Title: Presentation on Real Time Operating Systems


1
Presentation on Real Time Operating Systems
2
Contents
  • Real Time System Fundamentals
  • Real Time Operating System (RTOS)
  • Linux as RTOS

3
What are Real-time Systems ?
  • Real-time systems
  • Those systems in which the correctness of the
    system depends not only on the logical result of
    computation, but also on the time at which the
    results are produced.

4
Types of Real Time Systems
  • Based on Hard deadline Penalty due to missing
    deadline is a higher order of magnitude than the
    Reward in meeting the deadline.
  • Based on Soft deadline Penalty often equal /
    lesser magnitude than Reward.

5
A Sample Real Time System (1)
6
A Sample Real Time System (2)
  • Mission Reaching the destination safely.
  • Controlled System Car.
  • Operating environment Road conditions.
  • Controlling System
  • - Human driver Sensors - Eyes and Ears of the
    driver.
  • - Computer Sensors - Cameras, Infrared
    receiver, and Laser telemeter.

7
A Sample Real Time System (3)
  • Controls Accelerator, Steering wheel,
    Break-pedal.
  • Actuators Wheels, Engines, and Brakes.
  • Critical tasks Steering and breaking
  • Non-critical tasks Turning on radio

8
A Sample Real Time System (4)
  • Performance is not an absolute one. It measures
    the goodness of the outcome relative to the best
    outcome possible under a given circumstance.
  • Cost of fulfilling the mission ? Efficient
    solution.
  • Reliability of the driver ? Fault-tolerance is a
    must.

9
Contents
  • Real Time System Fundamentals
  • Real Time Operating System (RTOS)
  • Linux as RTOS

10
RTOS Kernel
  • RTOS Kernel provides an Abstraction layer that
    hides from application software the hardware
    details of the processor / set of processors upon
    which the application software shall run.

11
RTOS Kernel Functions
12
Task Management
  • Set of services used to allow application
    software developers to design their software as a
    number of separate chunks of software each
    handling a distinct topic, a distinct goal, and
    sometimes its own real-time deadline.
  • Main service offered is Task Scheduling
  • controls the execution of application software
    tasks
  • can make them run in a very timely and responsive
    fashion.

13
Task Scheduling
  • Non Real -time systems usually use Non-preemptive
    Scheduling
  • Once a task starts executing, it completes its
    full execution
  • Most RTOS perform priority-based preemptive task
    scheduling.
  • Basic rules for priority based preemptive task
    scheduling
  • The Highest Priority Task that is Ready to Run,
    will be the Task that Must be Running.

14
Priority based Preemptive Task Scheduling
  • Every Task in a software application is assigned
    a priority.
  • Higher Priority Higher Need for Quick Response.
  • Follows nested preemption

15
Nested Preemption
Timeline for Priority-based Preemptive Scheduling
16
Task Switch (1)
  • Each time the priority-based preemptive scheduler
    is alerted by an External world trigger /
    Software trigger it shall go through the
    following steps that constitute a Task Switch
  • Determine whether the currently running task
    should continue to run.
  • Determine which task should run next.
  • Save the environment of the task that was stopped
    (so it can continue later).
  • Set up the running environment of the task that
    will run next.
  • Allow the selected task to run.

17
Task Switch (2)
  • A Non Real time operating system might do task
    switching only at timer tick times.
  • Even with preemptive schedulers a large array of
    tasks is searched before a task switch.
  • A Real time OS shall use Incrementally arranged
    tables to save on time.

18
Task Switch (3)
  • Task Switching Timing

19
Intertask Communication Synchronization
  • These services makes it possible to pass
    information from one task to another without
    information ever being damaged.
  • Makes it possible for tasks to coordinate
    productively cooperate with each other.

20
Inter-Task communication Synchronization
  • The most important communication b/w tasks in an
    OS is the passing of data from one task to
    another.
  • If messages are sent more quickly than they can
    be handled, the OS provides message queues for
    holding the messages until they can be processed.

21
Message passing in OS
  • Most General Purpose OS actually copy messages
    twice as they transfer them from task to task via
    a message queue.

