ODS Primer

1
ODS Primer

• Enio Presutto
• York University
• September 21, 2001

2
Legal Stuff

• The Presenter, The SAS Institute, and the
  Management of BCE Place assume no responsibility
  if someone gets hit by flying raisins, chocolate
  Bars, etc.

3
For Your Information

• GLASGOW, Scotland (Reuters) -- Good news for
  chocoholics. The treat favoredby millions is
  also good for you, researchers said on
  Monday.Chocolate contains compounds called
  flavonoids that can help maintain a healthy heart
  and good circulation and reduce blood clotting --
  which can cause heart attacks and strokes."More
  and more, we are finding evidence that
  consumption of chocolate that is rich in
  flavonoids can have positive cardiovascular
  effects," Carl Keen, a nutritionist at the
  University of California, Davis, told a
  scienceconference here."We not only have
  observed an increase in antioxidant capacity
  after chocolate consumption, but also modulation
  of certain compounds which affect blood
  vessels."Antioxidants are substances that help
  reduce the damage of cancer-causing charged
  particles in the body. Fruits, vegetables, nuts
  and whole grains are high in antioxidant vitamins
  such as C and E.Not all chocolate created equal
  Flavonoids in chocolate are derived from cocoa,
  which is rich in the compounds. Research has
  shown that a small bar of dark chocolate contains
  as many flavonoids as six apples, 4.5 cups of
  tea, 28 glasses of white wine and two glasses of
  red.

4
ODS - What is it?

• In previous versions of SAS Datastep and
  procedures produced output directly
• Output was produced for mainframe printing using
  line printers (monospaced fonts)
• Graphics were produced for plotters
• Very little control over appearance

5
ODS Output Delivery System

• Scopo della giornata di corso è quello di
  introdurre le tecniche per utilizzare questa
  nuova funzionalità disponibile con la Versione 8
  di SAS per la produzione di output (listati,
  tabelle, pagine HTML, dataset SAS) e la
  generazione di template e stili per la produzione
  automatica di questi tipi di output.

6
ODS Output Delivery System

• Version 8 saw introduction of ODS
• Datastep and procedures now produce output
  objects
• ODS processes these output objects and produces
  required output
• ODS can produce in the following formats HTML,
  PDF, RTF, CSV, JPEG, GIF, Postscript, XML, etc.

7
ODS Proc Print before ODS

• proc print datatass.tass(obs5)
• run

8
ODS Proc Print before ODS

• The SAS System
• Obs number Title
• 1 1 Hello Mary Lou/Travelin'
  Man
• 2 2 I'm Gonna Knock On Your
  Door
• 3 3 Big Bad John
• 4 4 Crying/Candy Man
• 5 5 You're The Reason
• Obs Artist
  year
• 1 Ricky Nelson
  1961
• 2 Eddie Hodges
  1961
• 3 Jimmy Dean
  1961
• 4 Roy Orbison
  1961
• 5 Bobby Edwards 1961

9
ODS Proc Freq before ODS

• proc freq datatass.tass(obs20)
• tables artist
• run
• Output produced is suitable for line printers
• is monospaced
• Only one great font
• No colour
• Limited to 133 columns

10
ODS Proc Freq before ODS

• The SAS System
• The FREQ Procedure
• Artist
•
  Cumulative Cumulative
• Artist Frequency
  Percent Frequency Percent
• --------------------------------------------------
  ---------------------------
• Andy Stewart 1
  5.00 1 5.00
• Beau-Marks 1
  5.00 2 10.00
• Bobby Edwards 1
  5.00 3 15.00
• Chubby Checker 1
  5.00 4 20.00
• Clarence "Frogman" Henry 1
  5.00 5 25.00
• Del Shannon 1
  5.00 6 30.00
• Dion 1
  5.00 7 35.00
• Eddie Hodges 1
  5.00 8 40.00
• Elvis Presley 1
  5.00 9 45.00
• Everly Brothers 1
  5.00 10 50.00
• Highwaymen 1
  5.00 11 55.00
• Jimmy Bell 1
  5.00 12 60.00
• Jimmy Dean 1
  5.00 13 65.00

11
ODS Defaults

• Version 8 procedure output defaults to ODS
  LISTING destination
• No changes required to your program

12
ODS HTML Destination

• ods listing close
• filename results 'd\2001-09-21
  tass\saspgms\html1.html'
• ods html bodyresults
• proc print datatass.tass(obs5)
• run
• ods html close
• run
• View Results

13
ODS HTML Destination

• ods listing close
• ods html body'd\2001-09-21 tass\saspgms\html1.ht
  ml'
• (title'Proc Print to HTML')
• proc print datatass.tass(obs5 )
• run
• ods html close
• run
• Title option changes text used in browser title
  bar
• View Results

14
ODS HTML Destination

• ods listing close
• ods html body'd\2001-09-21 tass\saspgms\html3.ht
  ml'
• (title'Proc Print to HTML')
• title 'T.A.S.S. September 2001 - ODS
  Presentation'
• proc print datatass.tass(obs5)
• run
• proc freq datatass.tass(obs10)
• tables artist
• run
• ods html close
• run
• View Results

