Echocardiography of Cardiac Amyloidosis Frederick L. Ruberg

1
Echocardiography of Cardiac Amyloidosis

• Frederick L. Ruberg, MD
• Boston University Medical Center
• May 25, 2005

2
What is amyloid

• Any misfolded protein that aggregates as a
  ?-sheet
• stains with Congo Red (birefringence)
• Implication in pathogensis of alzheimers disease
  (? amyloid)
• Systemic amyloidoses

3
The Systemic Amyloidoses

• Primary (AL) or light chain disease
• Plasma cell dyscrasia (clonal proliferation)
• 12-15 patients with myeloma have AL
• Immunoglobulin light chains
• 12 month survival without treatment
• 6 month survival with cardiac disease
• Incidence is 1 in 100,000 in Western countries
• Familial (AF)
• Mutations in transthyretin (TTR)
• Ile 122 of particular interest

4
The Systemic Amyloidoses

• Senile systemic amyloid (SSA)
• TTR-based non-genetic (ie, TTR normal)
• Cardiac predilection
• Male gender, onset after age 60
• Secondary amyloidosis (AA)
• Chronic inflammatory states
• Other specific protein abnormalities
• apolipoprotein A-I and A-II, lysozyme

5
Manifestations of AL
Merlini, G. et al. N Engl J Med 2003349583-596
6
Diagnosis of Amyloidosis
Falk, R. H. et al. N Engl J Med 1997
7
Amyloid Cardiomyopathy

• Very poor prognosis (6 mo survival)
• Restrictive cardiomyopathy with profound
  abnormalities of diastolic function
• Systolic dysfunction late manifestation
• Classic teaching
• biventricular thickening in a small ventricle
• valvular thickening, speckled pattern
• Atrial enlargement
• Pericardial effusion/evidence of elevated filling
  pressures

8
Echo Features
Rehman, JACC 2004
9
Amyloid Cardiomyopathy

• Patients do NOT respond to normal medication for
  CHF
• ACE inhibitors, beta-blockers, dig
• There is a treatment for AL amyloid
• Autologous bone marrow transplant
• Patient selection critical
• assessment of cardiac involvement

10
Advanced Amyloid
11
Continuum of Amyloid

• Advanced disease is too late
• Initial changes are abnormalities of diastolic
  function
• As wall thickness progresses restrictive
  physiology ensues
• Loss of limb lead voltage on ECG
• Systolic dysfunction late stage

12
Diastolic dysfunction

• Transmitral inflow
• E and A wave pattern
• E wave deceleration time
• IVRT
• Tissue Doppler mitral annular velocities
• E prime lt 6 cm/s
• LA enlargement, IVC dilation
• Restrictive physiology a late manifestation

13
Early Cardiac Amyloid
14
Early Cardiac Amyloid
15
After cardiac arrest
16
Hypertension vs. Amyloid
17
HTN vs Amyloid Doppler
18
HTN vs. Amyloid TDI
19
Moderate disease
20
Restrictive inflow, Absent A
21
Atrial arrest

• Absent A wave in setting of NSR
• Restrictive pattern
• Atrial amyloid infiltration and/or markedly
  elevated LV DP
• Risk of stroke/TIA, anticoagulation
• Recovery of A wave following successful BMT
  correlating to symptomatic improvement

22
Depressed E prime
23
Low stroke volume
24
Evidence of congestion
25
Advanced Amyloid
26
Restrictive filling
27
Treatment of AL

• Autonomic dysfunction, low stroke volumes
• Dependent on HR
• Beta blockers, ACEI poorly tolerated
• Digoxin may bind to amyloid and promote toxicity
• Can use diuretics
• Loop diuretics
• Aldactone/eplerenone
• Amiodarone
• Proamatine (Midodrine) for BP support

28
Restrictive?
29
Grade I Dysfunction
30
LVOT obstruction
31
LVOT Obstruction
32
SSA (Senile Cardiac)
33
SSA Doppler
34
SSA Clinical Features

• Onset age greater than 60 years
• Often exclusively cardiomyopathy
• More benign clinical course than AL
• Often tolerate medications that AL patients wont
• TTR amyloid, must exclude AL as well as known
  mutations in TTR to diagnose

35
Familial TTR
36
Familial Amyloid CMP

• Over 80 mutations identified
• Ile 122 in African Americans
• 2-4 heterozygotic allele frequency
• Unclear penetrance
• Unclear importance in setting of HTN
• Onset of CMP after age 60 years
• Stabilization of TTR tetramer to stop
  amyloidogensis by diflunisal
• Other agents in development
• Liver transplant/heart transplant

37
Stem Cell Transplant

• AL can respond to chemotherapy
• High dose melphalan with autologous stem cell
  transplantation
• 8-year follow-up data (Skinner, et al. Ann Int
  Med 2004)
• Median survival 1.6 yrs
• Exclusion EF lt 40 or decompensated CHF
• Lower dose, marrow sparing regimens
• Oral therapy, investigative drug regimens

38
Survival after HDM/SCT
Skinner, et al. Ann Int Med 2004
39
Post-BMT changes?
40
Post BMT

• Symptomatic improvement without obvious change in
  echo appearance
• Hemodynamic recovery (A wave)
• Improvement in TDI
• BNP normalization
• Mass regression
• Chamber remodeling

41
Role of CMR

• More sensitive than echo
• Explore tissue-dependent changes through delayed
  enhancement
• Demonstrated in 70 patients (Maceira, Pennell,
  et al. Circ 2005) associated with mass
• Small LV size increased wall thickness does not
  necessarily increased mass

42
CMR vs. echo
43
CMR vs. echo
44
Diffuse Delayed Enhancement
45
New echo approaches

• Strain imaging determines impaired longitudinal
  contraction (Koyama, Falk, et. al. Circ 2003)
• In absence of fractional shortening abnormality
• Preceded CHF symptoms
• Utility of TDI with BNP to facilitate diagnosis
  in early disease

46
Applications of echo/CMR

• Early diagnosis
• Predict outcomes with treatment
• Monitor response to treatment
