Graphs more on Web search

• 15-211 Fundamental Data
  Structures and Algorithms

Stefan Niculescu James Lyons March 21, 2002
2
Announcements
3
Homework 5

• Homework Assignment 5 will be out on Friday.
• Must do some reading in order to complete it.
• Must take a progress quiz.
• Get started today and as usual, think b4 u hack!

4
Reading

• About graphs
• Chapter 14
• About Web search
• http//www.cadenza.org/search_engine_terms/srchad.
  htm
• A HTML tutorial
• http//www.cwru.edu/help/introHTML/toc.html

5
Introduction to Graphs
6
Graphs an overview
7
Graphs an overview
BOS
DTW
SFO
PIT
JFK
LAX
8
Graphs an overview
BOS
DTW
SFO
PIT
JFK
LAX
Undirected
9
Graphs an overview
BOS
618
DTW
SFO
2273
211
190
PIT
318
JFK
1987
344
2145
2462
LAX
Weights
Undirected
10
Terminology

• Graph G (V,E)
• Set V of vertices (nodes)
• Set E of edges
• Elements of E are pairs (v,w) where v,w ? V.
• An edge (v,v) is a self-loop. (Usually assume no
  self-loops.)
• Weighted graph
• Elements of E are (v,w,x) where x is a weight.

11
Terminology, contd

• Directed graph (digraph)
• The edge pairs are ordered
• Every edge has a specified direction
• The Web is a directed graph
• Undirected graph
• The edge pairs are unordered
• E is a symmetric relation
• (v,w) ? E implies (w,v) ? E
• In an undirected graph (v,w) and (w,v) are
  usually treated as though they are the same edge

12
Directed Graph (digraph)
BOS
DTW
SFO
PIT
JFK
LAX
13
Undirected Graph
BOS
DTW
SFO
PIT
JFK
LAX
14
Terminology, contd

• v and w adjacent (neighbors) if (v,w)?E or
  (w,v)?E
• d(v) (degree of v) neighbors of v (for
  undirected graphs)
• d(v) (out-degree of v) of edges (v,w)?E
• d-(v) (in-degree of v) of edges (w,v)?E

15
Terminology, contd

• Path
• a list of nodes (v1, v2,...,vn) s.t.
  (vi,vi1) ? E for all 0 lt i lt n
• The length of the above path is n-1
• Cycle
• a path that begins and ends with the same node
• Cyclic graph contains at least one cycle
• Acyclic graph - no cycles

16
Elements of a Graph
BOS
DTW
SFO
PIT
JFK
LAX
17
Terminology, contd

• Subgraph of a graph G
• a subset of V with the corresponding edges
  from E.
• Connected graph
• a graph where for every pair of nodes there
  exists a sequence of edges starting at one node
  and ending at the other.
• Connected component of a graph G
• a connected subgraph of G.

18
Elements of a Graph, contd
BOS
DTW
SFO
PIT
JFK
LAX
19
Terminology, contd

• Unrooted (undirected) tree
• a acyclic connected undirected graph
• Theorem in any unrooted tree T(V,E), VE1.
• Proof by induction on V
• Base case V1 (E0)
• Show there exists a node of degree one
• Remove that node and apply induction hypothesis

20
Example of a unrooted tree
BOS
DTW
SFO
PIT
JFK
LAX
21
Quiz Break
22
So, is this a connected graph?
Cyclic or Acyclic?
3
2
Directed or Undirected?
4
1
6
5
23
Directed graph (unconnected)
3
2
Cyclic or Acyclic?
4
1
6
5
24
Representing Graphs
25
Representing graphs

• Adjacency matrix
• 2-dimensional array
• For each edge (u,v), set Auv to true
  otherwise false

• Adjacency lists
• For each vertex, keep a list of adjacent vertices

26
Choosing a representation

• Size of V relative to size of E is a primary
  factor.
• Dense E/V is large
• Sparse E/V is small
• Adjacency matrix is expensive in terms of space
  if the graph is sparse (O(V2 gt O(EV)).
• Adjacency list is expensive in terms of checking
  edges if the graph is dense.

27
Size of a Graph

• How many edges in a undirected graph with n
  vertices?
• Minimum 0
• Maximum

• How many undirected graphs for a set of n given
  vertices?
• Answer

28
Graphs are Everywhere
29
Graphs as models

• The Internet
• Communication pathways
• DNS hierarchy
• The WWW
• The physical world
• Road topology and maps
• Airline routes and fares
• Electrical circuits
• Job and manufacturing scheduling

30
Graphs as models

• Physical objects are often modeled by meshes,
  which are a particular kind of graph structure.

By Jonathan Shewchuk
31
More graph models
NASA CFD labs
By Paul Heckbert and David Garland
See also http//java.sun.com/applets/jdk/1.1/demo/
WireFrame/index.html and http//www.mapquest.com
32
Structure of the Internet
MAPS
UUNET MAP
SOURCE CISCO SYSTEMS
33
Relationship graphs

• Graphs are also used to model relationships among
  entities.
• Scheduling and resource constraints.
• Inheritance hierarchies.

