ISO New EnglandsWinter 2005/2006 Assessment
Action PlanPreparing for Cold Weather
Reliability

• October 6, 2005

2
Needs Assessment
3
New England Faces a Potential Shortfallin
Electricity Supply this Winter

• ISO-NE believes that there is a significant risk
  that there will be insufficient availability from
  gas-fired generating units to meet peak
  electrical demands this winter
• A shortfall in gas-only generating unit
  availability would be a system-wide resource
  issue as opposed to a specific load pocket issue

• ISO-NE is proposing a number of remedial action
  to reduce this risk

4
January 2004 Cold Snap Experience

• During the January 2004 Cold Snap, all of the
  natural gas pipelines firm customers were served
  in accordance with their tariffs

• 9,000 MW of generation was out-of-service in
  New England

• 7,200 MW of this capacity consisted of gas-only
  units that were unavailable due to fuel and
  weather related outages/reductions

• The damage to the gas and oil production
  infrastructure inflicted by the recent Gulf
  hurricanes poses an increased risk to the
  availability of gas-fired generation this winter
• 25 of New Englands peak-day natural gas comes
  from Gulf sources

5
Cold Snap Process Improvements

• Since 2004, ISO New England has implemented a
  number of process improvements that should
  improve the availability of New England
  generation
• Increased Coordination
• Gas/Electric Operations Committee
• Day Ahead Market timing
• Improved Availability
• Timely switching to alternate fuels
• Improved winterization of generating units
• Additional dual fuel units

6
Summary of Problem Issues

• New England is subject to great uncertainty/high
  risks in the price, availability and
  deliverability of natural gas during Winter 05/06
  due to the impacts of Hurricanes Katrina and
  Rita
• The regional gas pipelines have indicated they
  are well prepared to serve firm customers

• New England LDC storage is on track
• Because the majority of the New England
  generation sector does not have firm gas
  entitlements, it is exposed to high risk because
  of limitations on both gas supply and
  transportation

7
Summary of Problem Issues (cont.)

• Generators have the choice to use gas to generate
  electricity or sell gas back into the market
  based on economics

• LDCs have an obligation to serve firm customers
• Recent experience during periods of volatile gas
  prices shows that generators have limited
  incentives under the current market rules to turn
  gas into electricity during the most critical
  winter periods
• The major planned market enhancements that will
  address this problem will not be in place for
  this winter


8
(No Transcript)
9
(No Transcript)
10
What are the Contingency Concerns?

• Increased quantities of gas-only generation are
  likely to be out of service during a Cold Snap
  period

• Forecast peak electricity demand for Winter 05/06
  is about 1,000 MW greater than January 2004
  actual Cold Snap peak

• Multiple Cold Snap events would exacerbate supply
  and price issues for New England generators

• Ability to withstand the loss of a major
  generating unit during a Cold Snap event without
  invoking load shedding may be at risk

11
Risk Analysis

• The following charts depict the risk exposure New
  England has to unit availability and electricity
  supply shortages during this winter based on a
  range of potential impacts
• Total gas pipeline import capability is 3.5
  Bcf/d

• Based on firm pipeline transportation contracts
• 3.0 Bcf/d to the LDCs and other end users
• 0.5 Bcf/d to the electric generators
• Based on the above entitlements, a maximum of
  3,000 MW of gas-only units can be supported from
  pipeline deliveries during a Cold Snap event (See
  Bar 1 of Supply Scenarios Chart)
• This is approximately equal to what was available
  during the January 2004 Cold Snap

• It is assumed that Mystic generation will be
  available because it has a separate supply source
  (i.e. LNG)

12
Risk Analysis

• The other supply scenarios depicted in the chart
  describe the hypothetical reduction in gas supply
  to 90 of pipeline capability and its impacts on
  LDC and power generation availability
• Bar 2 assumes a pro-rata share of supply to the
  LDC and generation sectors

• Bar 3 assumes a market response where the LDC
  acquires the requisite volumes of gas to fulfill
  their obligations

• The last scenario shown in the Operable Capacity
  Analysis depicts the New England power supply
  situation if all gas-fired generation (except for
  Mystic) becomes unavailable, which could happen
  if there is an extreme gas shortfall or gas price
  instability

13
Supply Scenarios
14
Winter Peak Operable Capacity Analysis
Includes 900 MW of ICAP Sales to NY
(currently 640 MW scheduled) Assumes only 3
,000 MW of the 8,700 MW of gas-only generation
has firm pipeline transportation contracts
Includes increase in 90/10 peak load due to
increase in electric heating load (400 MW)
15
Contingency Plans
16
ISO-NE Contingency Plan Summary
17
Actions Needed to Protect Reliability for Winter
2005/06

• Communications/Conservation
• Reduce consumption in all hours to conserve fuel
• Secure Additional Dual Fuel Capability
• Via change to MR1
• Demand Side Management/Load Management
• Expand DSM programs in New England
• Add capacity resources to help maintain 30-minute
  reserves

• Develop/Implement Energy Emergency Procedures
• Cold Weather Event Operations (Appendix H)
• Expand Actions During a Capacity Deficiency
  (OP4)

• Develop new operating procedure and/or change to
  MR1 for multi-period energy shortfall conditions

18
Upcoming Dates

• We propose the following dates for working on the
  Contingency Plan

• Thursday, October 13 joint Markets/Reliability
  Committee meeting (Marlboro)

• Materials to go out on Friday, October 7
• Friday, October 14 NPC meeting (Boston)
• Wednesday, October 19 joint Markets/Reliability
  Committee meeting (Marlboro)

• Materials to go out on Monday, October 16, or
  sooner if possible

• Friday, October 21 Special NPC meeting
  (teleconference)

• Friday, October 28 Target date for FERC filings
