Fundamentals of Nucleic Acid Biochemistry RNA

• Donna Sullivan, PhD
• Division of Infectious Diseases
• University of Mississippi Medical Center

2
DNA AND RNA BASIC STRUCTURE
3
Repeating Nucleotide Subunits In DNA and RNA
4
STRUCTURE OF RNA

• SUGAR
• Ribose
• Phosphate group
• Nitrogen containing base
• Adenine
• Guanine
• Cytosine
• Uracil

5
THE NUCLEOTIDE RNA
OH OP-O-5CH2
BASE OH O
4C 1C H
H H H
3C 2C
OH 0H

Adenine Guanine Cytosine Uracil
6
The Forms Of RNA Not Just Another Helix

• Does not normally exist as a double helix,
  although it can under some conditions
• Can have secondary structure
• Hairpins pairing of bases within 5-10 nt
• Stem-loops pairing of bases separated by gt50 nt
• Can have tertiary structure
• Pseudoknot, cloverleaf

7
RNA Structures
8
Structure Of RNA
9
Structure of tRNA
10
Structure of rRNA
11
RNA Replication vs. DNA Replication

• RNA replication
• Requires no priming
• Has many more initiation sites
• Is slower (50100 b/sec vs. 1000 b/sec)
• Has lower fidelity
• Is more processive

12
Transcription

• Transcription is the enzyme-dependent process of
  generating RNA from DNA.
• The process is catalyzed by a DNA-dependent RNA
  polymerase enzyme.
• Only coding segments of DNA (genes) are
  transcribed.
• Types of genes include structural genes (encode
  protein), transfer RNA (tRNA), and ribosomal RNA
  (rRNA).

13
Transcription

• Transition from DNA to RNA
• Initiation Gene recognition
• RNA polymerase enzyme and DNA form a stable
  complex at the gene promoter.
• Promoter Specific DNA sequence that acts as a
  transcription start site.
• Synthesis of RNA proceeds using DNA as a
  template.
• Only one strand (coding strand) is transcribed,
  the other strand has structural function.
• Transcription factors are proteins that function
  in combination to recognize and regulate
  transcription of different genes.
• Termination signal

14
(No Transcript)
15
RNA POLYMERASES

• Cellular RNA polymerase
• RNA pol I transcribes rRNA genes
• RNA pol II transcribes protein encoding genes
• RNA pol III transcribes tRNA genes
• Viral RNA polymerases
• Reverse transcriptase of retroviruses
• RNA dependent RNA polymerases of negative
  stranded viruses

16
RNA Polymerase Enzymes(DNA-dependent RNA
Polymerase)

• RNA Polymerase I transcribes most rRNA genes (RNA
  component of ribosomes).
• RNA Polymerase II transcribes structural genes
  that encode protein.
• RNA Polymerase III transcribes tRNA genes (for
  transfer RNAs).
• RNA Polymerase IV is the mitochondrial RNA
  polymerase enzyme.

17
(No Transcript)
18
RNA TRANSCRIPTION
19
General Organization of a Eukaryotic Gene
Promoter/Enhancer
20
Gene Structure
21
Nuclear Processing of RNA

• Chemical modification reactions (addition of the
  5 CAP)
• Splicing reactions (removal of intronic
  sequences)
• Polyadenylation (addition of the 3 polyA tail)

22
Processing of mRNA

• In eukaryotes, the mRNA molecule that is released
  after transcription is called precursor mRNA or
  pre-mRNA.
• It undergoes several changes before being
  exported out of the nucleus as mRNA.

23
Processing of mRNA

• 5 end is capped with a modified form of the G
  nucleotide known as the 5 cap
• At the 3 end, an enzyme adds a long series of A
  nucleotides referred to as a poly-A tail
• It serves to protect the mRNA from enzymes in the
  cytoplasm that may break it down
• The greater the length of the poly-a tail, the
  more stable the mRNA molecule

24
RNA Transcription and Processing

• The process of RNA transcription results in the
  generation of a primary RNA transcript (hnRNA)
  that contains both exons (coding segments) and
  introns (noncoding segments).
• The noncoding sequences must be removed from the
  primary RNA transcript during RNA processing to
  generate a mature mRNA transcript that can be
  properly translated into a protein product.

