Tool Identification

1
Tool Identification

• By Johnny M. Jessup
• Agriculture Instructor/FFA Advisor

2
Adjustable Wrench

• Turning various size nuts and bolts.

3
Allen Wrench

• Turning hex head socket screws.

4
Aviation Snips

• Cutting sheet metal.

5
Ball Pein Hammer

• Hammering metal.

6
Bar Clamp

• Clamping large sections of wood together.

7
Bent Nose Pliers

• Reaching obstructive or awkward places.

8
Bolt Cutters

• Cutting bolts steel rods.

9
Bolt Die

• Cutting threads on bolts and rods.

10
Bolt Die Stock

• Holder for bolt tie.

11
Bolt Tap

• Cutting inside threads.

12
Box End Wrench

• Turning hex head nuts and bolts.

13
Brick Jointer

• Smoothing and designing masonry joints.

14
Brick Trowel

• Placing and spreading mortar.

15
Bulb Planter

• Planting and transplanting bulbs.

16
Bush Axe

• Cutting bushes and under
  growth.

17
Butt Hinge

• Hinge for narrow fencing.

18
C Clamp

• Clamping two or more pieces of metal together.

19
Carriage Bolt

• Bolting wood to wood or wood to metal.

20
Castrator

• Tool for sterilizing male animals.

21
Center Punch

• Starting holes in metal.

22
Chain Saw File

• Sharpening chain saw file.

23
Chalk Line Reel

• Making straight lines.

24
Chipping Hammer

• Removing slag from welds.

25
Circuit Breaker

• Protection from overload in electrical circuits.

26
Circular Carbide Saw Blade

• Blade used on portable electric saw.

27
Cold Chisel

• Cutting metal.

28
Combination Oil Stone

• For sharpening and honing cutting tools.

29
Combination Square

• Determining 45o and 90o angles.

30
Combination Wrench

• Turning hex and square nuts and bolts.

31
Common Nail

• Nailing boards together where holding
  power is desired.

32
Compass

• Drawing circles.

33
Compass Saw

• Cutting wood in close places.

34
Concrete Finishing Trowel

• Smoothing concrete.

35
Concrete Float

• Leveling concrete.

36
Coping Saw

• Cutting curves and irregular cuts.

37
Cordless Drill

• Drilling holes with a tool that uses a battery
  pack.

38
Countersink

• Flaring top of hole for recessing head for
  flathead screw or bolt.

39
Cutting Torch

• Cutting metal with heat.

40
Deep Socket

• Turning nuts and bolts in depressed areas.

41
Dehorner

• Removing horns from cattle.

42
Diagonal Cutting Pliers

• Surface and diagonal wire cutting.

43
Drift Punch

• Aligning holes.

44
Drill Press Vise

• Holding stock while drilling.

45
Duplex Receptacle

• To plug electrical units.

46
Dust Mask

• Protects the respiratory system from airborne
  particles.

47
Ear Tagger

• Labels individual animals for identification.

48
Electrical Multimeter

• Performs various tests on electrical circuits.

49
Emery Dresser

• Smoothing face of grinding wheel.

50
End Cutting Nippers

• Cutting ends of wire, nails and small bolts.

51
Expansion Shield

• Anchoring a lag screw into concrete, brick or
  block.

52
Extension

• Extends reach of socket.

53
Eye Bolt

• Bolt used to attach wire onto.

54
Fence Pliers

• Building and repair of wire fences.

55
Fence Staple

• For nailing up fence.

56
File Card

• Cleaning cutting grooves of file.

57
Finishing Nail

• Nailing boards where head will not be noticed.

58
Flaring Tool

• Flaring ends of tubing.

59
Flathead Stove Bolt

• Fastening wood to metal/metal to metal with
  wrench leaving a flat surface.

60
Flathead Wood Screw

• Fastening wood to wood where a flat surface is
  required.

61
Framing Square

• Squaring cut corners and laying out stairs and
  rafters.

62
Fuse Puller

• Removing cartridge fuses.

63
Gate Valve

• Cutting off water supply on a main line.