22
Message passing in RTOS
  • In RTOS, the OS copies a pointer to the message,
    delivers the pointer to the message-receiver
    task, and then deletes the copy of the pointer
    with message-sender task.

23
Dynamic Memory Allocation in General Purpose OS
  • Non-real-time operating systems offer memory
    allocation services from what is termed a Heap.
  • Heaps suffer from a phenomenon called External
    Memory Fragmentation.
  • Fragmentation problem is solved by Garbage
    collection / Defragmentation.
  • Garbage collection algorithms are often wildly
    non-deterministic.

24
Dynamic Memory Allocation in RTOS
  • RTOS does it by a mechanism known as Pools.
  • Pools memory allocation mechanism allows
    application software to allocate chunks of memory
    of 4 to 8 different buffer sizes per pool.
  • Pools avoid external memory fragmentation, by not
    permitting a buffer that is returned to the pool
    to be broken into smaller buffers in the future.
  • When a buffer is returned the pool, it is put
    onto a free buffer list of buffers of its own
    size that are available for future re-use at
    their original buffer size

25
Contents
  • Real Time System Fundamentals
  • Real Time Operating System (RTOS)
  • Linux as RTOS

26
Dark Side of Linux in Real-Time
  • The Linux kernel (lt version 2.6) is neither
    preemptive nor reentrant by user processes.
  • Processes are heavy-weight Linux has
    insufficient resource handling.
  • Fair share scheduling algorithm .
  • Unbound amount of CPU time used by interrupt
    handlers under Linux, and these run at a higher
    priority than any user process.

27
Typical Solutions for Linux
  • 3 ways to deal with Linux s poor real-time
    performance
  • Ignore the problem (only for soft real-time).
  • Work around and run real-time applications under
    an RTOS with Linux itself as a separate task.
    e.g. RT-Linux.
  • Adapt Linux and run a Linux compatible RTOS
    kernel instead of the Linux kernel.

28
Ignore the problem Approach
  • The most popular approach is to ignore the
    problem.
  • Mostly works for soft real-time systems.
  • Design recommendations to reduce latency
  • If possible, address all real-time response needs
    directly with interrupt service routines.
  • Avoid known excessive interrupt-off periods in
    Linux.
  • If a process component is required in the
    real-time control path, then consider aggregate
    system loading Adapt processes.

29
Work Around Approach
  • Linux kernel runs as a task under a small
    real-time executive.
  • Real-time tasks are run directly under the
    real-time executive
  • Non-real-time tasks are run under Linux.
  • Applications that work on such a system can
    include machine control, process control, and
    instrumentation applications.

30
Work Around - Advantages
  • The real-time executive can be small and simple
    making it easier to verify its real-time
    performance.
  • The Linux kernel running non-real-time tasks is
    "standard" Linux so it is compatible with other
    Linux distributions and can easily be updated.
  • Supports hard real-time applications.

31
Work Around - Disadvantages
  • Not applicable if real-time part of the software
    is large / not easily separated from the code
    that needs a Linux environment
  • Tasks running under the real-time executive do
    not have access to the Linux facilities, device
    drivers, etc.
  • Tasks running under the Linux kernel and can
    access the facilities are not real-time.
  • Programmers tend to increase the number of
    facilities in the real-time kernel until the
    real-time executive replicates facilities of
    Linux.

32
Adapt Linux
  • The original Linux kernel is replaced with a
    compatible kernel with hard real-time performance
    characteristics.
  • The kernel is only a small part of a whole
    operating system. If just the Linux kernel is
    replaced and the libraries, utilities, and file
    structure remain the same.
  • The real-time kernel must support all the
    facilities of a Linux kernel while still
    remaining fully preemptive and reentrant.

33
Adapt Linux Approach Advantages Disadvantages
  • Advantages
  • No limits on the size and complexity of the
    real-time application code.
  • Third party software not originally envisioned
    for real-time use can be invoked by real-time
    tasks
  • With the same programming interfaces, programmers
    who understand Linux would already be experts in
    the real-time environment.
  • Disadvantages
  • With modified Linux you are NOT sure of full
    compatibility with standard Linux application

34
Any Questions?
35
Thank You !
