Open Path Methods

1
Open Path Methods
Albert J. Heber, Professor heber_at_purdue.edu
AgAirQuality.com
Agricultural and Biological Engineering Purdue
University
2
Biocurtain at Laying House
Biocurtain over 3 fans
Lab
3
Inside Biocurtain at Layer House
4
NRC Report on Air Emissions
Emissions Global/Nat. Local Concern
NH3 Major Minor N-Dep/PM2.5
N2O Significant Insignificant Climate
NOx Significant Minor Haze/Health
CH4 Significant Insignificant Climate
VOCs Insignificant Minor Quality
H2S Insignificant Significant Quality
PM10 Insignificant Significant Haze
PM2.5 Insignificant Significant Health/Haze
Odor Insignificant Major Quality
5
Comparing Open Path Sensors
Type of Sensor FTIR UV OPL
Detector cooling Cryocooler - -
Path Length, m 400 150-1000 2000
Mode Monostatic Bistatic Monostatic
Compounds NH3, VOC, CH4 NH3, H2S, Nox H2S or NH3
Scan frequency, Hz 1 1 4000
Detection Limits
Hydrogen sulfide Deuterium
ppm-m 10-30 0.4-5 6-25
ppb 75-600 2.8-33 3-120
Linear upper range
Ammonia Xenon
ppm-m 1.5 2 2
ppb 2-50 3-20 1-40
Linear upper range 903
Models BLS, TOM BLS, TOM BLS
6
Type of Sensor FTIR UV OPL
Scanning Yes Yes ?
Reflectors -
200 m 30 cube Small retro
400 m 60 cube
1000 m 90 cube
Real-time quantification yes yes, w/ BLS yes
Capital cost 140K 20K-45K 30K
Short term costs none none none
Annual costs Repump cooler, replace retros New source None
Recalibration needs None Annually 7K laser/7 yr.
7
FTIR with 48-m Closed Cell

• Advantages
• Measures greenhouse gases
• Measures ammonia MDLlt6 ppb, NO, NO2
• Measures dozens of other gases, SO2
• Real-time measurement
• Quick response limited by cell volume
• Disadvantages
• Expensive 75,000
• Heavy, non-portable

8
Scanning FTIR - Tomography

• Layer house
• Horizontal scanning
• Vertical scanning

9
Source Bruce Harris, U.S. EPA, 2004
10
Source Bruce Harris, U.S. EPA, 2004
11
Field Measurement of Air Pollutants Near Swine
Confined Animal Feeding Operations using UV DOAS
and FTIRC. D. Secrest (paper presented in 2000)

• Ambient ammonia concentrations 0.8 km from a
  large swine facility with lagoons over a two week
  period were 0 to 900 ppb.
• An Iowa Study Group recommended that ambient
  exposure to ammonia should not exceed 150 ppb.
• The UV DOAS and FTIR were in good agreement.
• Open-path monitors combined with wind monitors
  are powerful tools for comparing daytime and
  nighttime pollutant concentrations, and for
  determining the effect of wind speed on
  concentration.

12

• Area sources -gt diffuse plumes
• Open-path -gt entire plume length
• An array paths maps the plume

Source Bruce Harris, U.S. EPA, 2004
13
OP-FTIR Measurement Pathsfor Path-Integrated
Optical Remote Sensing (Tomography)
Source Bruce Harris, U.S. EPA, 2004
14
Controlled release simulation of an area source
under unstable air conditions worst case
Reconstructed plumes Actual release rate 1.7
g/s Calculated flux 1.2 g/s Measured s?
50.7 Pasquill-Gifford Stability A - Unstable
Height meters
Source Bruce Harris, U.S. EPA, 2004
15
Controlled release simulation of an area source
under stable air conditions best case
Reconstructed plumes Actual release rate 1.7
g/s Calculated flux 1.5 g/s Measured s?
12.7 Pasquill-Gifford Stability C-D - Neutral
Source Bruce Harris, U.S. EPA, 2004
16
FTIR References

• Harris, D. B., and E.L. Thompson, Jr. 1998.
  Evaluation of ammonia emission from swine
  operations in North Carolina. Proc. Emission
  Inventory-Living in a Global Environment, VIP-88,
  pp. 420-429. AWMA, Pittsburgh, PA.
• Harris, D. B., E.L. Thompson, Jr., D.A.
  Kirchgessner, J.W. Childers, M. Clayton, D.F.
  Natschke, W.J. Phillips. 1999. Multi-pollutant
  concentration mapping around a concentrated swine
  production facility using open-path FTIR
  spectrometry. Workshop on Atmospheric Nitrogen
  Compounds II Emissions, Transport,
  Transformation, Deposition and Assessment, NCSU,
  Raleigh, NC, pp. 237-246.
• Childers, J. W., E.L. Thompson, Jr., D.B. Harris,
  D.A. Kirchgessner, M. Clayton, D.A. Natschke,
  W.J. Phillips. 2001. Multi-pollutant measurements
  around a concentrated swine production facility
  using open-path spectrometry. Atm. Env. 35
  1023-1936.
• Childers, J. W., Thompson, E. L., Jr., Harris, D.
  B., Kirchgessner, D. A., Clayton, M., Natschke,
  D. A., Phillips, W. J. (2001) Application of
  standardized quality control procedures to
  open-path fourier transform infrared data
  collected at a concentrated swine production
  facility. Env. Science Tech. 351859-1866.

