Advanced MPI

1
Advanced MPI

• Dan Stanzione

2
Audience Background

• This class assumes you have some background in
  parallel programming
• You are familiar with basic MPI
• You are familiar with basic OpenMP
• And, of course, you are familiar with a
  programming language and the UNIX/Linux operating
  environment
• You have run parallel jobs through a queueing
  system in a shared environment such as Ranger
  before.
• You can use SSH to log into remote systems and
  transfer files
• If this is not the case, please see the TACC
  introductory courses
• Slides from Lisboa class this week
  http//taccspringschool.ist.utl.pt/SpringSchool/Ag
  enda.html
• Ranger Virtual Workshop
• https//www.cac.cornell.edu/ranger/

3
Outline

• Review of MPI Advanced Topics
• Derived Datatypes
• Communicator manipulations
• One-sided communication
• I/O
• What is Parallel I/O? Do I need it?
• Cluster Filesystem Options
• MPI I/O and ROMIO
• Example striping schemes

4
User Defined Datatypes

• Methods for creating data types
• MPI_Type_contiguous()
• MPI_Type_vector()
• MPI_Type_indexed()
• MPI_Type_struct()
• MPI_Pack()
• MPI_Unpack()
• MPI allows datatypes to be defined in much the
  same way as modern programming languages
  (C,C,F90)
• This allows your communication and I/O operations
  to operate using the same datatypes as the rest
  of your program
• Makes expressing the partitioning of datasets
  easier

5
Contiguous Array

• Creates an array of counts elements
• MPI_Type_contiguous(int count,
• MPI_Datatype oldtype,
• MPI_Datatype newtype)

6
Strided Vector

• Constructs a cyclic set of elements
• MPI_Type_vector(int count,
• int blocklength,
• int stride,
• MPI_Datatype oldtype,
• MPI_Datatype newtype)
• Stride specified in number of elements
• Stride can be specified in bytes
• MPI_Type_hvector()
• Stride counts from start of block

7
Subarrarys

• Perhaps the most useful MPI Datatype, the
  Subarray type lets you divide a
  multi-dimensional array into smaller blocks
• int MPI_Type_create_subarray(ndims,
  array_of_sizes, array_of_subsizes,
  array_of_starts, order, oldtype, newtype)
• int ndims
• int array_of_sizes
• int array_of_subsizes
• int array_of_starts
• int order
• MPI_Datatype oldtype
• MPI_Datatype newtype
• SubArray Example coming after we add some
  communicator and I/O operations

8
SubArray Illustration
start1
Size0
start0
subsize0
subsize1
Size1
9
Indexed Vector

• Allows an irregular pattern of elements
• MPI_Type_indexed(int count,
• int array_of_blocklengths,
• int array_of_displacements,
• MPI_Datatype oldtype,
• MPI_Datatype newtype)
• Displacements specified in number of elements
• Displacements can be specified in bytes
• MPI_Type_hindexed()
• MPI_Type_create_indexed_block() is a shortcut if
  all blocks are the same length

10
Structured Records

• Allows different types to be combined
• MPI_Type_struct(int count,
• int array_of_blocklengths,
• MPI_Aint array_of_displacements,
• MPI_Datatype array_of_types,
• MPI_Datatype newtype)
• Blocklengths specified in number of elements
• Displacements specified in bytes

11
Committing types

• In order for a user-defined derived datatype to
  be used as an argument to other MPI calls, the
  type must be committed.
• MPI_Type_commit(type)
• MPI_Type_free(type)
• Use commit after calling the type constructor,
  but before using the type anywhere else
• Call free after the type is no longer in use (no
  one actually does this, but it makes computer
  scientists happy...)

12
Vector Example

• MPI_TYPE_VECTOR function allows creating
  non-contiguous vectors with constant stride

mpi_type_vector(count, blocklen, stride, oldtype,
vtype, ierr)mpi_type_commit(vtype, ierr)
1 6 11 16 2 7 12 17 3 8 13
18 4 9 14 19 5 10 15 20
nrows
ncols
call MPI_Type_vector(ncols, 1, nrows,
MPI_DOUBLE_PRECISION, vtype, ierr) call
MPI_Type_commit(vtype, ierr) call MPI_Send(
A(nrows,1) , 1 , vtype )
13
Dealing with Communicators

• Many MPI operations deal with all the processes
  in a communicator
• MPI_COMM_WORLD by default contains every task in
  your MPI job
• Other communicators can be defined for more
  complex operations for different parts of the
  task, to add topology, to segregate different
  kinds of messaging

14
Communicators and Groups I

• All MPI communication is relative to a
  communicator which contains a context and a
  group. The group is just a set of processes.

