Brain Stem II

1
Brain Stem II

• Basic Neuroscience
• James H. Baños, Ph.D.

2
Today

• Brain Stem Reticular Formation
• Corticobulbar tract
• Cranial nerves and their nuclei

3
Major Brain Stem Activities

• Conduit
• Ascending and descending pathways
• Integrative functions
• Complex motor patterns
• Respiratory and cardiovascular activity
• Regulation of arousal and level of consciousness
• Cranial Nerve functions

4
Integrative FunctionsBrain Stem Reticular
Formation
5
Brain Stem Reticular Formation

• Reticular netlike
• Loosely defined nuclei and tracts
• Extends through the central part of the medulla,
  pons, and midbrain
• Intimately associated with
• Ascending/descending pathways
• Cranial nerves/nuclei
• Input and output to virtually all parts of the CNS

6
Brain Stem Reticular Formation
7
Brain Stem Reticular Formation

• Can be roughly divided into three longitudinal
  zones
• Midline - Raphe Nuclei
• Medial Zone - Long ascending and descending
  projections
• Lateral Zone - Cranial nerve reflexes and
  visceral functions

8
Brain Stem Reticular Formation

• Connectivity is extremely complex
• Many different types of neurons
• Innervate multiple levels of the spinal cord
• Numerous ascending and descending collaterals
• Some have bifurcating collaterals that do both
• Many have large dendritic fields that traverse
  multiple levels of the brain stem

9
Brain Stem Reticular Formation
10
Reticular Formation Functions

• I. Participates in control of movement through
  connections with both the spinal cord and
  cerebellum
• Two reticulospinal tracts originate in the
  rostral pontine and medullary reticular formation
• Major alternate route by which spinal neurons are
  controlled
• Regulate sensitivity of spinal reflex arcs
• Tonic inhibition of flexor reflexes
• Mediates some complex behavioral reflexes
• Yawning
• Stretching
• Babies suckling
• Some interconnectivity with cerebellar motor
  control circuitry

11
Clinical Correlation

• Pseudobulbar affect (as seen in Amyotrphic
  Lateral Sclerosis)
• Degeneration of descending motor pathways from
  the cortex to the brainstem
• Release of some of complex motor behaviors such
  as laughing and crying
• Usually uncontrollable, not consistent with mood
• May laugh when angry, cry at sad things, etc
• Conceptually analogous to upper motor neuron
  hyperreflexia
• Disinhibited spinal reflexes are very simple
• Disinhibited brainstem reflexes are very complex

12
Clinical Correlation

• The Terri Schiavo case

13
Reticular Formation Functions

• II. Modulates transmission of information in pain
  pathways
• Spinomesencephalic fibers bring information about
  noxious stimuli to the periaqueductal grey
• Periaqueductal grey also receives input from the
  hypothalamus and cortex about behavioral and
  drive states
• Efferents from the periaqueductal grey project to
  one of the raphe nuclei and medullay reticular
  formation
• These project to the spinal cord and can suppress
  transmission of pain information in the
  spinothalamic tract

14
Reticular Formation Functions
Cortex
Hypothal
Thalamus
Periaqueductal Grey
Spinothalamic Tract
Raphe
Spinal Cord Level
15
Clinical Correlation

• Pain Management
• Periaqueductal grey has high concentration of
  opiate receptors
• Natural pain modulation relies on endogenous
  opiates
• Exogenous opiates are used for pain management

16
Pause for contemplation!

• Major recurring theme LOOPS
• Many brain functions are represented in loops
  (usually with a modulatory influence)
• Muscle tone
• Reflex loops
• Pain modulation
• Pathology and treatment of pathology are often
  related to modulating these loops
• Many of the basic pathways are supplemented by
  more complex pathways that complete this
  modulated loop architecture

17
meanwhile, back at the reticular formation

• III. Autonomic reflex circuitry
• Reticular formation receives diverse input
  related to environmental changes
• Also receives input from hypothalamus related to
  autonomic regulation
• Output to
• cranial nerve nuclei
• Intermediolateral cell column of the spinal cord
• Involved in
• Breathing
• Heart rate
• Blood pressure
• Etc.

18
Clinical Correlation

• Damage to the medulla often kills you
• Horners Syndrome
• Interruption of descending pathways to the
  intermediolateral cell column
• Ipsilateral Miosis (small pupil)
• Ipsilateral Ptosis (drooping eyelid)
• Ipsilateral Flushing/lack of sweating

19
Reticular Formation Functions

• IV. Involved in control of arousal and
  consciousness
• Input from multiple modalities (including pain)
• Ascending pathways from RF project to thalamus,
  cortex, and other structures.
• Thalamus is important in maintaining arousal and
  cortical tone
• This system is loosely defined, but referred to
  as the Ascending Reticular Activating System
  (ARAS)
• ARAS is a functional system, not an anatomically
  distinct structure

20
Clinical Correlation

• Normal functions
• Sleep/wakefulness
• Loss of Consciousness
• Traumatic brain injury
• Smelling salts, sternal rubs, and the ARAS
• Coma
• Can result from extensive damage to cortex
• More focal damage to ARAS
• Coma vs Minimally Conscious State
• Intact sleep/wake patterns in brain activity