Source Bruce Harris, U.S. EPA, 2004
17
FTIR References

• Childers, J. W., E.L. Thompson, Jr., D.B. Harris,
  D.A. Kirchgessner, M. Clayton, D.A. Natschke,
  W.J. Phillips. 2000. Comparison of an innovative
  algorithm to classical least squares for
  analyzing open-path fourier transform infrared
  spectra collected at a concentrated swine
  production facility. Appl.Spect. 56325-336.
• Hashmonay, R. A., D.A. Natschke, K. Wagoner, D.B.
  Harris, E.L. Thompson, Jr., M.G. Yost. 2001.
  Field evaluation of a method for estimating
  gaseous fluxes from area sources using open-path
  fourier transform infrared. Env. Sci. Tech.
  352309-2313.
• Harris, D. B., E.L. Thompson, Jr., Vogel, C. A.,
  Hashmonay, R. A., Natschke, D. A., Wagoner, K.
  Yost, M.G. Innovative approach for measuring
  ammonia and methane fluxes from a hog farm using
  open-path fourier transform infrared
  spectroscopy. 94th Annual Conf. of the AWMA,
  VIP-102-CD, AWMA, Pittsburgh, PA 2001.
• Hashmonay, R.A. and D.B. Harris. 2001.
  Particulate matter measurements using open-path
  Fourier transform infrared spectroscopy. 94th
  Annual Conference of the Air Waste Management
  Association, VIP-102-CD, AWMA, Pittsburgh, PA.
• Harris, D.B., R.C. Shores, L.G. Jones. Ammonia
  Emission Factors from Swine Finishing Operations.
  Int. Emissions Inventory Conference, One
  Atmosphere, One Inventory, Many Challenges.
  www.epa.gov/ttn/chief/conferences/ei10/index.html.

Source Bruce Harris, U.S. EPA, 2004
18
Wind
ponds
sheds
ponds
sheds
Source Lowry Harper USDA-ARS, 2004
19
Wind
Source Lowry Harper USDA-ARS, 2004
Smeared plume
20
Wind
Source Lowry Harper USDA-ARS, 2004
21
Backward Lagrangian Stochastic (BLS) Dispersion
Models

• Backward Lagrangian Stochastic Modeling
• Introduced by Flesch, T.K., and J.D. Wilson.
  1995. Backward-time Lagrangian stochastic
  dispersion models and their application to
  estimate gaseous emissions. J. Applied
  Meteorology 341320-1332.
• Utilizes point or line measurement
• Ultrasonic or cup anemometers
• Flexible and easy to use.
• Surface layer model. Locate lt 1 km.
• Commercial software available www.thunderbeachscie
  ntific.com

22
UV-DOAS

• Ultraviolet Differential Optical Absorption
  Spectroscopy
• 1-1000 ppb path length
• Fast scanning, compact, tunable
• EPA Equivalent Method for SO2, O3 and NO2.
• Also measures ammonia, benzene, toluene, xylenes,
  styrene, Hg, HF, HNO2, HCHO
• Continuous operation
• MDL for ammonia 2.8 to 5.8 ppb

Source Myers, J., T. Kelly, C. Lawrie, and K.
Riggs. 2000. ETV Technology Evaluation Report.
Opsis, Inc. AR-500 Ultraviolet Open-Path Monitor.
ETV Advanced Monitoring Systems Center, Battelle.
23
EPA Lab for Ambient Measurements
TEOM
UV-DOAS
UV-DOAS
TEOM
UV-DOAS
1-min averaging and recording intervals
MET tower
24
Collocated UVs
25
Micromet Setup at Lagoons
FTIR Tomography
UV BLS
FTIR BLS
Source Bruce Harris, U.S. EPA, 2004
26
Equipment Required per Team

• Two FTIR scanning systems with 20 retros
• Two UV systems
• Four computers for optical remote sensors
• One computer for data QAQC and analysis
• Two 3D ultrasonic anemometers (2 and 12 m)
• Complete weather station
• Two, 12-m towers for FTIR/UV systems
• One, 2 m tower for ultrasonic anemometer
• Software for computed tomography method
• Software for BLS method
• Van and trailer

27
Thank you!
Check out AgAirQuality.com
