature Atomic in Nature
10
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Active proxies Execute in an environment local
to devices and hence perform context aware
optimizations and transformations on behalf of
devices 1)Dynamic Service Adaptation
Distillation of service content into a
format more suitable for small devices eg. 1)
HTML to WML for WAP phones
2)Design of the light weight protocols 2) Secure
Service Access from Diverse Clients trusted
active proxies can perform context aware
transformations on data before it arrives at a
kiosk 3) Multiple device fusion Combining
capabilities of various devices .Eg. Display
of local kiosk and entering data thru PDA
11
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Paths Composition of Services Across the
Wide-Area 1)Automatic Path Creation (APC )
Finding path between the networks
Creating the network connection
Fine Tuning the performance of data
flow Error Correction 2) Path
Operators (perform computation on data)
Connectors (protocol translations between
operators ) 3) Operators
Strongly types and know the input they
accept and output they produce .
12
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Operators have Cost parameters associated with
it which helps in route optimization .
Types of Operators Long
lived - standard Ninja services
Dynamically generated light weight and
short lived transformation
elements created by the
APC facility as and when required Both these
types of the operators ensure that that the path
can be reconstructed when A failure occurs .
Example of Path Mapquest Service
13
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
14
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Service Location Service across the Wide Area
(SDS) Services announce their
presence Location of the
announced services help clients
decide the trustworthiness of the
service and vice a versa . Properties of the
SDS Fully secure
Semantically rich
Scalable Fault Tolerant
15
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Design of Service Discovery Service 1)
Elements of the SLS Clients
Services SDS servers. 2)
Hierarchical arrangement of servers Domain
concept 3) Uses of XML for encoding both services
and queries 4) Certificate Authority (CA)
trusted source which provide the proof of
binding between a principal and its public
and Private keys in the form of certificates
. 5) Capability Manager (CM) Manages individual
access control Lists on behalf of each
authenticated service . Hiding the services
rather than disallowing the access
16
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices
Wide Area Operation in SDS Information is
propagated up to parent servers and queries
are partitioned among and forwarded to the
relevant servers. To prevent upper level
servers in the hierarchy from being loaded by
the query load SDS filters the information
while it propagates the information forward
. SDS servers dynamically organize themselves
into potentially multiple hierarchies for
data partitioning and query routing.
17
The Ninja Project Enabling
Internet-scale Services from Arbitrarily Small
Devices

• Ninja and Related Work Ninja is not Java
• 1) Jini 2) EJB
• 3) CORBA 4) Centaurus
• 5) Active networks
• Future Work in Ninja
• Challenges in automatically composing service
• components to meet the needs of particular
  device
• 2) Unsolicited advertising SPAM
• 3) Requirement of Services capturing bits rather
  than
• eyeballs