34
Where are we right now?
35
The Web Graph
36
Web Graph

• Documents written in HTML
• HTML (HyperText Markup Language)
• TAGS
• ltheadgt, ltbodygt, lttitlegt
• ltH1gt, ltpgt
• ltagt (anchor, link)

37
A simple HTML example
lthtmlgt ltheadgt ltTITLEgtA Simple HTML
Examplelt/TITLEgt lt/headgt ltbodygt lta
href"http//www.cmu.edu"gt Carnegie Mellon
University lt/agt lt/bodygt lt/htmlgt
38
Web Graph

• A directed graph where
• V (all web pages)
• E (all HTML-defined links from one web
  page to another)

39
Web Graph
lta href gt lta href gt
lta href gt
lta href gt lta href gt
lta href gt lta href gt

• Web Pages are nodes (vertices)
• HTML references are links (edges)

40
Is the Web Graph connected?

• Sparse, unconnected graph
• AUTHORITIES
• web pages containing a reasonable amount of
  relevant information about a specific topic
• HUBS
• web pages that point (link) to many pages
  containing relevant information about a given
  topic

41
Finding Hubs Authorities

• Nice iterative algorithm by Jon Kleinberg
• www.cs.cornell.edu/home/kleinber/auth.ps
• HUB Avrims Machine Learning page
• www.cs.cmu.edu/avrim/ML
• AUTHORITY www.java.sun.com
• Extra credit opportunity for homework 5 ?

42
Graphs Application Search Engines
43
Search Engines
44
What are they?

• Tools for finding information on the Web
• Problem hidden databases, e.g. New York Times
  (ie, databases of keywords hosted by the web site
  itself. These cannot be accessed by Yahoo,
  Google etc.)
• Search engine
• A machine-constructed index (usually by keyword)
• So many search engines, we need search engines to
  find them. Searchenginecollosus.com

45
Did you know?

• Vivisimo was developed here at CMU
• Developed by Prof. Raul Valdes-Perez
• Developed in 2000

46
SE Architecture

• Spider
• Crawls the web to find pages. Follows
  hyperlinks. Never stops
• Indexer
• Produces data structures for fast searching of
  all words in the pages (ie, it updates the
  lexicon)
• Retriever
• Query interface
• Database lookup to find hits
• 1 billion documents
• 1 TB RAM, many terabytes of disk
• Ranking

47
A look at

• 10,000 servers (WOW!) ?
• Web site traffic grows over 20 per month
• Spiders over 2 Billion URLs
• Supports 28 language searches
• Over 100 million searches per day
• Even CMU uses it! ?

48
Googles server farm
49
Web Crawlers

• Start with an initial page P0. Find URLs on P0
  and add them to a queue
• When done with P0, pass it to an indexing
  program, get a page P1 from the queue and repeat
• Can be specialized (e.g. only look for email
  addresses)
• Issues
• Which page to look at next? (Special subjects,
  recency)
• How deep within a site do you go (depth search)?
• How frequently to visit pages?

50
So, why Spider the Web?

• Refresh Collection by deleting dead links
• OK if index is slightly smaller
• Done every 1-2 weeks in best engines
• Finding new sites
• Respider the entire web
• Done every 2-4 weeks in best engines

51
Cost of Spidering

• Spider can (and does) run in parallel on hundreds
  of severs
• Very high network connectivity (e.g. T3 line)
• Servers can migrate from spidering to query
  processing depending on time-of-day load
• Running a full web spider takes days even with
  hundreds of dedicated servers

52
Indexing

• Arrangement of data (data structure) to permit
  fast searching
• Which list is easier to search?
• sow fox pig eel yak hen ant cat dog hog
• ant cat dog eel fox hen hog pig sow yak
• Sorting helps. Why?
• Permits binary search. About log2n probes into
  list
• log2(1 billion) 30
• Permits interpolation search. About log2(log2n)
  probes
• log2 log2(1 billion) 5

53
Inverted Files
POS 1 10 20 30 36
A file is a list of words by position - First
entry is the word in position 1 (first word) -
Entry 4562 is the word in position 4562 (4562nd
word) - Last entry is the last word An inverted
file is a list of positions by word!
FILE
54
Inverted Files for Multiple Documents
jezebel occurs 6 times in document 34, 3 times
in document 44, 4 times in document 56 . . .
LEXICON
WORD INDEX
55
Ranking (Scoring) Hits

• Hits must be presented in some order
• What order?
• Relevance, recency, popularity, reliability,
  alphabetic?
• Some ranking methods
• Presence of keywords in title of document
• Closeness of keywords to start of document
• Frequency of keyword in document
• Link popularity (how many pages point to this one)

56
Spamdexing Link Popularity

• Spamdexing means influencing retrieval ranking by
  altering a web page. (Puts spam in the index)
• www.linkpopularity.com
• Link popularity is used for ranking
• Many measures
• Number of links in (In-links)
• Weighted number of links in (by weight of
  referring page)

57
Search Engine Sizes
AV Altavista EX Excite FAST FAST GG Google INK Ink
tomi NL Northern Light
SOURCE SEARCHENGINEWATCH.COM
58
Historical Notes

• WebCrawler first documented spider
• Lycos first large-scale spider
• Top-honors for most web pages spidered First
  Lycos, then AltaVista, then Google...

59
Overview

• Engines are a critical Web resource
• Very sophisticated, high technology, but secret
• Most spidering re-traverses stable web graph
• They dont spider the Web completely
• Spamdexing is a problem
• New paradigms needed as Web grows
• What about images, music, video?
• Googles image search engine
• Napster
