Title: Avalanches a warning


1
Avalanches - a warning
http//www.youtube.com/watch?v6qVwIuznFW0
2
Avalancheprerequisites
  • snow accumulations and
  • steep topography

Mean snow depth, February (cm)
3
Avalanche fatalities (1998-9)
Kangiqusualujjaq
4
Avalanche facts and figures(Canada)
  • range in size from few 100 m3 to 100 x 106 m3.
  • most occur in remote mountain areas.
  • gt1 million events per yr in Canada
  • 100 avalanche accidents (casualties, property
    damage) reported per yr.
  • Estimated that 1 avalanche in 3000 is potentially
    destructive.

5
Avalanche fatalities per year North America
6
Source New Scientist
7
Avalanche deaths, N. America (2002-3)
Activity Fatalities Skiers 25 Snowmobilers 23
Climbers 5 Snowboarders 4 Hikers
1Total 58
8
Avalanches kill eight in B.C. Headline in The
Province (Jan. 04, 1998)
we have a real disaster on our hands .this is
one of the worst weekends on record Alan
Dennis, Canadian Avalanche Centre
9
Kootenay avalanches, Jan. 03, 1998
  • 6 heli-skiers die in Kokanee Glacier Park
  • 2 skiers die on Mt. Alvin, near New Denver
  • 1 snowmobiler dies (4 buried) near Elliot Lake

10
Avalanches in inhabited areas (e.g. the Alps)
  • On 9th February 1999 in the afternoon a large
    avalanche destroyed 17 buildings on the edge of
    Montroc and killed twelve vertical drop 2500m to
    1300m, horizontal length 2.25Km, deposit depth
    6m. The map shows known avalanche paths in the
    area, with the 1999 avalanche circled.

11
Juneau, Alaska(a city at risk)
Mountains 5 - 10 m of snow?
City receives 2.5m of snow per year
12
Snowfall and avalanche hazards
More than 70 people died in the Alps in the
winter of 1998-9 as a result of avalanches
resulting from the heaviest snowfalls in 50 yrs.
There was extensive damage to property (e.g.
Morgex, Italy), and many tourists were stranded.
13
Deaths in villages (1998-9)
Place Deaths
Kangiquasualujjaq, Qué 9 in school
gym Darband, Afghanistan 70 in
village Gorka, Nepal 6
in village Le Tour, France 12
in ski resort/village Galtuer, Austria
20 in ski resort/village
14
Bruce Tremper Staying Alive in Avalanche Terrain,
(Mountaineers Books) most avalanches happen
during storms but most avalanche accidents occur
on the sunny days following storms. Sunny weather
makes us feel great, but the snow-pack does not
always share our opinion. And elsewhere
People who are most likely to die are those whose
skills at their sport (e.g. snowboarding) exceed
their skill at forecasting avalanches. So, some
basics..
15
Avalanche triggers
  • Snowstorms dump thick snowpacks over surface hoar
    (increased weight)
  • Vehicles or skiers increase weight on pack
  • Surface heating (sunshine, warm airmass) weakens
    snowpack
  • Gravitational creep
  • Shaking (seismic, explosives), but rarely low
    noise (shouts, aircraft overhead)

16
Avalanche types and triggers
from The Province Jan. 04, 1998
17
Avalanche types IPoint-release
  • start at a point in loose, cohesionless snow
  • downslope movement entrains snow from sidewalls
  • in dry snow they are relatively small
  • in wet snow they can be large and destructive

18
Avalanche types IISlabs
  • layers of cohesive snow may fail as a slab
  • can be triggered from below
  • fracture must occur around the perimeter (crown,
    flanks and toe or stauchwall)
  • depth controlled by depth to failure plane

crown
flank
toe
19
Slab avalanches Failures are a result of layered
snowpacks
20
Slab avalanches dry and wet
Dry avalanches moveat 50-200 km/h develop
powder clouds
Wet avalanches moveat 20-100 km/h (denser
slower)
most dangerous!
21
Formation of weak layers in snowpacks
  • In calm conditions snow settles as a fluffy,
    powdery layer of unbroken crystals (the weak
    layer). If the wind speed increases, a layer of
    dense broken crystals settles on top (the
    slab).
  • Cold air over a thin snowpack can create depth
    hoar near the base of the snowpack. Water
    vapour sublimates from pores in snow onto ice
    crystals (produces a weak layer).
  • Surface hoar forms on cold, clear nights. Ice
    crystals are large and have weak cohesion.

22
(No Transcript)
23
Surface hoarice crystals commonly 10 mm long
Photo K.Williams
24
Strengthening of surface hoar layer over time
Avalanches
Graph Chalmers and Jamieson (2003) Cold Reg.
Sci. Tech. 37, 373-381.
25
Snow stability Rutschblock test
26
Snow stability testing
Surface test Bench test
failure plane at depth
Images Landry et al. (2001) Cold Reg. Sci.
Tech. 33, 103-121.
27
Effects of slope angle
rare
infrequent
60
most large slabs
frequent sluffs
45
frequent
rare
30
infrequent
rare
25
Point release
Slabs
28
Avalanche hazard and aspect
leeward? windward?
north-facing? south-facing? shaded
sunnylittle T fluc. large T fluc.
Photo R. Armstrong
29
start zone
track
run-out zone
30
Effects of clearcutting in mountainous terrain.
A wet slab avalanche was generated from a
clearcut block on a 37 slope at Nagle Creek, BC
(1996). It split into six separate avalanche
paths, which destroyed 400K of timber
31
Avalanche forecasting
  • Wind speedhazard increases if wind gt25 km/h.
  • Snowfall forecastlt0.3 m snow depth - no
    hazard.gt1.0 m - major risk.
  • Temperature change hazard increases if T gt0C.

