Title: ITI481: Unix Administration


1
ITI-481 Unix Administration
  • Meeting 2
  • Rutgers University Center for Applied Computer
    Technologies
  • Chris Uriarte, Instructor

2
Todays Agenda
  • Software Installation
  • Booting and Shutting Down
  • Emergency Boot Procedures

3
Software Installation
  • Methods of Installation
  • Binary distributions
  • Red Hat Package Manager (RPM)
  • Compiling from source
  • Software installations usually must be done as
    root.

4
Red Hat Package Manager (RPM)
  • Generally used for installation and removal of
    precompiled software.
  • Originally deployed on Linux systems, now
    available on other major platforms (most notably,
    Solaris)
  • Installation of operating system and additional
    software on many UNIX distributions managed
    through RPMs.
  • RPMs that are part of the Linux Distribution can
    be found on your install CD at/mnt/cdrom/ltDistri
    bution Namegt/RPMS
  • RPM installations are usually managed by the rpm
    command (/bin/rpm)
  • As close to setup as you can get on UNIX one
    command installs an entire software package.

5
RPM at the Command Line
  • For a list of packages already installedrpm qa
  • To install a new packagerpm ivh
    package-file-name
  • To upgrade an existing packagerpm Uvh
    package-file-name
  • To uninstall a package rpm e package-name
  • (package name as seen in rpm qa)

6
RPM at the Command Line (cont)
  • List the files associated with a particular
    package
  • rpm ql package-name

7
Package Files vs. Installed Packages
  • An rpm package file is a file that contains all
    the software associated with a particular
    application. It ends with the .rpm extension,
    for example netscape-communicator-4.71-i586.rpm
  • When the package is installed, using the rpm i
    option, the package name is officially entered in
    the system package database as the application
    name and version, i.e. netscape-communicator-4.71.
    Therefore, to remove the package, you need use
    the package name not the full name of the file
    that you used to install the package.

8
Exercise Using Red Hat Package Manager
  • Place your Linux CD in your drive - the files on
    your CD can now be accessed via the directory
    /mnt/cdrom.
  • The Mandrake/RPMS directory on your CDROM
    contains many RPM files.
  • Install tcpdump off of the Red Hat CDgt cd
    /mnt/cdrom/Mandrake/RPMSgt rpm ivh
    tcpdump-3.6.1-1mdk.i586.rpm
  • Uninstall elm software gt rpm -e elm-2.5.3-7mdk
  • Question Is vim installed on your system? If
    so, what is the version number?

9
Installing Software from Source
  • A source installation takes raw computer code and
    compiles it into a usable software program.
  • Optimizes software for platform on which it is
    compiled.
  • Generally provides more installation and
    configuration options that using a binary or RPM
    distribution.
  • Requires a C compiler (gcc is the most common and
    is pre-installed with many systems).

10
Typical Steps for Installing from Source
  • Download source archive.
  • Unpack archive
  • filename.tar.gz or filename.tgz - use gzip
    and/or tar
  • filename.Z use uncompress
  • filename.zip use unzip
  • Look at README and/or INSTALL documents for
    specific installation steps.
  • Usually, you
  • Run configure script if there is one.
  • Run make.
  • Run make install.
  • Key READ the README and INSTALL files!

11
Exercise Installing ssh1 from Source
  • Download ssh1.2.27. Additional download
    locations can be found at http//www.ssh.com/produ
    cts/ssh/download.html.
  • From the download directorygt tar -xvzf
    ssh-1.2.27.tar.gz gt cd ssh-1.2.27gt./configuregt
    makegt make install

12
Where to Find UNIX Software
  • Tucows Linuxhttp//www.linuxberg.com
  • Freshmeathttp//www.freshmeat.net/
  • Rpmfind.nethttp//rpmfind.net/linux/RPM/
  • Updates for packages distributed with Red Hat
    Linux can be found at any of the Red Hat Mirrors
    http//www.redhat.com/download/mirror.html

13
Where to Find UNIX Software
  • TwoCows http//www.twocows.com
  • SunFreeware http//www.sunfreeware.com.
  • Download.com http//www.download.com

14
When will you use these software installation
procedures?
  • When you want to install a new system or user
    application.
  • When you need to apply patches, fixes or updates
    that have been provided by your OS vendor.
  • i.e. RedHat security patches and bug fixes
    available at http//www.redhat.com/apps/support/
    errata/

15
The UNIX Boot Process
  • The UNIX boot process is unique.
  • UNIX is divided into system states called run
    levels, ranging from level 0 to level 6.
  • UNIX Flavors boot differently, but the general
    concepts are always the same
  • Bootstrap the system using a bootloader
  • Load the kernel into memory
  • Execute rc scripts (startup scripts)

16
The Linux Boot Process
  • LILO starts and Linux is selected as the
    operating system to boot.
  • The Linux kernel is loaded into memory and then
    probes system hardware.
  • The init process reads /etc/inittab and
    determines whether runlevel 0-6 should be
    started.
  • rc scripts are executed for the specified run
    level to start various services.

17
Linux Loader (LILO)
  • LILO is a boot manager.
  • Usually installed in the Master Boot Record (MBR
    a special segment of your hard disk that the
    system reads during startup).
  • Configuration file is /etc/lilo.conf. If any
    changes are made to lilo.conf, /sbin/lilo needs
    to be run for the changes to become active.
  • For Linux, LILOs purpose is to identify the
    location of the kernel, which is actually just a
    file like/boot/vmlinuz-2.2.12-20

18
General UNIX System Booting
  • Linux is unique, as it uses LILO - a very
    interactive bootloading system.
  • Administrators rarely interact with the
    bootloader on other flavors of UNIX (unless a
    special bootloader is present).
  • Other UNIX flavors, however, have capabilities
    that are similar to those of LILO.