25
RNA Processing

• Capping of the 5-end of mRNA is required for
  efficient translation of the transcript (special
  nucleotide structure).
• Polyadenylation at the 3-end of mRNA is thought
  to contribute to mRNA stability (PolyA tail).
• Once processed, the mature mRNA exits the nucleus
  and enters the cytoplasm where translation takes
  place.

26
RNA ProcessingBiogenesis of Mature mRNA
27
RNA ProcessingFundamentals of RNA Splicing
28
RNA Processing Spliceosomes

• Ribonucleoproteins (snRNPs) function in RNA
  processing to remove intronic sequences from the
  primary RNA transcript (intron splicing).
• Alternative splicing allows for the generation of
  different mRNAs from the same primary RNA
  transcript by cutting and joining the RNA strand
  at different locations.
• snRNPs are composed of small RNA molecules and
  several protein molecules.
• Five subunits form the functional spliceosome.

29
RNA ProcessingAlternative Splicing of RNA
30
Structural Genes Encode Proteins

• The majority of structural genes in the human
  genome are much larger than necessary to encode
  their protein product.
• Structural genes are composed of coding and
  noncoding segments of DNA.

31
Structural Genes Encode Proteins

• The structure of a typical human gene includes
  informational sequences (coding segments termed
  exons) interrupted by noncoding segments of DNA
  (termed introns).
• The exon-introncontaining regions of genes are
  flanked by non transcribed segments of DNA that
  contribute to gene regulation.

32
Factors That Control Gene Expression Include

• Cis elements are DNAsequences.
• Trans elementsare proteins.

33
Control of Gene Expression

• Primary level of control is regulation of gene
  transcription activity.
• TATA box contained within the gene promoter
  provides binding sites for RNA polymerase.
• Enhancer sequences can be sited very far away
  from the gene promoter and provide for
  tissue-specific patterns of gene expression.

34
Gene Enhancer Sequences
35
Protein binding sequences in the Promoter region
36
Gene Regulation Two types of regulation

• Negative regulation
• Substrate induction (lac operon) gene OFF unless
  substrate is present
• End product repression (trp operon) gene OFF if
  end product is present
• Common in bacteria
• Positive regulation
• Gene is OFF until a protein turns it ON
• Regulatory proteins turn gene ON
• Occurs in eukaryotes

37
Negative Regulation
38
Positive Regulation
39
Lac Operon

• Operon
• Gene organization in bacteria in which several
  proteins are coded by one mRNA
• Allows all proteins to be controlled together

40
Differences Between Prokaryotes And Eukaryotes

• Prokaryote gene expression typically is regulated
  by an operon, the collection of controlling sites
  adjacent to protein-coding sequence.
• Eukaryotic genes also are regulated in units of
  protein-coding sequences and adjacent controlling
  sites, but operons are not known to occur.
• Eukaryotic gene regulation is more complex
  because eukaryotes possess a nucleus
  (transcription and translation are not coupled).

41
Two Categories Of Eukaryotic Gene Regulation

• Short-term - genes are quickly turned on or off
  in response to the environment and demands of the
  cell.
• Long-term - genes for development and
  differentiation.

42
Eukaryote Gene Expression Is Regulated At Six
Levels

• Transcription
• RNA processing
• mRNA transport
• mRNA translation
• mRNA degradation
• Protein degradation

43
Transcription Control Of Gene Regulation
Controlled By Promoters

• Occur upstream of the transcription start site.
• Some determine where transcription begins (e.g.,
  TATA), whereas others determine if transcription
  begins.
• Promoters are activated by highly specialized
  transcription factor (TF) proteins (specific TFs
  bind specific promoters).
• One or many promoters (each with specific TF
  proteins) may occur for any given gene.
• Promoters may be positively or negatively
  regulated.

44
Transcription Control Of Gene Regulation
Controlled By Enhancers

• Occur upstream or downstream of the transcription
  start site.
• Regulatory proteins bind specific enhancer
  sequences binding is determined by the DNA
  sequence.
• Loops may form in DNA bound to TFs and make
  contact with enhancer elements.
• Interactions of regulatory proteins determine if
  transcription is activated or repressed
  (positively or negatively regulated).

