Central Nervous System9. Tumors
2

• INTRACRANIAL TUMORS (ICTS)
• Primary or Metastatic
• Occur with equal frequency in adults, but in
  children primary tumors are far more common.
• Primary ICTs account for
• 2 of cancers in adults
• 20 of all cancers in children.
• In children 70 of ICTs arise in ? Posterior
  fossa (infra-tentorial). as
• In adults 70 of ICTs arise in ?
  Supra-tentorial.
• Because of its location, a benign ICT may have
  fatal malignant effects.
• Malignant ICTs spread by
• Direct infiltration of adjacent tissues
• May disseminate within the CNS via CSF.
• Gliomas account for 60 of primary ICTs
• Meningiomas for 20 all others 20.
• All CNS tumors behave as malignant clinically .
  Limited space

3

The unique features of CNS tumors ICP 1. CNS
tumors- lt 2 of all malignant tumors. They grow
in a unique environment the intracranial
space. 2. The intracranial contents -
incompressible Brain and blood contained within a
rigid unyielding bony structure. 3. Intracranial
pathologies (tumors, abscess, hematoma,
infarction, edema, etc.) eventually produce life
threatening increase of the intracranial-pressure
ICP.
4
Cytologic origin of CNS tumors

• Neuro-ectodermal most important are the
  Gliomas
• Mesenchymal most frequent ones are the
  Meningiomas
• Ectopic tissues from tissues displaced during
  embryogenesis Ex., Dermoid cyst
• Retained embryonal structures various cysts
  Paraphyseal cyst
• Metastases Lung, Breast, Melanoma, etc. in 50
  of cases

5
Neuro ecto - dermal tumors

• Glial cells
• astrocytes (A) - Astrocytoma
• Oligodendroglial cells - Oligodendroglioma
• Ependymal cells Ependymoma
• Neurons - Gangliocytoma

6
Incidence of brain tumors
7
Seen in kids with increased cellularity
8
What is benign and malignant in case of CNS
tumors?
9
ASTROCYTOMAS

• Account for 80 of primary ICTS in adults
• MC in the cerebral hemispheres
• MC Symptoms headaches, seizures, focal
  neurologic deficits ( usually in the anterior or
  middle)
• Low-grade Astrocytomas
• Gross
• Poorly defined gray-white infiltrative tumors.
• Histology
• Hypercellularity astrocytic nuclei of mild
  degree of atypia astrocytic processes ?
  fibrillary background fingers of astrocytes

10
Low-grade Astrocytomas

• Pilocytic Astrocytomas
• MC in the cerebellum of children young adults
  and less commonly in the optic nerve,
  hypothalamic region or cerebral hemispheres
• Morphology
• Cystic, with a tumor nodule in the wall of the
  cyst.
• Composed of bipolar astrocytes, with long
  hair-like processes, Rosenthal fibers
  Micro-cysts calcification good prognosis
• Grow very slowly (some patients have survived for
  gt40 yrs after incomplete resection) have an
  Excellent prognosis
• DD - not to confuse with low grade Fibrillary
  Astrocytoma

11
Grade I. tumor pilocytic astro
12
Pilocytic Astrocytoma
13
Pilocytic Astrocytoma
14
Pilocytic Astrocytoma
15
Rosenthal fibers
16
Gr. II. Astrocytoma
17
Gr. II. astrocytoma
18
Gr. III. astrocytoma
19
Gr. III. astrocytoma
20
Gr. III. Astrocytoma
21
Gr. IV. astro GBM
22
Gr. IV. astro GBM
23
Gr. IV. astro GBM
24
GBM necrosis/pseudo-palisade
25
GBM pleomorphic cytology
26
Gr. IV. Astro GBM
Die directly
27
OLIGODENDROGLIOMA

• Comprise 5 -15 of Gliomas
• Arise in the cerebral white matter
• MC in the 4th 5th decades
• Gross
• Well circumscribed, gelatinous, gray masses, with
  foci of hemorrhage calcification.
• Histology
• Sheets of cells with rounded nuclei surrounded by
  a halo of clear cytoplasm (fried egg appearance).