19
The UNIX init Process
  • init reads /etc/inittab, which designates what
    runlevel to start. A runlevel of initdefault is
    selected unless otherwise designated.
  • A runlevel determines what functionality the
    system should be providing. Run levels
    include0 Halt the system1 Single-user (no
    networking)2 Multiuser without NFS3
    Multiuser with NFS4 Unused5 Same as 3 but
    with X11 console6 Reboot the system

20
UNIX Run Levels
  • Run Level 1 single user mode
  • No prompts for username/password
  • Access only via console no remote access to the
    system (i.e. telnet)
  • Very minimal services are running no
    networking, no X Windows.
  • Console user has root permissions
  • User for system maintenance
  • Used when you forget your root password

21
UNIX Run Levels (cont)
  • Run Level 2
  • All typical services are started
  • Multi-user mode users are allowed to log into
    the system
  • NO NFS (Network File System) file sharing
  • Run Level 3
  • Same as run level 2, but NFS is enabled.
  • This is the DEFAULT system run level.

22
UNIX Run Levels (cont)
  • Run Level 4
  • Not used (historical)
  • Run Level 5
  • Same as run level 3, but the system will
    automatically boot into X Windows and console
    users will authenticate via an X Windows
    username/password interface.

23
Special Run Levels
  • Run Level 0
  • The system halt or shutdown run level
  • System processes are stopped and the system halts
  • Run Level 6
  • The system reboot run level.
  • System processes are stopped and the machine is
    restarted.

24
rc Scripts
  • Run level scripts are located in /etc/rc.d/rcX.d
    (Xrunlevel , e.g. /etc/rc.d/rc3.d for run
    level 3). They are used for both startup and
    shutdown purposes.
  • These directories have startup scripts that run
    processes and applications during boot time. The
    scripts use the following naming convention
  • K or S Number Service Name (i.e. S80sendmail)
  • S is for start. K is for kill. Lower numbers
    start before higher.
  • Startup scripts take two options start or stop.
    Scripts with a S are run with start option.
    Scripts with a K are run with a stop option.

25
rc scripts, cont
  • The scripts in the rcX.d directories are
    typically NOT actual files themselves they are
    usually symbolic links to links to scripts
    located in /etc/rc.d/init.d or /etc/init.d
  • For example
  • A script that starts the apache server, might
    exist /etc/rc.d/init.d/apache. This script need
    only contain the commands that required to start
    apache.
  • To start Apache during run level 3, create a
    symbolic link in /etc/rc.d/rc3.d called, for
    example, S99apache and link it to
    /etc/rc.d/init.d/apache

26
rc script example
  • Example you create a script that checks the
    system for world writeable files (files that
    anyone on the system can write to) and emails
    these files to you.
  • This script is called checkworldread and is
    located in /etc/rc.d/init.d.
  • You would like to run this script when the system
    starts in ANY multiuser mode (I.e. run level 2, 3
    and 5)
  • Therefore, you must create rc-style symbolic
    links to /etc/rc.d/init.d/checkworldread from the
    /etc/rc.d/rc2.d, rc3.d and rc5.d directories.

27
rc script diagram
/etc/rc.d/rc3.d
/etc/rc.d/rc5.d
/etc/rc.d/rc1.d
/etc/rc.d/rc2.d
S99checkwr
S99checkwr
S99checkwr
/etc/rc.d/init.d
Symbolic link
checkworldread
28
Ways of Changing Run Levels
  • /sbin/telinit 0-6 or /sbin/init 0-6
  • Allows you to specify a specific run level to
    change to
  • /sbin/shutdown (typically, shutdown now)
  • /sbin/reboot
  • /sbin/halt
  • At LILO boot prompt type linux ltrun levelgt (i.e.
    linux 5)
  • CTRL-ALT-DELETE
  • Key combination on PC-based UNIX systems reboots
    the systemCan be disabled in /etc/inittab.
  • Only power-cycle a UNIX system as a last
    resort.

29
Changing the Default Run Level
  • To change the default run level, edit
    /etc/inittab look for the line
  • id3initdefault
  • After id put the run level number you wish to
    use as your default run level. (usually 3 and 5
    are most common options)
  • Now when your machine boots, it will
    automatically enter that run level.
  • The default UNIX run level is 3, unless youve
    specified otherwise during setup.

30
Useful Keyboard Shortcuts
  • Change to text consoleCTRL-ALT-F1-F6
  • Change to X-Windows CTRL-ALT-F7
  • Terminate X-Session CTRL-ALT-Backspace

31
Exercise Changing Runlevels
  • As root, type the followingshutdown t 30 h
    System Downtime Beginning
  • Hit the power switch on your machine to turn the
    system back on after the shutdown process is
    complete. NEVER turn power off without a proper
    shutdown.
  • At the LILO prompt, enter linux 1. (Linux only)
  • After booting into single-user mode, typeinit 5

32
Emergency Boot Procedures
  • If system is unable to boot normally or you
    forgot your root password, the following options
    are available
  • Boot off of your system-specific boot disk
  • Can be created usually be created during a UNIX
    install process. Linux also has a mkbootdisk
    command.
  • Boot off of your install floppy or cdrom. You
    may be prompted to boot into single user mode or
    into a recovery mode
  • Boot into single user mode.

33
Homework
  • Reading Linux Administration A Beginners Guide
    assigned in class.
Write a Comment
User Comments (0)
About PowerShow.com