64
Glass Cutter

• Cutting glass.

65
Grafting Tool

• Preparing woody parts for grafting.

66
Grease Gun

• Lubricating through grease fitting.

67
Groove Joint Pliers

• Gripping when greater pressure is needed.

68
Hack Saw

• Sawing metal.

69
Half Hatchet

• Cutting and fitting wood.

70
Half Round File

• Curve and flat filing.

71
Hammer Drill

• Power drilling in concrete, brick or block.

72
Hand Screw Clamp

• Clamping wood together.

73
Hedge Shears

• Trimming and shaping hedge.

74
Hinge Handle

• Socket handle to be used when flexibility is
  needed.

75
Hose Bib

• Valve for attaching a water hose turning water
  supply on or off.

76
Implant Gun

• Injects growth hormones in animals.

77
Impulse Sprinkler

• Overhead irrigation of plants where rotation is
  water driven.

78
Increment Borer

• Checking growth rate of trees.

79
Junction Box

• Join several electrical wires into a circuit.

80
Lag Screw

• Screw used where great pressure to turn is
  required.

81
Level

• Leveling and plumbing.

82
Line Level

• Leveling between long distance points.

83
Long Nose Pliers

• Reaching into recessed areas.

84
Lopping Shears

• Cutting large braches when pruning shrubbery.

85
Machine Bolt

• Fastening metal to metal with a wrench.

86
Machinists Vise

• Holding metal firm while working.

87
Mason Hammer

• Chipping and shaping masonry material.

88
Mason Level

• Leveling and plumbing masonry materials.

89
Masonry Bit

• Boring a hole in concrete, brick, or block.

90
Masonry Nail

• Nailing in concrete, brick, or block.

91
Mill File

• Filing metal.

92
Miter Box

• Cutting angles.

93
Nail Hammer

• Driving nails.

94
Nail Set

• Countersinking nail heads.

95
Nailing Gun

• Rapid nailing using air, gas, or electricity.

96
Nut Driver

• Socket permanently attached to a handle for
  turning small nuts and bolts.

97
Obstruction Wrench

• Reaching nuts and bolts around obstructions.

98
Open End Wrench

• Turning square head nuts and bolts.

99
Phillips Screwdriver

• Turning phillips heads screws.

100
Pin Punch

• Driving out metal pins.

101
Pipe Bushing

• Reducing pipe size.

102
Pipe Cap

• Closing the end of a pipe by going over the pipe
  end.

103
Pipe Coupling

• Joining two pieces of pipe.

104
45o Pipe Elbow

• Making a 45 degree turn with a pipe.

105
90o Pipe Elbow

• Making a 90 degree turn with a pipe.

106
Pipe Nipple

• Adding length to apiece of pipe.

107
Pipe Plug

• Closing the end of a pipe, threads on inside.

108
Pipe Reducer

• Reducing galvanized pipe size, threads on inside.

109
Pipe Stop Waste

• Turning off water and draining line.

110
Pipe Tee

• Joining at 90o angles.

111
Pipe Union

• Joining two pieces of galvanized pipe where
  neither side can be turned.

112
Pipe Wrench

• Turning and holding metal pipe.

113
Piston Ring Compressor

• Compressing ring for inserting into cylinder.

114
Planting Bar

• Setting out tree seedlings.

115
Plumb Bob

• Vertical plumbing to locate points.

116
Portable Circular Saw

• Sawing wood in construction projects.

117
Portable Electric Drill

• Drilling holes with an external source of power.

118
Portable Jig Saw

• Making irregular cuts.

119
Portable Electric Sander

• Power tool used for smoothing surface.

120
Pruning Saw

• Sawing limbs from shrubbery and trees.

121
Pruning Shears

• Cutting and shaping shrubbery.

122
Putty Knife

• Applying and smoothing putty.

123
PVC Cutter

• Cutting non-metallic pipe.

124
Regular Socket

• General purpose socket for turning nuts and bolts.

125
Reversible Ratchet

• Reverse rotation of socket turning.