MPI_COMM_WORLD
3
2
4
1
0

MPI_COMM_WORLD
2
0
COMM1
1
0
1
COMM2
15
Communicators and Groups II

• To subdivide communicators into multiple
  non-overlapping communicators Approach I
• e.g. to form groups of rows of PEs

MPI_Comm_rank(MPI_COMM_WORLD, rank) myrow
(int)(rank/ncol)
16
MPI_Comm_split

• Argument 1 communicator to split
• Argument 2 key, all processes with the same key
  go in the same communicator
• Argument 3 (optional) value to determine
  ordering in the result communicator
• Argument 4 result communicator

MPI_Comm_rank(MPI_COMM_WORLD, rank) myrow
(int)(rank/ncol) MPI_Comm_split(MPI_COMM_WORLD,
myrow,rank,row_comm)
17
Topologies and Communicators

• MPI allows processes to be grouped in logical
  topologies
• Topologies can aid the programmer
• Convenient naming methods for processes in a
  group
• Naming can match communication patterns
• a standard mechanism for representing common
  algorithmic concepts (i.e. 2D grids)
• Topologies can aid the runtime environment
• Better mappings of MPI tasks to hardware nodes
• (Not really widely used in most implementations
  yet)

18
Topology Mechanics

• Topologies have the scope of a single
  (intra)communicator
• Topologies are an optional attribute given to a
  communicator
• Two topologies are supported
• Cartesian coordinates (grid)
• Graph
• nodes are tasks
• edges are named communication pathways

19
Cartesian Topologies

• int MPI_Cart_create(MPI_Comm comm_old, int ndims,
  int dims, int periods, int reorder, MPI_Comm
  comm_cart)
• MPICartcomm MPIIntracommCreateCart(...)
• MPI_CART_CREAT(...)
• comm_old - input communicator
• ndims - of dimensions in cartesian grid
• dims - integer array of size ndims specifying the
  number of processes in each dimension
• periods - true/false specifying whether each
  dimension is periodic
• reorder - ranks may be reordered or not
• comm_cart - new communicator containing new
  topology.

20
MPI_DIMS_CREATE

• A helper function for specifying a likely
  dimension decomposition.
• int MPI_Dims_create(int nnodes, int ndims, int
  dims)
• MPI_DIMS_CREATE(NNODES, NDIMS, DIMS, IERROR)
• void MPICompute_dims(int nnodes,int ndims, int
  dims)
• nnodes - total nodes in grid
• ndims - number of dimensions
• dims - array returned with dimensions
• Example
• MPI_Dims_create(6,2,dims) will return (3,2) in
  dims
• MPI_Dims_create(6,3,dims) will return (3,2,1) in
  dims
• No rounding or ceiling function provided

21
Cartesian Inquiry Functions

• MPI_Cartdim_get will return the number of
  dimensions in a cartesian structure
• int MPI_Cartdim_get(MPI_Comm comm, int ndims)
• MPI_Cart_get provides information on an existing
  topology
• Arguments roughly mirror the create call
• int MPI_Cart_get(MPI_Comm comm,int maxdims, int
  dims, int periods, int coords)
• maxdims keeps a given communicator from
  overflowing your arguments

22
Cartesian Translator Functions

• Task IDs in a cartesian coordinate system
  correspond to ranks in a "normal" communicator.
• point-to-point communication routines
  (send/receive) rely on ranks
• int MPI_Cart_rank(MPI_Comm comm, int coords, int
  rank)
• int MPI_Cart_coords(MPI_Comm comm, int rank, int
  maxdims, int coords)
• Coords - cartesian coordinates
• rank - ranks

23
Cartesian Shift function

• int MPI_Cart_Shift(MPI_Comm comm, int direction,
  int disp, int rank_source, int rank_dest)
• direction - coordinate dimension of shift
• disp - displacement (can be positive or negative)
• rank_source and rank_dest are return values
• use that source and dest to call MPI_Sendrecv

24
Remote Memory Access Windows and Window Objects

• MPI-2 provides a facility for remote memory
  access in specified regions
• "one-sided communication" - no need for send and
  receive
• From what I hear, this may not work well yet,
  but...
• MPI_Win_create( base, size, disp_unit, info,
  comm, win)
• exposes memory from base to base(sizesizeof(disp
  _unit) to remote memory access

