comparison of watermarking and cryptogrphy

1
SAVEETHA SCHOOL OF ENGINEERING

• SAVEETHA UNIVERSITYCHENNAI602105
• DEPARTMENT OF ELECTRONICS AND COMMUNICATION
  ENGINEERING

2
COMPARISON OF WATERMARKING WITH CRYPTOGRAPHY

• DONE BY,
• POOJA SHUKLA
• PRIYANKA RANJAN
• SONAM TIWARI
•

•


3
AIM

• To compare watermarking with cryptography
• To compare the relative advantages and
  disadvantages
• To provide security needs as well as extra layer
  of authentication

4
ABSTRACT

• Watermarking is a technique for labelling digital
  pictures by hiding secret information into the
  images.
• Cryptography is a scheme of protecting
  information by transforming it into an unreadable
  format.

5
EXISTING METHODOLOGY

• Cryptography is a secret sharing scheme which
  independently disclose no information about the
  original secret image

• Cryptography can be applied to,
• TEXT
• CODE
• IMAGES

6
PROPOSED SYSTEM

• Watermarking uses electronic stamps which is used
  for labeling digital pictures by hiding secret
  information into the images.

• Water Marking can be applied to,
• IMAGES
• TEXT
• AUDIO
• VIDEO

7
BLOCK DIAGRAM

• IMAGE WATERMARKING

WATERMARKED IMAGE
ORIGINAL IMAGE
WATERMARK
INVERSE DWT
EMBEDDING PROCESS
DWT
8
IMAGE CRYPTOGRAPHY
KEY
INVERSE KEY
ENCRYPTION
DECRYPTION
SECRET IMAGE
9
TEXT WATERMARKING
TEXT
SECRET TEXT
EMBEDDING
ENCRYPTION
EXTR-ACTION
DECRYPTION
KEY
INVERSE KEY
10

• TEXT CRYPTOGRAPHY

KEY
INVERSE KEY
CIPHER TEXT
PLAIN TEXT
PLAIN TEXT
ENCRYPTION
DECRYPTION
11
GENERAL COMPARISON

• WATERMARKING
• 1. Watermarking is about robustness against
  possible attacks
• 2. Uses steganography techniques
• 3. Gives more privacy

• CRYPTOGRAPHY
• 1. Cryptography is about protecting the meaning
  of the document
• 2. Uses biometrics techniques
• 3. No privacy

12
ADVANTAGES
WATERMARKING

• Undetectable and Undeletable by hackers
• Resistant to lossy data compression
• EXAMPLE JPEG
• Resistant to image manipulation and processing
  operations
• EXAMPLE cut-copy-paste
• Privacy
• Security
• Cost and Capacity
• Recoverable and Reversible

13
CRYPTOGRAPHY

• Message secure algorithm
• Security parameter
• Secure keying
• Not transmitted to anyone
• Enables use of DIGITAL CERTIFICATES
• Fully automated
• High speed

14
APPLICATIONS
WATERMARKING

• Copyright protection
• Prevention of unauthorized copying
• Authentication
• Media Bridging
• Broadcast Monitoring
• Fingerprinting
• Secret Communication
• Determination of ownership

15
CRYPTOGRAPHY

• Secrecy in transmission and storage
• Integrity in transmission and storage
• Authentication of identity
• Credentialing system
• System using changing key
• Hardware support

16
PROPERTIES
WATERMARKING

• Perceptually Invisible
• Robustness
• Embedding Effectiveness
• Data Payload
• Blind and Informed Detection
• High bit rate

17
CRYPTOGRAPHY

• Image resistance
• Message authentication codes
• Accessibility
• Cryptokey security
• Protection
• Exportable and Removable
• Unique owner

18
REQUIREMENTS

• Requirements vary with application. For example,
• Perceptually transparent - must not perceptually
  degrade original content.
• Robust survive accidental of malicious
  attempts at removal.
• Oblivious or Non-oblivious recoverable with or
  without access to original.
• Capacity number of watermark bits embedded.
• Efficient encoding and decoding.

19
WATERMARKING TECHNIQUES

1. Embedding Locations
2. Robust Watermarking
3. Fragile Watermarking
4. Semi-Fragile Watermarking
5. Configuration of Cover Work by Watermark
   Embedding
6. Watermarking Domains

20
CRYPTOGRAPHY TECHNIQUES

1. Hash Techniques
2. Symmetric Key Cryptography
3. Asymmetric Key Cryptography

21
BASIC FREQUENCY DOMAIN

• DISCRETE FREQUENCY TRANSFORM
• DISCRETE COSINE TRANSFORM
• DISCRETE WAVELET TRANSFORM

22
PARAMETERS

• PSNR
• SNR
• Transformation Method
• Image Format
• Quality Factor
• Kemel size
• Security Parameter
• Embedding Parameter
• Detection Parameter

23
WATERMARKING CONTENT
ORIGINAL IMAGE
SECRET IMAGE
24
WATERMARKED IMAGE
25
CRYPTOGRAPHED CONTENT
26
Share 1 Share 2
27
CONCLUSION
CRYPTOGRAPHY

• Detecting and decoding the hidden data within a
  given medium.
• Even if secret content is not revealed, modifying
  the cover medium changes the mediums statistical
  properties.
• Distributed Dictionary Attack

WATERMARKING

• It deals with possible attacks and protects the
  content.
• Once you try to hack the secret the whole content
  gets destroy.

28
FUTURE WORKS

• The most important use of CRYPTOGRAPHY techniques
  will probably lie in the field of digital
  watermarking.
• It may become limited under laws - governments
  claimed that criminals use CRYPTOGRAPHY AND
  WATERMARKING to communicate.

29
LITERATURE SURVEY

• Independent watermarking classification by
  Dittmann, J., Mukherjee, A., Steinebach, M.
  (2000, March 27 - 29).
• Applied cryptography by Wiley and Sons, 1996.

30
REFERENCE

• Hidden Digital Watermarks in Images by Chiou-Ting
  Hsu and Ja-Ling Wu, Senior Member, IEEE
• A Feature-Based Robust Digital Image Watermarking
  Scheme by Chih-Wei Tang and Hsueh-Ming Hang,
  Fellow, IEEE
• Comparison Of Visual Cryptography Schemes by M.
  Amarnath Reddy, IJEST

31
THANK U.!!!!!!
32
QUERIES..????
