Trench for the First Responder

1
Trench for the First Responder

• Chris Bednarek
• Chicago Heights Fire Department

2
Orientation

• Extension of the Trench Rescue material in the
  Technical Rescue Awareness class.
• You will learn additional information about
  working safely around a trench rescue scene prior
  to the arrival of qualified trench rescue
  personnel.

3
Orientation

• This class does not qualify you for OSFM
  certification, nor does is qualify you for entry
  at a trench rescue operation.
• This information is intended to give the first-in
  company an idea of what to do and how to go about
  it safely.

4
Terms to Know

• Angle of Repose the greatest angle above the
  horizontal plane at which loose dirt will lie
  without sliding.
• Back Fill the refilling of a trench, or the
  material used to refill a trench, or to fill a
  void between two surfaces.
• Spoil Pile the material excavated from the
  trench.

5
More Terms to Know

• Fin Form ¾, 14-ply, arctic white birch.
• Strong Back a 2 x 10 or 2 x 12 attached to fin
  form to create a panel for shoring the wall of a
  trench.
• Struts the horizontal bracing between the
  trench walls.
• Uprights vertical supports, usually 2 x 8s,
  the depth of the trench.
• Ground Pads 4x8 or 2x8 sheets of plywood used
  to disperse weight around the edge of the
  trench.

6
Where do we see trenches?

• Commonly seen occupied and unprotected
• Public works routinely work in trenches.
• Pipeline cable installation.
• Areas of new construction (water, sewer)

7

• Fin-form strong backs
• Air-Shore strut
• Paratech strut
• Back fill (wood dirt)
• Ground pads

8

• Use of multiple types of shores
• Fin-form strong backs
• Ground pads
• Whalers
• Escape ladders

9
OSHA

• Defines a trench as an excavation that is deeper
  than it is wide and is no more than 15 wide.
• Has regulations governing operations in trenches
  5 deep or deeper.
• Regulations apply to rescues.
• Provides guidelines for trenches up to 15 wide
  and 20 deep. Custom engineering is required by
  a Registered Professional Engineer beyond those
  limits.

10
60 to 65 OF ALL FATALITIES ARE THE WOULD-BE
RESCUER

• Lack of knowledge
• Lack of training
• Compassion for the victim

11
Trenches are Dangerous

• Once earth is disturbed, pressure begins to act
  on the trench walls.
• Sooner or later all trenches cave in.
• There is no way to predict when a trench will
  fail.

12
Note the deterioration to the left corner
13
Vibration Hazards

• All heavy equipment should be turned off and
  secured (take the keys and block the tires).
• All sources of vibration should be eliminated for
  300 in every direction. This includes roadways
  and railways.

14
Backhoes

• Backhoe operators will insist they can dig the
  victim out.
• OSHA statistics are riddled with cases of
  disembowelment and decapitation.
• Backhoe operators cannot tell the difference
  between a rock and a body.
• Weight of the backhoe adds to instability of
  trench walls.
• Vibration likely to speed up secondary collapse

15
Atmospheric Hazards

• The victim may be the result of bad air in the
  trench and have no actual trauma.
• Air should be monitored every 15 minutes for O2,
  CO, H2S and combustibles.
• Rescuers can fall victim to the same bad air if
  it is not checked regularly.
• O2 permissible exposure limits 19.5-23.5.
• Methane Gas Flammable Limits 5.0-15.0.

16
Public Utilities as a Hazard

• Many trenches are dug for utility maintenance or
  installation.
• Utility cables and pipes can add to trench
  instability.
• Electrical utilities can pose a threat to both
  the victim and the rescuer.
• Broken sewer or water lines may fill the trench,
  causing a drowning potential for the victim.

17
CONTACT WITH UTILITIES CAN BE DANGEROUS CAUSE
DISRUPTION TO SERVICE
ROADWAY UNDERMINING
18
Heavy equipment can fall into the trench trapping
workers
Workers can be struck by operating heavy
equipment
19
Digging their own grave
20
Seattle, WA 8/8/2000 Worker killed Rescuers using
camera to locate victims body
21
Lebanon, MO 1989 Hit 10 propane pipeline Killed
operator
22
1996 - Operator burned after hitting 8 gasoline
pipeline
23
St. Paul, MN - 1993 City crew working on sewer
line hit natural gas line Killed 3, injured 11
24
1988 Hit propane line 3 Workers injured
25
Dirt as a Hazard

• One cubic foot of dirt weighs 90-145 lbs.
• The average collapse is 1.5 cubic yards (4000
  lbs.).
• The average victim buried under 2 feet of dirt
  will be covered by 3000 lbs., about 1000 lbs. of
  that will be on his chest.
• The speed of collapsing dirt is often less than
  1/10th of a second.

26
TimeTimeTime

• The average trench rescue takes between 4 and 10
  hours.
• Long rescue time allows for further deterioration
  of trench walls.
• Rotation of rescue crews necessary to keep people
  fresh.

27
The First-In Company

• Apparatus should be located no closer than 50 to
  the trench and should be shut down.
• Locate the victim and try to find out what was
  being done at the time of the accident from
  someone else on the scene.
• Approach the trench from the end, never from the
  side and stay as far away as possible.

28
The First-In Company

• If the victim is conscious, he may be able to
  rescue himself if a ladder and/or shovel is
  lowered to him.
• Call Orland Dispatch (708/403-5584) and activate
  a CART box for a trench rescue.
• Keep everyone back from the trench and shut down
  all machinery on the scene.
• Shut down all roads and railways for a 300
  radius from the scene.

29
The First-In Company

• Identify any utilities that my be marked by JULIE
  at the scene.
• Orange Communications
• Red Electric
• White Excavation Boundaries
• Yellow Natural Gas
• Green Sewer
• Blue - Water

30
The First-In Company

• The location of an unconscious or trapped victim
  can be marked with paint or dry-chem at the edge
  of the trench.
• Ground pads will need to be laid around the edge
  of the trench.
• The spoil pile must be moved a minimum of 2 away
  from the edge of the trench. This must be done
  while working off ground pads.

31
Water, Water Everywhere

• Prior to the rescue team entering the trench, all
  water must be evacuated. This includes water
  from a main break, ground water and rain water.
• Small amounts of water can be removed with a sump
  pump in a 5 gallon bucket.
• Larger amounts of water or water which is flowing
  can be removed with a vac-truck.
• The truck must be set up 300 away and have a
  safety valve in line with the vacuum hose.

32
Incident Command

• Establish a trench team command structure
• Rescue Officer (required) Officer in charge of
  the rescue and designates other rescue sectors.
• Rescue Safety (required ) May be in addition to
  the scene safety officer and trained to the
  level of the incident.
• Rescue Operations Officer who runs the rescue.

33
Medical Care for the Trench Victim

• Establish medical care for the victim as soon as
  protection is established and victim is accessed.
• Prepare for open closed fractures, chest
  injuries, spinal injuries, crush syndrome,
  hypothermia, dehydration and hypoxia.
• Give the victim a head, eye and respiratory
  protection as soon as possible.

34
Trench Rescue Hazards

• Hazards are not obvious
• Secondary collapses are common
• Dirt is heavy and moves fast
• Rescues are usually long-term operations
• Backhoes are not safe for victim rescue
• OSHA has trench limits and regulations
• Buried utilities can pose a threat to rescuers
• Impact or entrapment from falling debris or
  equipment
• Unprotected trenches are dangerous
• There may be inadequate equipment for shoring
• Possible legal liabilities for fire officers

35
The End
