Introduction to Oscilloscopes

1
Introduction To Oscilloscopes
2
What is an Oscilloscope

• The oscilloscope is basically a graph-displaying
  device that draws a graph of an electrical
  signal. the vertical (Y) axis represents voltage
  and the horizontal (X) axis represents time. The
  intensity or brightness of the display is
  sometimes called the Z axis.

3
Types of Waves

• Waveform shapes reveal a great deal about a
  signal.
• Any time you see a change in the height of the
  waveform, you know the voltage has changed.
• Any time there is a flat horizontal line, you
  know that there is no change for that length of
  time.
• Straight, diagonal lines mean a linear change

4
Basics of Measurement

• Frequency and Period
• If a signal repeats, it has a frequency. The
  frequency is measured in Hertz (Hz) A repetitive
  signal also has a period, which is the amount of
  time it takes the signal to complete one cycle.
• Voltage
• Voltage is the amount of electric potential
  between two points in a circuit. The voltage from
  the maximum peak to the minimum peak of a
  waveform is referred to as the peak-to-peak
  voltage.
• Amplitude
• Amplitude refers to the amount of voltage
  between two points in a circuit. Amplitude
  commonly refers to the maximum voltage of a
  signal measured from ground, or zero volts.

5
Types of Oscilloscopes

• Cathode-ray oscilloscope (CRO)
• The earliest and simplest type of oscilloscope
  consisted of a cathode ray tube, a
  vertical amplifier, a time base, a horizontal
  amplifier and a power supply.
• Dual-beam oscilloscope
• The dual-beam analog oscilloscope can display
  two signals simultaneously. A special
  dual-beam CRT generates and deflects two separate
  beams.

6
Types of Oscilloscopes

• Digital oscilloscopes
• While analog devices make use of continually
  varying voltages, digital devices employ binary
  numbers which correspond to samples of the
  voltage. In the case of digital oscilloscopes, an
  analog-to-digital converter (ADC) is used to
  change the measured voltages into digital
  information.

7
Types of Oscilloscopes

• Mixed-domain oscilloscopes
• A mixed-domain oscilloscope (or MDO) has three
  kinds of inputs, a small number analog channels,
  a larger number of digital channels, and one RF
  channel. It provides the ability to accurately
  time-correlate analog, digital, and RF signals
  with each other.

8
Types of Oscilloscopes

• Handheld oscilloscopes
• Handheld oscilloscopes (also called scopemeters)
  are useful for many test and field service
  applications. Today.
• Mixed-signal oscilloscopes
• A mixed-signal oscilloscope (or MSO) has two
  kinds of inputs, a small number (typically two or
  four) of analog channels, and a larger number
  (typically sixteen) of digital channels.

9
Operating The Oscilloscope

• Proper Grounding
• Ground your oscilloscope by plugging its
  three-pronged power cord into an outlet grounded
  to earth ground. Grounding the oscilloscope is
  necessary for safety. If a high voltage contacts
  the case of an ungrounded oscilloscope

10
Operating The Oscilloscope

• Connecting the Probes
• Now you are ready to connect a probe to your
  oscilloscope. A probe, if well-matched to the
  oscilloscope, will enable you to access all of
  the power and performance in the oscilloscope and
  will ensure the integrity of the signal you are
  measuring.

11
Operating The Oscilloscope

• Calibrating the Instrument
• When using an oscilloscope, it is very easy to
  plug the oscilloscope probe in and start to make
  measurements. There is a built in calibrator on
  virtually every oscilloscope for this purpose.

12
Thank You