25
One-Sided Communication Calls

• MPI_Put() - stores into remote memory
• MPI_Get() - reads from remote memory
• MPI_Accumulate() - updates remote memory has an
  op like MPI_Reduce
• All are non-blocking data transfer is described,
  maybe even initiated, but may continue after call
  returns
• Subsequent synchronization is needed to make sure
  operations on window object are complete
  MPI_Win_fence()

26
I/O -(Parallel and Otherwise) on Large Scale
Systems Dan Stanzione Arizona State University
27
Parallel I/O in Data Parallel Programs

• Each task reads a distinct partition of the input
  data and writes a distinct partition of the
  output data.
• Each task reads its partition in parallel
• Data is distributed to the slave nodes
• Each task computes output data from input data
• Each task writes its partition in parallel

28
What Are All These Names?

• MPI - Message Passing Interface Standard
• Also known as MPI-1
• MPI-2 - Extensions to MPI standard
• I/O, RDMA, dynamic processes
• MPI-IO - I/O part of MPI-2 extensions
• ROMIO - Implementation of MPI-IO
• Handles mapping MPI-IO calls into communication
  (MPI) and file I/O

29
Filesystems

• Since each node in a cluster has it's own disk,
  making the same files available on each node can
  be problematic
• Three filesystem options
• Local
• Remote (eg. NFS)
• Parallel (eg. PVFS, LUSTRE)

30
Filesystems (cont.)

• Local - Use storage on each node's disk
• Relatively high performance
• Each node has different filesystem
• Shared datafiles must be copied to each node
• No synchronization
• Most useful for temporary/scratch files accessed
  only by copy of program running on single node
• RANGER DOESNT HAVE LOCAL DISKS
• This trend may continue with other large scale
  systems for reliability reasons
• Very, very small RAMdisk (300MB)

31
Accessing Local File Systems

• I/O system calls on compute nodes are executed on
  the compute node
• File systems on the slave can be made available
  to tasks running there and accessed as on any
  Linux system
• Recommended programming model does not assume
  that a task will run on a specific node
• Best used for temporary storage
• Access permissions may be a problem
• Very small on newer systems like Ranger

32
Filesystems(cont.)

• Remote - Share a single disk among all nodes
• Every node sees same filesystem
• Synchronization mechanisms manage changes
• "Traditional" UNIX approach
• Relatively low performance
• Doesn't scale well server becomes bottleneck in
  large systems
• Simplest solution for small clusters,
  reading/writing small files

33
Accessing Network File Systems

• Network file systems such as NFS and AFS can be
  mounted by slave nodes
• Provides a shared storage space for home
  directories, parameter files, smaller data files
• Performance problems can be severe for a very
  large number of nodes (100)
• Otherwise, works like local file systems

34
Filesystems(cont.)

• Parallel - Stripe files across multiple disks on
  multiple nodes
• Relatively high performance
• Each node sees same filesystem
• Works best for I/O intensive applications
• Not a good solution for small files
• Certain slave nodes are designated I/O nodes,
  local disks used to store pieces of filesystem

35
Accessing Parallel File Systems

• Distribute file data among many I/O nodes
  (servers), potentially every node in the system
• Typically not so good for small files, but very
  good for large data files
• Should provide good performance even for a very
  large degree of sharing
• Critical for scalability in applications with
  large I/O demands
• Particularly good for data parallel model

36
Using File Systems

• Local File Systems
• EXT3, /tmp
• Network File Systems
• NFS, AFS
• Parallel File Systems
• PVFS, LUSTRE, IBRIX,Panasas
• I/O Libraries
• HDF, NetCDF, Panda

37
Example Application for Parallel I/O
Input
Read
Process
Write
Output
38
Issues in Parallel I/O

• Physical distribution of data to I/O nodes
  interacts with logical distribution of the I/O
  requests to affect performance
• Logical record sizes should be considered in
  physical distribution
• I/O buffer sizes depend on physical distribution
  and number of tasks
• Performance is best with rather large requests
• Buffering should be used to get requests of 1MB
  or more, depending on the size of the system

39
I/O Libraries

• May make I/O simpler for certain applications
• Multidimensional data sets
• Special data formats
• Consistent access to shared data
• "Out-of-core" computation
• May hide some details of parallel file systems
• Partitioning
• May provide access to special features
• Caching, buffering, asynchronous I/O, performance