21
The Corticobulbar Tract
22
The Corticobulbar Tract

• Corticospinal tract
• Descending motor pathways to ventral horn of the
  spinal cord
• Includes only fibers for torso, arms, legs (i.e.,
  headless HAL)
• Decussates at a single point in the pyramids of
  the medulla (pyramidal decussation)

23
The Corticobulbar Tract

• Corticobulbar tract
• Descending motor pathways to cranial nerve nuclei
• Includes descending fibers for HALs head
• Fibers for each CN nucleus decussate at the level
  of that nucleus (i.e., multiple points of
  decussation)

24
(No Transcript)
25
Cranial Nerves and Their Nuclei
26
A word about organization

• Sensory and motor spinal nerves can be divided
  into
• Sensory (dorsal)
• Somatic - pain, temperature, mechanical stimuli
• Visceral - from receptive endings
• Motor (ventral)
• Somatic - Innervate skeletal muscle
• Visceral - To visceral autonomic ganglia

27
A word about organization

• Cranial Nerves also include
• Special Sensory fibers
• Hearing, equilibrium, etc
• Special motor fibers
• Branchial motor
• Muscles of the head and face
• Different embryologic origin and location
• Otherwise, structurally and functionally the same
  as other muscle
• Autonomic fibers

28
A word about organization

• All of these fiber types organize predictably
  around the sulcus limitans

See p. 292
29
A word about organization
See p. 294, 296
30
Starting from the topCN I
31
Starting from the topCN I - Olfactory

• Fiber types
• Special Sensory -- Smell
• The olfactory bulb and tract arent really CNI
• The fibers of CNI originate in the olfactory
  mucosa of the nasal cavity, pass through the
  cribiform plate, and synapse onto the olfactory
  bulb
• Note that there is no brain stem nucleus for CNI

32
Cribiform plate
Olfactory bulb
CN I
33
Clinical Correlation

• Olfactory nerve dysfunction is often reported as
  altered taste and smell
• Conditions affecting CNI include
• Upper respiratory tract infection
• Traumatic Brain Injury (TBI)
• Subfrontal meningioma
• Dementia

34
Clinical Correlation

• Anosmia - Total loss of smell
• Hyposmia - Partial loss of smell
• Hyperosmia - Exaggerated sense of smell
• Dysomia - Distorted sense of smell
• Olfactory hallucinations - Associated with
  seizures

35
CN II - Optic
36
CN II - Optic

• Fiber Types
• Special Sensory -- Vision
• Retinal ganglion cells to
• Thalamus (lateral geniculate nucleus) -- Primary
  visual pathway
• Superior colliculus -- Reflexes involving vision
  and light
• Hypothalmus -- Light-dependent behavioral cycles
• Does not have a specific nucleus in the brain stem

37
CN III - Oculomotor
38
CN III - Oculomotor

• Somatic Motor - Eye movement
• Superior, inferior, medial recti
• Inferior oblique
• Levator palpebrae superioris
• Autonomic - Pupillary constriction
• Edinger-Westphal nucleus to pupillary sphincter

39
CN III - Oculomotor
Edinger-Westphal
Nucleus of III
40
CN III - Oculomotor

• Eye movement
• Superior rectus - elevation
• Inferior rectus - depression
• Medial rectus - adduction
• Inferior Oblique - extorsion/elevation
• Levator palpebrae superioris?

41
CN III - Oculomotor

• CN III Oculomotor
• Pillars that hold the eye open
• CN VII Facial
• Hook that pulls the eye closed

7
III
42
CN III - Oculomotor

• Edinger-Westphal nucleus
• Receives bilateral projections from superior
  colliculi (which had received unilateral
  projections from CN II)
• This is the efferent component of the pupillary
  light reflex
• Also involved in pupillary accomodation

43
Clinical Correlation

• Damage to CN III or nucleus of III
• Down and out eyeball
• Diplopia
• Ptosis
• Dilated and fixed pupil
• Paralysis of pupillary accommodation
• Can be cause by
• Uncal/transtentorial herniation
• Aneurysm

44
Clinical Correlation

• Pupillary light reflex
• Direct
• Consensual

II - left
III - left
II - right
III - right
45
Clinical Correlation
II - left
III - left
II - right
III - right
46
Clinical Correlation
II - left
III - left
II - right
III - right
47
Clinical Correlation
II - left
III - left
II - right
III - right
48
CN IV - Trochlear
49
CN IV - Trochlear

• Somatic Motor
• Superior Oblique - Intorts, depressed, adducts
  the eye

50
CN IV - Trochlear
Nucleus of IV
51
CN VI - Abducens
52
CN VI - Abducens

• Somatic Motor
• Lateral Rectus

53
CN VI - Abducens
III
III
IV
IV
VI
VI
54
Finally, lets add a pathway

• What muscles are being used when we look left or
  right?
• What cranial nerves?
• Is the same thing happening on each side?

55
Finally, lets add a pathway

• During horizontal conjugate eye movements, each
  eye is doing the opposite of the other
• Adduction (CN III) on one side
• Abduction (CN VI) on the other side
• This is accomplished by cross wiring the nuclei
  via the medial longitudinal fasciculus (MLF)

56
Finally, lets add a pathway
57
Learn More
University of California -- Davis Eye Simulation
Website
http//cim.ucdavis.edu/eyes/version15/eyesim.html
58
Coming Up

• Tomorrow
• More cranial nerves
• Thursday
• Diencephalon