32
Avalanche forecasting(Centre for Snow Studies,
Grenoble, France)
3-phase model
SAFRAN
Predicts average weather for 23 zones in
Alps Predicts snowpack changes (errors tend to
accumulate) Predicts snow stability
CROCUS
MEPRA
33
Protecting settlements
In Switzerland and some parts of US red zones
have avalanche return intervals lt30 yrs or large
avalanches (impacts gt30 kPa) lt300 yrs. Building
is prohibited in these areas. In blue zones the
upslope walls of a building must be reinforced or
include a deflecting wedge.
34
Avalanche protection structures (snow nets) 5 m
high
35
Andermatt,Switzerland.Village protected by
fences to hold snowpack, and forest (cutting
forbidden by C13th by-law)
36
Protecting transportation corridors e.g
Coquihalla Hwy.
37
Protecting highway links
  • Boston Bar (Coquihalla Highway)
  • 71 avalanche paths producing 100 events / yr.
  • RI varies from lt monthly to 25 yrs.
  • Forecasts from 5 weather stations (4 in alpine)
  • Defences- snowsheds (5 shed cost 12M)-
    raised highway deflection dams check dams- use
    of artillery and ropeways to initiate controlled
    events

38
Will global warming reduce the avalanche hazard
in temperate alpine areas?
Data from Switzerland show that snowpacks in the
1990s were significantly thinner than in any
decade since the 1930s. Natural variation or
global warming?
above below
Laternser and Schneebeli (2003) Int. J.
Climatology 23, 733-750.
39
Will global warming reduce the avalanche hazard
in temperate alpine areas?
Above normal
Below normal
Scott and Kaiser (2003?) Amer. Met.Soc
Conference pdf 71795.
40
Ice avalanches
  • On September 21, 2002 the terminus of the Kolka
    Glacier in the Caucasus Mountains collapsed, and
    some 4 M m3 of ice swept 20 km down-valley,
    killing 100 people and burying a village. A
    similar event occurred in the same valley in
    1902.

Kolka Glacier
avalanchedebris
cf. Mt.Yungay, Peru (1970)
41
Subsidence and local ground failure
before
vertical displacement of the ground surface
D, v
after
Velocity
fast
slow
slight
expansive soils
Vertical displacement
surface loading
sinkholes
large
42
Subsidence and local ground failure
Expansive soils
  • associated with smectite clays and frost-heaving
  • annual cost gt1000M in North America

43
Sinkholes
  • Characterized by rapid surface collapsee.g. New
    Mexico (1918) a sinkhole 25m wide by 20 m deep
    formed in a single night.
  • Individual holes small, but may be locally
    numerous
  • Collapse behaviour unpredictable often triggered
    by heavy rain, which causes loading of soil and
    sinkhole collapse (e.g. in Pascoe Co., Florida.,
    twice as many sinkholes are reported in wet
    season vs. dry season)

44
Sinkholes
Occur in soluble carbonates or evaporites
limestone dolomite gypsum halite
Relative solubility
1 1 150 7500
45
Stage 1 - Cavern formation Stage 2
- Sinkhole formation
46
House for scale
Large sinkhole, central Florida
47
Sinkhole formation in halite, Dead Sea
sinkholes collapse above halite caverns


fresh water
Dead Sea
halite
48
1912 survey of one land section in
Indiana, showing numerous sinkholes
49
Subsidence and local ground failure
  • Effects - damage to urban and suburban
    infrastructure
  • Detection - e.g. GPR and ER (see next slide)
  • Mitigation - non-intensive land uses on affected
    land to minimize hazard

50
Sinkhole detection(ground-penetrating radar
imagery)
soil
sinkhole
limestone
51
Sinkhole detection electro-resistivity
techniques
52
Global distribution of vertisols
53
Vertisol profile
Note blocky structure and uniform black upper
horizons
54
Vertisols - Gilgai
55
Vertisols-dry season shrinkage and cracking
56
Vertisols - Slickensides
57
Smectite clay minerals expansive soils
H2O
Graphic www.smianalytical.com
58
Damage to buildings on expansive soils
Farm buildings, Idaho
House, Texas
59
How significant is the problem?
  • Expansive soils are the 1 cause of structural
    damage to buildings and urban infrastructure
    (roads, sidewalks, pipelines) in the US.
  • Annual losses US-2 - 7 G (probably x2 the
    amount associated with all other natural hazards!)

60
Future problemse.g. Dallas, TX
  • Expansive soils ( low urbanization potential)
    are predominant on the interfluves of the plains
    of north Texas.
  • Suburban construction is increasingly moving onto
    these soils in as low and medium risk soils reach
    their development capacity (gt50 of new
    construction on these soils in some counties).
  • Source Williams (2003) Environmental Geology
    44 933-938