40
MPI-IO

• Common file operations
• MPI_File_open()
• MPI_File_close()
• MPI_File_read()
• MPI_File_write()
• MPI_File_read_at()
• MPI_File_write_at()
• MPI_File_read_shared()
• MPI_File_write_shared()
• Open, close are collective. The rest have
  collective counterparts add _all

41
MPI_File_open

• MPI_File_open(
• MPI_Comm comm,
• char filename,
• int amode,
• MPI_Info info,
• MPI_File fh)
• Collective operation on comm
• amode similar to UNIX file mode a few extra MPI
  possibilities

42
MPI_File_close

• MPI_File_close(
• MPI_File fh
• )

43
File Views

• File views supported
• MPI_File_set_view()
• Essentially, a file view allows you to change
  your program's treatment of a file as simply a
  stream of bytes, to viewing the file as a set of
  MPI_Datatypes and displacements.
• Arguments to set view are similar to the
  arguments for creating derived datatypes

44
MPI_File_read

• MPI_File_read(
• MPI_File fh,
• void buf,
• int count,
• MPI_Datatype datatype,
• MPI_Status status
• )

45
MPI_File_read_at

• MPI_File_read_at(
• MPI_File fh,
• MPI_Offset offest,
• void buf,
• int count,
• MPI_Datatype datatype,
• MPI_Status status
• )
• MPI_File_read_at_all() is the collective version

46
Non-Blocking I/O

• MPI_File_iread()
• MPI_File_iwrite()
• MPI_File_iread_at()
• MPI_File_iwrite_at()
• MPI_File_iread_shared()
• MPI_File_iwrite_shared()

47
MPI_File_iread

• MPI_File_iread(
• MPI_File fh,
• void buf,
• int count,
• MPI_Datatype datatype,
• MPI_Request request
• )
• Request structure can be queried to determine if
  the operation is complete

48
Collective access

• The shared routines use a collective file
  pointer
• Collective routines also provided to allow each
  task to read/write a specific chunk of the file
• MPI_File_read_ordered(MPI_File fh, void buf, int
  count, MPI_Datatype type, MPI_Status st)
• MPI_File_write_ordered()
• MPI_File_seek_shared()
• MPI_File_read_all()
• MPI_File_write_all()

49
File Functions

• MPI_File_delete()
• MPI_File_set_size()
• MPI_File_preallocate()
• MPI_File_get_size()
• MPI_File_get_group()
• MPI_File_get_amode()
• MPI_File_set_info()
• MPI_File_get_info()

50
ROMIO MPI-IO Implementation

• Implementation of MPI-2 I/O specification
• Operates on wide variety of platforms
• Abstract Device Interface for I/O (ADIO) aids in
  porting to new file systems
• Fortran and C bindings
• Successes
• Adopted by industry (e.g. Compaq, HP, SGI)
• Used at ASCI sites (e.g. LANL Blue Mountain)

51
Data Staging for Tiled Display

• Commodity components
• projectors, PCs
• Provide very high resolutionvisualization
• Staging application splitsframes into a tile
  stream foreach visualization node
• Uses MPI-IO to access data from PVFS file system
• Streams of tiles are merged into movie files on
  visualization node

52
Splitting Movie Frames into Tiles

• Hundreds of frames make up a single movie
• Each frame is stored in its own file in PVFS
• Frame size is 2532x1408 pixels
• 3x2 display
• Tile size is 1024x768 pixels (overlapped)

53
Obtaining Highest Performance

• To make best use of PVFS
• Use MPI-IO (ROMIO) for data access
• Use file views and datatypes
• Take advantage of collectives
• Use hints to optimize for your platform
• Simple, right )?

54
Trivial MPI-IO Example

• Reading contiguous pieces with MPI-IO calls
• Simplest, least powerful way to use MPI-IO
• Easy to port from POSIX calls
• Lots of I/O operations to get desired data

MPI_File_open(comm, fname, MPI_MODE_RDONLY, MPI_I
NFO_NULL, handle) / read tile data from one
frame / for (row 0 row lt 768 row)
offset rowrow_size tile_offset
header_size MPI_File_read_at(handle, offset,
buffer, 10243, MPI_BYTE, status) MPI_File_
close(handle)
55
Avoiding the VFS Layer

• UNIX calls go through VFS layer
• MPI-IO calls use Filesystem library directly
• Significant performance gain