• There is often a delicate network of capillaries
  scattered foci of calcification (psammoma
  bodies)( seen in thyroid, CNS, kidneys etc).
• Grows slowly, presents commonly with seizures,
  prognosis is better than Astrocytoma, average
  survival is 5-10 yrs (with modern therapeutic
  approaches

28
Oligodendroglioma
29
Oligodendroglioma
30
Oligodendroglioma
31
Oligo-Astrocytoma
32
EPENDYMOMA

• Arise from the Ependymal lining of the ventricles
  or the central canal of the spinal cord
• Arise in the
• Fourth ventricle in children young adults
• Spinal cord in the middle aged.
• Morphology
• Highly cellular, tumor cells have regular nuclei
• May exhibit epithelial features with formation of
  rosettes (Flexner) or canals, also
  perivascular pseudo-rosettes (homer )
• Most tumors are well differentiated
• 4th ventricle tumors
• May cause hydrocephalus, usually cant be
  completely removed
• CSF dissemination may occur
• Average survival is 4 yrs

33
Myxo-papillary Ependymomas

• Arise in the filum terminale of the spinal cord
• Prognosis depends on completeness of surgical
  excision

34
Ependymoma
Rosettes perivascular Pseudo-rosettes
35
MEDULLOBLASTOMAS

• Second MC ICT of childhood (after Astrocytomas).
• Occurs exclusively in the cerebellum.
• Derived from fetal external granular layer of
  cerebellum.
• Grows rapidly occludes CSF flow ?
  hydrocephalus.
• Seeds through CSF ? implants around the spinal
  cord cauda equina (need irradiation of the
  whole Neuraxis).
• Histology
• Extremely cellular, anaplastic, small round or
  carrot-shaped cells with hyperchromatic nuclei, ?
  N/C, may form Homer-Wright pseudo-rosettes
• Highly malignant, yet radiosensitive 5-yr
  survival 75.

36
Medulloblastoma
37
Medulloblastoma
Homer-Wright pseudo-rosettes
carrot-shaped cells
38
MENINGIOMAS

• Usually Benign slow-growing tumors of adults, F/M
  32
• Originate from meningothelial cells of the
  arachnoid.
• Usually solitary ( multiple meningiomas ? NF2 )

• Morphology
• Firm rounded masses, adherent to the dura and
  compressing the underlying brain (no
  infiltration).
• Histologic variants include
• Syncytial, fibroblastic, transitional,
  Psammomatous papillary (? propensity to recur).
• Malignant Meningioma is very rare
• Infiltrates the underlying brain, shows marked
  nuclear atypia, ? mitoses, foci of necrosis.
• Other rare sarcomas of meninges include
• Hemangiopericytoma, malignant fibrous
  histiocytoma Fibrosarcoma.

39
Meningioma
40
Meningioma
Syncytial
Psammomatous
Epithelial Membrane Antigen
41
NERVE SHEATH TUMORS

• 1. Schwannomas
• Benign tumors of Schwann cells
• MC in the vestibular branch of the VIII CN at the
  cerebello-pontine angle (acoustic neuroma) ?
  tinnitus hearing loss
• Also involve branches of the trigeminal nerve
  dorsal nerve roots
• Tumors are encapsulated, attached to one side of
  the nerve axons do not pass through the tumor
• Consist of
• Antoni -A areas of high cellularity
• Nuclei form palisades Verocay bodies
• Antoni -B myxoid areas

42
Schwannoma
Antoni A hyprecellular
Antoni B Sparsely cellular
43

• 2. Neurofibromas
• Benign tumors composed predominately of Schwann
  cells, but also containing fibroblasts
  perineural cells
• May involve single or multiple dorsal spinal
  nerve roots (multiple in patients with von
  Ricklinghausen's disease - NF1)
• CN involvement is extremely rare
• May present as
• Localized fusiform enlargement of a nerve or
• Extensively infiltrate along the nerve ? ropy
  enlargement of the nerve its branches
  (plexiform Neurofibroma)
• Plexiform neurofibromas are usually part of NF1,
  excision is very difficult
• Histology
• Wavy spindle shaped cells, myxoid collagenous
  stroma with interspersed nerve fibers