126
Roofing Nail

• Nailing tin, aluminum, fiberglass or asphalt
  roofing.

127
Round File

• Filing round holes.

128
Roundhead Stove Bolt

• Fastening wood or or metal to metal with a
  screwdriver or wrench.

129
Roundhead Wood Screw

• Fastening wood to wood.

130
Router

• Making edges or designs in wooden surfaces.

131
Rubber Mallet

• Hammering to avoid marring surface.

132
Safety Glasses

• Protects eyes from the impact of foreign objects.

133
Safety Goggles

• Protects eyes from liquids and vapors.

134
Screw Extractor

• Removing broken bolts, studs, and screws.

135
Screwmate

• Drills and countersinks flat head wood screw
  holes.

136
Sheet Metal Screw

• Joining two pieces of sheet metal.

137
Side Cutting Pliers

• Holding and/or cutting wire.

138
Sledge Hammer

• Heavy hammering.

139
Slip Joint Pliers

• Adjust for holding various size material.

140
Slotted Screwdriver

• Turning slotted screwdriver.

141
Solderless Wire Nut

• Joining two or more electrical wires.

142
Soil Auger

• Boring into soil to get samples.

143
Soil Thermometer

• Determining soil temperature.

144
Soil Tube

• Obtaining soil for testing.

145
Soldering Gun

• Melting solder.

146
Spark Plug Gauge

• Gauge and set spark plug gap.

147
Spark Plug Socket

• Install and remove spark plugs.

148
Speed Bore Bit

• Wood boring bit for electric drill.

149
Speed Handle

• Rapid turning of socket.

150
Straight Shank Drill Bit

• Drilling metal.

151
Strap Hinge

• Hinge used where major strength or support is
  required.

152
90o Street Elbow

• 90 degree turn with galvanized pipe threads on
  inside of one, outside of other.

153
Switch Box

• Used to install toggle switches or duplex
  receptacles.

154
T-Hinge

• Used where strength is required but one facing is
  narrow.

155
Tap Wrench

• Holding bolt tap.

156
Tape Rule

• Straight or curved measuring.

157
Thickness Gauge

• Determining gaps.

158
Timing Light

• Timing ignition.

159
Tip Cleaners

• Cleaning welding and cutting tips.

160
Tire Chuck

• To inflate tires.

161
Tire Gauge

• Checking tire air pressure.

162
Toggle Bolt

• Anchoring into a hollow space.

163
Toggle Switch

• Turning current on and off.

164
Toggle Switch Plate

• Cover for toggle switch.

165
Torch Lighter

• Light acetylene and propane torches.

166
Torque Wrench

• Measure amount of torque.

167
Torx Screwdriver

• Turning torx-head screws and bolts.

168
Tree Diameter Tape

• Measure circumference of
  tree.

169
Triangular File

• Filing saws.

170
Try Square

• 90o squaring.

171
Tube Cutter

• Cutting soft tubing.

172
Universal Joint

• Holding socket for angle turning.

173
Universal Socket

• Socket for angle turning.

174
Valve Spring Compressor

• Compressing valve spring for removal and
  insertion.

175
Vise Grip Pliers

• For extra firm gripping.

176
Vise Grip Welding Clamp

• For extra firm gripping of welding materials.

177
Water Breaker

• Reduces the impact of water pressure on soil and
  plants.

178
Welding Gloves

• Protects welders hands.

179
Welding Goggles

• Protects welders eyes.

180
Welding Helmet

• Protects face and eyes from welding flash.

181
Welding Torch

• Heats and fuses metal.

182
Wheel Puller

• Remove wheel from axle.

183
Wire Scratch Brush

• Cleaning metal.

184
Wire Strippers

• Removing insulation from electric wire.

185
Wood Chisel

• Dressing and shaping wood.

186
Wood Mallet

• Driving non-metallic objects.

187
Wood Rasp

• Coarse filing of wood.

188
Wrecking Bar

• Ripping and prying.

189
Designed By

• Johnny M. Jessup, FFA Advisor
• Hobbton High School