15
ODS HTML Destination

• ods listing close
• ods html body'd\2001-09-21 tass\saspgms\html4-bo
  dy.html'
• contents'd\2001-09-21
  tass\saspgms\html4-contents.html'
• frame'd\2001-09-21 tass\saspgms\html4-frame.h
  tml'
• (title'Proc Print to HTML')
• title 'T.A.S.S. September 2001 - ODS
  Presentation'
• title2 'Proc Print output'
• proc print datatass.tass(obs5)
• run
• title2 'Proc freq output'
• proc freq datatass.tass(obs10)
• tables artist
• run
• ods html close
• run
• View Results

16
ODS HTML Destination

• ods listing close
• ods html body'd\2001-09-21 tass\saspgms\html5-bo
  dy.html'
• contents'd\2001-09-21
  tass\saspgms\html5-contents.html'
• frame'd\2001-09-21 tass\saspgms\html5-frame.h
  tml'
• (title'Proc Print to HTML')
• title 'T.A.S.S. September 2001 - ODS
  Presentation'
• title2 'Proc Print output'
• ods proclabel 'Listing of Songs'
• proc print datatass.tass(obs5)
• run
• title2 'Proc freq output'
• ods proclabel 'Frequency Report'
• proc freq datatass.tass(obs10)
• tables artist
• run
• ods html close
• run
• View results

17
ODS HTML Destination

• ods listing close
• ods html body'd\2001-09-21 tass\saspgms\html6.ht
  ml'
• (title'Proc Print to HTML')
• title 'lth1gtSong titles taken from 1050 Chum
  Chartslt/h1gt'
• proc print datatass.tass(obs5 ) noobs label
• var title artist year
• label artist'ltigtltfont colorredgtArtist
  Namelt/fontgtlt/igt'
• run
• ods html close
• run
• View results

18
ODS HTML Destination

• ods listing close
• goptions devicegif
• ods html body'd\2001-09-21 tass\saspgms\html7.ht
  ml'
• (title'Proc Print to HTML'
• no_bottom_matter)
• title 'lth1gtSong titles taken from 1050 Chum
  Chartslt/h1gt'
• NOTES
• No_bottom_matter tells ods not to generate
  closing html tags

19
ODS HTML Destination

• proc print datatass.tass(obs5 ) noobs label
• var title artist year
• label artist'ltigtltfont colorredgtArtist
  Namelt/fontgtlt/igt'
• run
• ods html close
• Notes
• Ods destination is closed

20
ODS HTML Destination

• filename graphic 'd\2001-09-21
  tass\saspgms\html7.html' mod
• title 'Song titles taken from 1050 chum charts'
• ods html filegraphic (no_top_matter)
• gpath'd\2001-09-21 tass\saspgms\'
• (urlnone)
• NOTES
• Use filename to append to html file created on
  previous page
• Use no_top_matter to tell ods not to generate
  opening tags in html file
• (urlnone) tells ods not to use URLs, but to
  use filenames instead, it you specify a url then
  ods will use it to build the html page names

21
ODS HTML Destination

• proc gchart datatass.tass
• vbar3d year /
• name'Year Recorded'
• run quit
• ods html close
• run
• View Results

22
ODS RTF destination

• ods listing close
• filename results 'd\2001-09-21
  tass\saspgms\rtf1.rtf'
• ods rtf fileresults
• proc print datatass.tass(obs5)
• run
• ods rtf close
• run
• View results

23
ODS RTF destination

• libname tass 'D\2001-09-21 tass\sasdata'
• run
• ods listing close
• filename results 'd\2001-09-21
  tass\saspgms\rtf2.rtf'
• proc format
• value traffic low-100000 'cxCC0000'
  / green /
• 100001-240000'cxFF9900
  / yellow /
• 240001-high 'cx006600
  / red /
• run
• Note
• Traffic lighting

24
ODS RTF destination

• ods rtf fileresults
• proc tabulate datatass.popular
• class name /STYLEFONT_FACE"Times New
  Roman"
• var amount /STYLEFONT_FACE"Helvetica"
• tables name'Item Name' all, amount'Amount
  Sold'sum
• STYLEFOREGROUNDTRAFFIC.
  FONT_WEIGHTbold
• run
• ods rtf close
• run
• View Results

25
ODS PDF destination

• libname tass 'D\2001-09-21 tass\sasdata'
• run
• ods listing close
• filename results 'd\2001-09-21
  tass\saspgms\pdf2.pdf'
• ods pdf fileresults notoc
• proc tabulate datatass.popular
• class name /STYLEFONT_FACE"Times New
  Roman"
• var amount /STYLEFONT_FACE"Helvetica"
• tables name'Item Name' all, amount'Amount
  Sold'sum
• STYLEFOREGROUNDTRAFFIC.
  FONT_WEIGHTbold
• run
• ods pdf close
• run
• View results

26
References

• Output Delivery System
• By Lauren E. Haworth