44
Acoustic Neurinoma (Schwannoma)
45
METASTATIC ICTS

• 50 of ICTs.
• Common Primaries
• Broncho-genic small cell undifferentiated (oat
  cell) ca., Breast ca., Malignant melanoma, RCC.
  Colon ca.
• Sites of metastases
• Cerebral cortex 80
• Rest are in the cerebellum brain stem.
• 50 are multiple at the junction between the
  gray white matter.
• Vertebral column is a common site for metastases
  of
• Breast Prostatic carcinomas
• Thoracic spine 60, Cervical 20 Lumbar 20
• Treatment Radiotherapy

46
Metastasis
47

• CHOROID PLEXUS PAPILLOMA
• MC in children ? Arising from the lateral
  ventricles
• In adults they are found MC in the 4th ventricle

• Present with Hydrocephalus
• Due to either over-production of CSF or to
  obstruction of the ventricular system.
• Consist of papillae with fibrovascular stalks
  covered with a cuboidal or columnar ciliated
  epithelium, recapitulating the structure of the
  normal choroid plexus.

48

• COLLOID CYST OF THE THIRD VENTRICLE
• A non-neoplastic cystic lesion
• Morphology
• Having a thin fibrous capsule, a lining of
  Cuboidal to columnar epithelium containing
  gelatinous Proteinaceous material.
• Attached to the roof of the third ventricle at
  the foramina of Munroe may cause sudden
  obstruction of the CSF flow ? acute
  non-communicating hydrocephalus ? brain
  herniation death
• Symptoms headaches (often positional), drop
  attacks, incontinence
• Goblet cells are confirmatory

49
MISCELLANEOUS (MIDLINE) TUMORS

• Pinealomas
• True pineocytomas are extremely rare, may also
  have pineoblastomas
• Germinomas
• MC in the pineal suprasellar regions in
  adolescents young adults
• Closely resemble testicular Seminomas ovarian
  Dysgerminomas
• Other GCTs (Teratomas Choriocarcinomas) also
  occur
• Not clear how GCTs arise within the CNS
• Craniopharyngiomas
• Benign cystic tumors of children adolescents
• Develop in the suprasellar region ?
  Hypopituitarism
• Originate from remnants of Rathkes pouch
  contain squamous columnar epithelium,
  calcifications are common.

50
CNS LYMPHOMA

• Primary CNS lymphomas
• Account for 1 of ICTs
• MC CNS neoplasm in AIDS other immunosuppressed
  patients often arise deep within the cerebral
  hemispheres are commonly bilateral
• Lymphoma cells exhibit an angiocentric
  distribution
• Usually are B-cell lymphomas many appear to be
  EBV-related.
• Secondary CNS lymphomas
• Lymphomas arising outside of the CNS rarely
  involve the brain parenchyma
• May involve the meninges, intradural spinal nerve
  roots epidural space

51
PHAKOMATOSES

• NEUROCUTANEOUS SYNDROMES (PHAKOMATOSES)
• AD
• Hamartomas Neoplasms
• Esp. involving the nervous system skin
• Mutations in tumor suppressor genes
• 1. Neurofibromatosis Type 1 (NF1)
• Neurofibromas, Neurofibro-sarcomas
• Optic nerve Gliomas
• Pigmented cutaneous macules (café au lait spots)
• Pigmented nodules of iris (Lisch nodules)
• 2. Neurofibromatosis Type 2 (NF2)
• Bilateral Schwannomas of CN VIII
• Multiple meningiomas
• Spinal cord Ependymomas

52

• 3. Tuberous Sclerosis
• Hamartomas (tubers) in the cerebral cortex,
  Sub-Ependymal hamartomas (candle drippings) ?
  Sub-Ependymal giant cell Astrocytomas
• Seizures mental retardation
• Extra CNS findings
• Kidney (Angiomyolipoma), Heart (Rhabdomyoma MCC
  in kids, adult mixomas ), skin (Angiofibroma)

53
Tuberous Sclerosis
54

• 4. von Hippel-Lindau disease
• Hemangioblastomas of the cerebellum, retina,
  brain stem spinal cord
• Cysts of liver, kidney pancreas
• ?? incidence of RCC, may be bilateral
• 10 of Hemangioblastomas ? polycythemia

55
von Hippel-Lindau disease
Hemangioblastomas