56
Why Use File Views?

• Concisely describe noncontiguous regions in a
  file
• Create datatype describing region
• Assign view to open file handle
• Separate description of region from I/O operation
• Datatype can be reused on subsequent calls
• Access these regions with a single operation
• Single MPI read call requests all data
• Provides opportunity for optimization of access
  in MPI-IO implementation

57
Setting a File View

• Use MPI_Type_create_subarray() to define a
  datatype describing the data in the file
• Example for tile access (24-bit data)

MPI_Type_contiguous(3, MPI_BYTE,
rgbtype) frame_size1 2532 / frame width
/ frame_size0 1408 / frame height
/ tile_size1 1024 / tile width
/ tile_size0 768 / tile height / /
create datatype describing tile
/ MPI_Type_create_subarray(2, frame_size,
tile_size, tile_offset, MPI_ORDER_C, rgbtype,
tiletype) MPI_Type_commit(tiletype) MPI_File_
set_view(handle, header_size, rgbtype, tiletype,
native, MPI_INFO_NULL) MPI_File_read(handle,
buffer, buffer_size, rgbtype, status)
58
Noncontiguous Access in ROMIO

• ROMIO performs data sieving to cut down number
  of I/O operations
• Uses large reads which grab multiple
  noncontiguous pieces
• Example, reading tile 1

59
Data Sieving Performance

• Reduces I/O operations from 4600 to 6
• 87 effective throughput improvement
• Reading 3 times as much data as necessary

60
Collective I/O

• MPI-IO supports collective I/O calls (_all
  suffix)
• All processes call the same function at once
• May vary parameters (to access different regions)
• More fully describe the access pattern as a whole
• Explicitly define relationship between accesses
• Allow use of ROMIO aggregation optimizations
• Flexibility in what processes interact with I/O
  servers
• Fewer, larger I/O requests

61
Collective I/O Example

• Single line change

/ create datatype describing tile
/ MPI_Type_create_subarray(2, frame_size,
tile_size, tile_offset, MPI_ORDER_C, rgbtype,
tiletype) MPI_Type_commit(tiletype) MPI_File_
set_view(handle, header_size, rgbtype, tiletype,
native, MPI_INFO_NULL) if 0 MPI_File_read(han
dle, buffer, buffer_size, rgbtype,
status) endif / collective read
/ MPI_File_read_all(handle, buffer, buffer_size,
rgbtype, status)
62
Two-Phase Access

• ROMIO implements two-phase collective I/O
• Data is read by clients in contiguous pieces
  (phase 1)
• Data is redistributed to the correct client
  (phase 2)
• ROMIO applies two-phase when collective accesses
  overlap between processes
• More efficent I/O access than data sieving alone

63
Two-Phase Performance

• Often a big win

64
Hints

• Controlling PVFS
• striping_factor - size of strips on I/O servers
• striping_unit - number of I/O servers to stripe
  across
• start_iodevice - which I/O server to start with
• Controlling aggregation
• cb_config_list - list of aggregators
• cb_nodes - number of aggregators (upper bound)
• Tuning ROMIO optimizations
• romio_cb_read, romio_cb_write - aggregation
  on/off
• romio_ds_read, romio_ds_write - data sieving
  on/off

65
The Proof is in the Performance

• Final performance is almost 3 times VFS access!
• Hints allowed us to turn off two-phase, modify
  striping of data

66
A More Sophisticated I/O Example

• Dividing a 2D Matrix with Ghost Rows

67
File - on Disk vs. in Memory
Partition on one processor (with ghost rows on
borders)
Full Dataset
68
includeltstdio.hgt includeltmpi.hgt main(int argc,
char argv) int gsizes2,psizes2,lsi
zes2,memsizes2 int
dims2,periods2,coords2,start_indices2
MPI_Comm comm MPI_Datatype filetype,
memtype MPI_File fh MPI_Status status
int local_array1212 int rank, m, n
m20 n30 gsizes0m
gsizes1n psizes02 psizes13
lsizes0 m/psizes0 / Rows in local
array / lsizes1 m/psizes1 / Cols
in local array / dims02 dims13
periods0periods1 1
MPI_Init(argc,argv) MPI_Cart_create(MPI
_COMM_WORLD, 2, dims, periods, 0, comm)
MPI_Comm_rank(comm, rank)
69
MPI_Cart_coords(comm, rank, 2, coords)
start_indices0 coords0 lsizes0
start_indices1 coords1 lsizes1
MPI_Type_create_subarray(2, gsizes, lsizes,
start_indices, MPI_ORDER_C,
MPI_FLOAT, filetype) MPI_Type_commit(fi
letype) MPI_File_open(MPI_COMM_WORLD,
"datafile", MPI_MODE_CREATE
MPI_MODE_WRONLY, MPI_INFO_NULL, fh)
MPI_File_set_view(fh,0, MPI_CHAR, filetype,
"native", MPI_INFO_NULL) memsizes0
lsizes0 2 memsizes1 lsizes1
2 start_indices0 start_indices1
1 MPI_Type_create_subarray(2, memsizes,
lsizes, start_indices, MPI_ORDER_C,
MPI_CHAR, memtype) MPI_Type_commit(me
mtype) MPI_File_write_all(fh,
local_array, 1, memtype, status)
MPI_File_close(fh)
70
Summary Why Use MPI-IO?

