Wireless Zigbee Protocol

1
Click anywhere to start the presentation
2
Product Name
Zigbee Sniffer

3
Product Information

• ZigBee is the
  leading standard
  for smart energy

  networks, home automation,
  sensor networks,
  health care,
  and many other exciting
  applications.
  ZigBee RF4CE is
  dedicated for remote
  controls
  and other consumer
  electronics applications.

4
Multi-channel Networks Analysis
The 802.15.4 PHY defines 16 possible
communication channels in the 2.4Ghz ISM band.
Perytons Protocol Analyzers capture multiple
channels simultaneously, enabling the analysis of
multiple networks operating in the same
environment
5
Analyzing 802.15.4/ZigBee network(s) with a
conventional, single channel analyzer

• A typical single-channel analyzer is capable of
  capturing only one of the 16 possible channels.
• The user needs to set the analyzer to the right
  channel, or the analyzer should actively or
• passively look for it.
• The following figures show messages received in a
  single channel setup vs. the actual network
• topology where the messages have been received
  from.

6
Contact Information

• Perytons Headquarters
• POB 3437, Ness-Ziona , 74133, Israel
• Tel [phone] Fax [phone]
  Skype perytons_at_skype
• Technical support support_at_perytons.com 1 703
  879 8962
• General inquiries contact_at_perytons.com 1 703
  879 8962
• US Office
• Sales Technical inquiries amnon_at_perytons.com
  1 734 846 0549 Mr. Amnon Steiner
