Title: Energy Savings Potential Estimates Using CBECS and CEUS


1
Energy Savings Potential Estimates Using CBECS
and CEUS
  • Michael MacDonald
  • Oak Ridge National Laboratory
  • macdonaldjm_at_ornl.gov
  • ASHRAE SLC Annual Meeting, 6-25-08

2
What will be presented
  • Brief info about CBECS and CEUS
  • Brief info on building energy performance scoring
    using multivariate normalization
  • Brief coverage of sectoral modeling
  • Brief info on preliminary sector-wide
    multivariate normalization models for US and CA
    using CBECS and CEUS
  • First-ever preliminary results on use of such
    models for estimating nationwide and CA energy
    savings potentials based on performance levels

3
CEUS, Commercial Energy Use Survey (CA)
  • In 1996, new law led to first CEUS being
    conducted, with latest survey in 2003, about 60
    building types, about 80 of sector covered
  • Very extensive data, used for complicated
    analyses, including calibrated simulations of
    entire commercial sector or subsectors
  • Used to develop estimates of statewide floor
    stock, energy intensities, and energy usage by
    building type
  • Building / site weights used to scale up to
    entire subsectors, and then results can be
    extrapolated to state levels
  • 2003 data currently being studied to examine
    building energy performance system options for CA
  • CA est 700,000 buildings, 6 billion sq ft in
    2003

4
CBECS, Commercial Buildings Energy Consumption
Survey
  • National survey conducted periodically since
    1979, latest is 2003
  • 2003 CBECS identifies about 50 commercial
    building types
  • Ignores buildings less than 1,000 sq ft after the
    original 1979 NBECS survey
  • Masks buildings gt 1,000,000 sq ft
  • Has complicated survey weights that allow
    extrapolation to entire country
  • 71 billion sq ft, almost 5 million buildings in
    2003

5
CBECS and CEUS, some important differences
6
Basic EUI Statistics kBtu/sq-ft per yr
7
(No Transcript)
8
CBECS and CEUS Data are already used for savings
potential estimates
  • CBECS data provide some of the basis for the
    National Energy Modeling System (NEMS)
  • CEUS data used for modeling of savings potentials
  • Results available based primarily on
    economic-engineering models
  • Results presented here are based on performance
    rating models

9
Energy Performance Methods
  • Meaningful standard of comparison?
  • Compare to what?
  • Data sources?
  • Comparison method (STD 105-2007)
  • Normalization options ... past internal
  • Slice-and-dice by specific characteristics
  • Additional normalization, e.g., weather
  • Simultaneous multivariate normalization

10
ASHRAE Handbook, Fundamentals
  • Chapter 32 2005, Energy Estimating and Modeling
    Methods
  • Table 10, Capabilities of Modeling Methods (p
    32.31)
  • 10 modeling methods mentioned
  • Multivariate linear regression is the one that
    allows simultaneous, multivariate normalization
    tools to be developed simple (sometimes), fast,
    medium accuracy (again, compared to what?)

11
Economic-Engineering Models
  • Economic-engineering (E-E) models such as in NEMS
    use engineering data and analysis results to feed
    into and partially interact with an economic
    model of energy and investment
  • Because change is often slow, this approach often
    works fine for certain types of forecasting
  • But many types of energy improvements cannot be
    modeled reasonably, let alone well, with these
    models, and watch out if changes are fast
  • To forecast total energy use, normalization of
    energy is not required, as normalized energy is
    not the desired output, but normalized energy can
    account for total energy performance, including
    operational efficiency
  • New energy technologies, and impacts of those
    technologies on new buildings, are ably modeled
    in E-E tools at times, but improvements in
    operations are typically not
  • Operational improvements are thus typically
    ignored

12
Page 34
13
Simultaneous Multivariate Normalization Compares
Performance
  • Tools like the Energy Star buildings rating
    system have been found capable of normalizing
    about 90 of the variation in energy use between
    buildings, leaving the last 10 as the basis for
    performance rating differences
  • This approach accounts for total energy
    performance, including operations (other factors
    such as IAQ typically handled separately)
  • The resulting performance score or rank gives a
    specific number on building energy performance,
    but not why
  • Engineering calculation tools like Energy Plus,
    DOE-2, etc, typically cannot say anything about
    how well a building performs compared to others,
    but can indicate why
  • Quantification of total energy performance is
    important, and this presentation will show the
    types of information possible using sectoral-wide
    models as opposed to building type models

14
Building-Type Models
  • Tools like Energy Star multivariate normalization
    tools are important for providing performance
    ratings that can be compared for specific
    building types
  • But coverage is limited
  • Model basis is national-average-driven
  • Keep in mind that these tools allow savings
    potential for a building (type) to be calculated
    based on score
  • Analysis for CA has indicated that state-level
    tools may be critical in some cases for rating
    building energy performance
  • Energy Star multivariate tools may cover 60 of
    the floor area but a much smaller percentage of
    all buildings in CA
  • Ratings of CA buildings using the national models
    appear to lead to fairly high rankings for some
    building types, indicating tougher normalization
    may be desirable in CA

15
Sector-Wide Models
  • Sector-wide models can cover almost all buildings
    and types
  • Performance rating will not be as robust as for
    building-type models, but sectoral coverage is
    essentially achieved
  • Savings potential is no longer limited to a
    building (type) but can now be calculated for the
    entire sector and possibly subsectors

16
Or Other Types of Models . . .
  • Entire sectors can be modeled, e.g., Buildings,
    Industry, Transportation
  • Scoring can be put on a curve to grade the
    entities analyzed
  • Normalization at one point in time can serve as a
    baseline to measure future improvements against

17
Example of possible grading
18
CBECS National Model Form
  • Energy use index (EUI) as a function of other
    parameters
  • EUI itself accounts for 65 of variation in
    energy use
  • CBECS 2003 weights used
  • Some data screening needed to remove problem
    facility types and include desirable parameters
  • Effective R-square 0.85, F 141

19
Basic CBECS Model Parameters
  • Heating and cooling degree-days
  • Seating density for eating meals
  • Hours of operation per week
  • Personal computer density
  • Worker density

20
Building / Space Types Adjusted
21
(No Transcript)
22
How is California Isolated?
23
Savings Potential based on CBECS Performance
Model Scores
24
California CEUS Model Form
  • Ln(energy) as a function of other parameters,
    with Ln(SqFt) as a parameter (not EUI-based,
    heteroskedasticity would not let go)
  • CEUS weights used in calculations
  • Some data screening needed to only use real fuel
    data and include desirable parameters
  • R-square 0.77, F 235

25
California Potential Savings
26
Where to Now?
  • Comparisons of CBECS and CEUS energy
    normalization methods indicate CA likely needs
    tougher adjustments than national-average-based
    methods provide
  • Several performance rating options will likely be
    available, including a sector-wide normalization
    tool, hopefully within a year
  • National sector-wide normalization tools also
    appear potentially important