• Better concurrent access model than POSIX one
• Explicit list of processes accessing concurrently
• More lax (but still very usable) consistency
  model
• More descriptive power in interface
• Derived datatypes for concise, noncontiguous file
  and/or memory regions
• Collective I/O functions
• Optimizations built into MPI-IO implementation
• Noncontiguous access
• Collective I/O (aggregation)
• Performance portability

71
Optional, Really Advanced Stuff

• Dynamic Process Management
• Intercommunicator communication
• MPI external connections

72
Creating Communicators

• int MPI_Comm_dup(MPI_Comm comm, MPI_Comm
  newcomm)
• MPIIntracomm MPIIntracommDup() const
• MPIIntercomm MPIIntercommDup() const
• MPICartcomm MPICartcommDup() const
• MPIGraph comm MPIGraphcommDup() const
• Creates an exact copy of the communicator

73
Creating Communicators

• int MPI_Comm_create(MPI_Comm comm, MPI_Group
  group, MPI_Comm newcomm)
• MPIIntracomm MPIIntracommcreate(...) const
• MPIIntercomm MPIIntercommcreate(...) const
• Creates a new communicator with the contents of
  group
• Group must be a subset of Comm
• Int MPI_Comm_split(comm,color,key,newcomm)

74
Destroying Communicators

• int MPI_Comm_free(MPI_Comm comm)
• void MPICommFree()
• Destroys the named communicator

75
Dynamic Process Management

• Create new processes from running programs (as
  opposed to with MPIrun)
• MPI_Comm_spawn
• (for SPMD style programs)
• MPI_Comm_spawn_multiple
• (MPMD style programs)
• Connecting two (or more) applications together
• MPI_Comm_accept and MPI_Comm_connect
• Useful in assembling complex distributed
  applications

76
Dynamic Process Management

• Issues
• maintaining simplicity, flexibility, and
  correctness
• interaction with OS, resource manager, and
  process manager
• connecting independently started processes
• Spawning new processes is collective, returning
  an intercommunicator
• Local group is group of spawning processes.
• Remote group is group of new processes
• New processes have own MPI_COMM_WORLD
• MPI_Comm_get_parent lets new processes find
  parent communicator

77
Intercommunicators

• Contain a local group and a remote group
• Point-to-point communication is between a process
  in one group and a process in the other
• Can be merged into a normal communicator
• Created by MPI_Intercomm_create()

78
Spawning Processes

• int MPI_Comm_spawn(command, argv, numprocs, info,
  root, comm, intercomm, errcodes)
• Tries to start numprocs process running command,
  passing them command line arguments argv
• The operation is collective over comm
• Spawnees are in remote group of intercomm
• Errors are reported on a per-process basis in
  errcodes
• Info used to optionally specify hostname,
  archname, etc...

79
Spawning Multiple Executables

• MPI_Comm_spawn_multiple(...)
• Arguments command, argv, numprocs, info all
  become arrays
• Still Collective

80
Establishing Connections

• MPI-2 makes it possible for two MPI jobs started
  separately to establish communication
• e.g. visualizer connecting to simulation
• Connection results in an intercommunicator
• Client/server architecture
• Similar to TCP Sockets programming

81
Establishing Connections

• Server
• MPI_Open_port(info, port_name)
• MPI_Comm_accept(port_name, info,root, comm,
  intercomm)
• Client
• MPI_Comm_connect( port_name, info, root, comm,
  intercomm)
• Optional name service (like normal UNIX)
• MPI_Publish_name( ... )
• MPI_Lookup_name( ... )
• (not sure if name service is implemented)
