InterScan AppletTrap
Zhang Hong
Trend Micro, AppletTrap Team 2001.09.18 (Nanjing)
2
Wheres AppletTrap

• Trend Micro InterScan AppletTrap is a
  policy-based, centrally-managed enterprise
  solution at the Internet gateway that monitors
  the behavior of malicious applets, ActiveX,
  JavaScript and VBScript.

3
The competitors

• SurfinShield Client solution. Replace Java
  library in browsers
• administration issue(deploy, upgrade)
• SurfinGate Server Solution. Static parsing at
  server.
• Heavy load on server

4
AppletTrap

• Distribute work between client and server evenly
• Balance between runtime monitoring and static
  scanning
• Low administration cost
• Support resign for Jar file

5
How AppletTrap works?
6
AppletTrap Proxy

• AppletTrap stands as a HTTP proxy and not require
  any client-side modification
• Implemented Cache
• Support Http, Https and Ftp

7
Jar File Controls

• Check the block list firstly
• Check the certification
• Do instrument
• Repack the Jar file
• Resign with imported sign key

8
Class File Controls

• Check the block list firstly
• Do instrument

9
Instrument

• Alter java code sequence during downloading
• Server static scan java code to find insecure
  function
• Server insert monitoring instruction before and
  after insecure function
• Client run original code and monitoring code
• Client send report back if malicious code found

10
Certification checks

• Check the integrality of certification to prove
  that the certification not be modified
• Check whether the CP are trusted with our CP list
• Check the integrality of software with the public
  key of CP

11
Certification

• A certificate is a set of data that identifies an
  entity.
• The data in a certificate includes the public
  cryptographic key.
• A certification include CP and CA

12
CA CP

• The trusted organization that issues the
  certificate is a Certification Authority (CA) and
  is known as the certificate's issuer.
• CP is some one who publish the software, as well
  as the certificate, and we can verify the
  authenticity of that CP by verifying the digital
  signature and the certificate

13
Re-Sign

• Break the integrity of digitally signed Applets
• Re-sign by specified signer
• Client only accept specified signer

14
ActiveX Signature Scanning

• AppletTrap can check the certification and block
  unsafe PE (Portable Executable) formats (for
  example, .exe, .ocx etc.) and cabinet (.cab)
  files with hash list.

15
HTML Script Filtering

• AppletTrap just gets out all the script from the
  html file.
• AppletTrap only filter scripts from Hypertext
  Markup Language file and will not do script
  filter for a normal script file.

16
URL Blocking

• AppletTrap provides the ability to forbid all the
  clients access the given URLs
• Administrator can add a remote folder and set
  recursive to forbid access all the files and all
  subfolders in it.

17
TVCS compatible

• InterScan AppletTrap comes fully compatible with
  the Trend Virus Control System
• TVCS registration supports through a proxy and
  supports

18
Update Block Lists

• Upload all blocked java,URL and ActiveX to server
  and download trend identified block list

19
Configure Controls

• Support remote configure
• InterScan AppletTrap comes with a
  web-based administrator console for central
  management on the network.

20
Q A
21
Known issues 1

• UTF8 name file can't exact correctly and report
  error in server log

22
Known issues 2

• If cached file quantity is large and shut down
  the PC abnormal, restart the applettrap service
  will take long time.

23
Known issues 3

• Cant access some website chat room or forum with
  Applettrap. For example, chat rooms in
  http//newchat.sina.com.cn/

24
Known issues 4

• We only support digital ID which is for Netscape
  Object signing purpose and can export to .p12
  format by Netscape browser.Digital ID from
  Verisign is recommended.

25
Known issues 5

• If the disk space is near to full, the all
  ActiveX can pass through, AppletTrap cant block
  it.

26
Known issues 6

• If update licensed version 2.0 to Version 2.5, it
  is still trial run version, user must input the
  license key again