45
Chromosome Structure, Eukaryote Chromosomes, And
Histones

• Prokaryotes lack histones and other structural
  proteins, so access to the DNA is
  straightforward.
• Eukaryotes possess histones, and histones repress
  transcription because they interfere with
  proteins that bind to DNA.
• Verified by DNase I sensitivity experiments
• DNase I readily degrades transcriptionally active
  DNA.
• Histones shield non-transcribed DNA from DNase I,
  and DNA does not degrade as readily.

46
Chromosome Structure, Eukaryote Chromosomes, And
Histones

• If you experimentally add histones and promoter
  binding proteins histones competitively bind to
  promoters and inhibit transcription.
• Solution transcriptionally active genes possess
  looser chromosome structures than inactive genes.
• Histones are acetylated and phosphorylated,
  altering their ability to bind to DNA.
• Enhancer binding proteins competitively block
  histones if they are added experimentally with
  histones and promoter-binding TFs.
• RNA polymerase and TFs step-around the
  histones/nucloesome and transcription occurs.

47
Genomic Imprinting(Silencing)

• Methylation of DNA inhibits transcription of some
  genes.
• Methylation usually occurs on cytosines or
  adenines.
• 5-methyl cytosine
• N-6 methyl adenine
• N-4 methyl cytosine
• CpG islands are sites of methylation in human
  DNA.
• CpG Island

ggaggagcgcgcggcggcggccagagaaaaa gccgcagcggcgcgcg
cgcacccggacagccgg cggaggcggg...
48
DNA Methylation And Transcription Control

• Small percentages of newly synthesized DNAs (3
  in mammals) are chemically modified by
  methylation.
• Methylation occurs most often in symmetrical CG
  sequences.
• Transcriptionally active genes possess
  significantly lower levels of methylated DNA than
  inactive genes.
• A gene for methylation is essential for
  development in mice (turning off a gene also can
  be important).
• Methylation results in a human disease called
  fragile X syndrome FMR-1 gene is silenced by
  methylation.

49
Hormone Regulation Example Of Short-term
Regulation Of Transcription

• Cells of higher eukaryotes are specialized and
  generally shielded from rapid changes in the
  external environment.
• Hormone signals are one mechanism for regulating
  transcription in response to demands of the
  environment.
• Hormones act as inducers produced by one cell and
  cause a physiological response in another cell.

50
Hormone Regulation Example Of Short-term
Regulation Of Transcription

• Hormones act only on target cells with hormone
  specific receptors, and levels of hormones are
  maintained by feedback pathways.
• Hormones deliver signals in two different ways
• Steroid hormones pass through the cell membrane
  and bind cytoplasmic receptors, which together
  bind directly to DNA and regulate gene
  expression.
• Polypeptide hormones bind at the cell surface and
  activate transmembrane enzymes to produce second
  messengers (such as cAMP) that activate gene
  transcription.

51
Examples Of Mammalian Steroid Hormones
52
Hormone Regulation

• Genes regulated by steroid hormones possess
  binding regions in the sequence called steroid
  hormone response elements (HREs).
• HREs often occur in multiple copies in enhancer
  sequence regions.
• When steroid is absent Receptor is bound and
  guarded by chaperone proteins transcription
  does not occur.
• When steroid is present Steroid displaces the
  chaperone protein, binds the receptor, and binds
  the HRE sequence transcription begins.

53
Model Of Glucocorticoid Steroid Hormone Regulation
54
RNA Processing Control

• RNA processing regulates mRNA production from
  precursor RNAs.
• Two independent regulatory mechanisms occur
• Alternative polyadenylation where the polyA
  tail is added
• Alternative splicing which exons are spliced
• Alternative polyadenylation and splicing can
  occur together.
• Examples
• Human calcitonin (CALC) gene in thyroid and
  neuronal cells
• Sex determination in Drosophila

55
Alternative Polyadenylation And Splicing Of The
Human CACL Gene In Thyroid And Neuronal Cells
56
mRNA Transport Control

• Eukaryote mRNA transport is regulated.
• Some experiments show 1/2 of primary transcripts
  never leave the nucleus and are degraded.
• Mature mRNAs exit through the nuclear pores.

