ROBOTICS IS

1

• ROBOTICS IS
• THE WAVE OF THE FUTURE

2
ARES Robotics has a perfect safety record with
zero injuries and recordable incidents. Ares is
the leader in ROV operations in the petrochemical
industry.ARES can solve your problems and help
minimize your costs

• Introduction to ARES Robotics, LLC
• ARES is the company to create solutions to your
  material removal and/or inspection needs.
• ROVs (remotely operated vehicles) for use in the
  petrochemical industry and has become the problem
  solver in the industry in material removal,
  inspection and remote tasking.
• Ability to work in any hazardous environment,
• Ares can perform well in all types of chemicals
  and vessels including carbon steel and stainless
  steel vessels.
• Top vessel entry maintenance cleaning and sludge
  reduction is one of our specialties.
• Ares has also entered into the pipeline industry
  and has a line of vehicles for inspection and
  well as cleaning oily water and sewer lines.

3

• ARES ROV APPLICATIONS
• The use of an ARES ROV (Remotely Operated
  Vehicle) provides alternatives that are not
  limited by standard material removal methodology.
• In-Service Material Removal is a limitless area
  where robotics can perform the previously
  unimaginable.
• Cost benefits of a vessel remaining in service
  vs. the time and cost of removing it from service

• The ability to perform maintenance material
  reduction and volume restoration on a
  prescheduled basis
• Material Removal and Disposal opportunities never
  before possible without shutdown
• Internal Floating Roof Maintenance and Inspection
  without human entry of the confined space.
• Camera inspections of individual roof components
  and sealing systems
• Removal of pontoon lids and pumping of any liquid
  materials from pontoons to verify structural
  integrity
• Ability to remove fugitive material accumulated
  on internal roof due to seal burp or failure
• All functions can be easily accomplished
  regardless of tank condition and/or internal roof
  integrity
• Bulk Material Removal regardless of vessel
  conditions, integrity or internal roof height
• A single ROV is designed to replace and
  significantly outperform an entire tank cleaning
  crew
• ROVs are unaffected by Tank Conditions/Integrity,
  LEL Levels or IHDL Conditions
• Systems are fully adaptable to perform material
  removal under changing conditions

4
(No Transcript)
5
ARES ROV System
Piloting Station
Command Center
ARES 4-wheel drive ROV
ARES 6-wheel drive ROV
Over 40 different models to perform ROV tasks and
problem solving.
6
Dry Crude
Collapsed Roof Heavy Crude
Pipeline ROV
Product Blending
Internal Floating Roof
7
TOP VESSEL ENTRYDESCRIPTION OF VESSELTank
Configuration External Floating Roof Tank
Diameter 212 ft 40ft high Amount of
Material Average 6-7 feet or 40,000 bbls. Type
of Material Crude Oil tank bottoms, non
pumpable solids 40 wax, 12 solids, 2 to 6
waterType of Entry Top Vessel entry and side
vessel entryRoof Condition Floating roof is
slanted one side of the roof is on its high legs
_at_ 6 feet and the other side is at the 9 foot
level being held up by suspected solids.
8
SIDE VESSEL ENTRY DESCRIPTION OF VESSEL Tank
Configuration Fixed coned roof Tank Diameter
180 ft x 48ft high Amount of Material 1 of
Residual No. 6 Oil Type of Material Residual
No. 6 Oil sludge Type of Entry (3) side man
waysRoof Condition GoodFloor Cone down with
(1) center sump, (2) gas fired steam tubes, (6)
banks of steam coilsAdditional information
Staging area approximately 100 (ft) by 50 (ft)
located on the side of the tankLast Cleaned
15 years ago Tank is being cleaned
for API inspection, repair and hot work
9
INTERNAL FLOATING ROOFDESCRIPTION OF VESSEL
Tank Configuration Internal Carbon Steel Roof
landed on its low legsTank Diameter 120 ft
by 40 ft highAmount of Material Cat gas on the
roof of the IFR, unknown amount. Type of
Material Liquid Cat GasType of Entry Top
vessel entry via 24 top man wayRoof
Condition Floating roof is set on its low legs
and is flat to drive the ROV on the roof
surfaceFloor flat floor, no coating on
floorAdditional information Remove the
material from on top of the IFR and degas the
vapor spaceLast cleaned unknownHazard
assessment Cat Gas present in liquid and vapors,
use proper PPE.Tank is being cleaned for
inspection, repair and hot work
10

• ARES CUSTOMER LIST
• AERA
• BP Amoco
• Brenttagg
• Citgo
• ConocoPhillips
• Diamond Shamrock
• DuPont/Invista
• Ethyl
• ExxonMobil
• Kinder Morgan
• Koch Industries
• LWD Field Services
• Lyondell Basel
• Lyondell Citgo
• MCS Technologies
• Motiva

11

• THE FUTURE IS HERE