57
mRNA Transport Control

• Unfertilized eggs are an example, in which mRNAs
  (stored in the egg/no new mRNA synthesis) show
  increased translation after fertilization).
• Stored mRNAs are protected by proteins that
  inhibit translation.
• Poly(A) tails promote translation.
• Stored mRNAs usually have short poly(A) tails
  (15-90 As vs 100-300 As).
• Specific mRNAs are marked for deadenylation
  (tail-chopping) prior to storage by AU-rich
  sequences in 3-UTR.
• Activation occurs when an enzyme recognizes
  AU-rich element and adds 150 As to create a full
  length poly(A) tail.

58
mRNA Degradation Control

• All RNAs in the cytoplasm are subject to
  degradation.
• tRNAs and rRNAs usually are very stable mRNAs
  vary considerably (minutes to months).
• Stability may change in response to regulatory
  signals and is thought to be a major regulatory
  control point.
• Various sequences and processes affect mRNA
  half-life
• AU-rich elements
• Secondary structure
• Deadenylation enzymes remove As from poly(A) tail
• 5 de-capping
• Internal cleavage of mRNA and fragment degradation

59
Post-translational Control - Protein Degradation

• Proteins can be short-lived (e.g., steroid
  receptors) or long-lived (e.g., lens proteins in
  your eyes).
• Protein degradation in eukaryotes requires a
  protein co-factor called ubiquitin.
• Ubiquitin binds to proteins and identifies them
  for degradation by proteolytic enzymes.
• Amino acid at the N-terminus is correlated with
  protein stability and determines rate of
  ubiquitin binding.
• Arg, Lys, Phe, Leu, Trp 1/2 life 3 minutes
• Cys, Ala, Ser, Thr, Gly, Val, Pro, Met 1/2 life
  20 hours

60
Epigenetics

• Non-sequence specific, heritable traits
• Transcriptional gene silencing (TGS)
• Imprinting
• X-inactivation
• RNA-induced transcriptional silencing (RITS)
• Post-transcriptional gene silencing (PTGS)
• RNA-induced silencing complex (RISC)
• G quartets
• Post-translational protein-protein interactions

61
RNAi

• First described in C. elegans
• Injecting antisense RNA into oocytes (ssRNA that
  is complementary to mRNA)
• Silences gene expression
• Also injected dsRNA into oocytes found it was 10X
  more potent in inhibiting expression
• Term RNAi

62
RNAi

• Higher eukaryotes produce a class of small RNAs
  that mediate silencing of some genes
• Small RNAs interact with mRNA in the 3UTR and
  this results in either mRNA degradation or
  translation inhibition
• Controls developmental timing in at least some
  organisms
• Used as a mechanism to protect against invading
  RNA viruses (plants)
• Controls the activity of transposons
• Formation of heterochromatin

63
Mechanism of RNA Interference
Step 1
Step 2
Nat Rev Genet. 2002 Oct3(10)737-47. Review.
64
Epigenetics

• The study of mechanisms by which genes bring
  about their phenotypic effects
• Epigenetic changes influence Phenotype without
  altering Genotype
• Changes in properties of a cell that are
  inherited but dont represent a change in genetic
  information.

65
A Histone Code?

• Modifications of histones (usually the amino
  terminal tails) convey epigenetic information
• Types of modifications
• Acetylation and methylation of lysine.
• Methylation of arginine
• Phosphorylation of serine
• Ubiquitination of lysine.
• The histone code hypothesis posits that serial
  modifications provide a blueprint for reading
  chromatin -for transcription, replication,
  repair, and recombination.

66
Remodeling Nucleosomes

• Changing the way nucleosomes bind to the DNA in
  chromosomes is important to allow access to the
  underlying DNA sequences during DNA replication,
  repair, recombination, and transcription.
• This occurs in three general ways
• Modification of the lys and Arg residues on the
  histone tails decreases the grip of the
  nucleosome on DNA and causes the nucleosome to
  slide more easily.
• Variant histones are added to pre-existing
  nucleosomes
• ATP-dependent protein remodelingcomplexes cause
  nucleosomes to dissociate and/or slide along the
  DNA.
