Title: Data Storage and Backup Strategies


1
Data Storage andBackup Strategies
  • Joe Cicero
  • Revised by Jeanne Conlon
  • Northeast Wisconsin Technical College

2
This Presentation Will Cover
  • Hard Copy - paper
  • Floppy
  • Zip Disk
  • USB Memory Stick / Flash Memory
  • Backup Partition
  • External / 2nd Hard Drive usb / 1394 etc
  • Tape
  • CD-R / CD-RW
  • DVD-R / DVD-RW

3
Data Storage / Backup MediaThings to consider
  • Ease of use
  • Ease of setup
  • Durability (MTBF mean time before failure)
  • The ability of a product to be reused, without
    significant degradation.
  • Resilience
  • Resilience generally means the ability to recover
    from some shock, or disturbance.
  • Susceptibility to EMI
  • Electromagnetic Interference. A naturally
    occurring phenomena when the electromagnetic
    field of one device disrupts, impedes or degrades
    the electromagnetic field of another device by
    coming into proximity with it.
  • Capacity
  • The amount of space inside a container provided
    for a given amount of product.
  • Transfer rates
  • The rate at which data can be transferred,
  • Cost
  • Reuse
  • Portability

4
Hard Copy - Paper
  • Pros
  • Ease of use
  • Easy to print things
  • Ease of setup
  • Easy to setup a printer
  • Durability (MTBF)
  • Fire / Water but other media will have a problem
    with this also
  • Resilience
  • Dependent upon type of paper and ink
  • Susceptibility to EMI
  • No
  • Cons
  • Ease of use
  • It is not electronically searchable!
  • Capacity
  • How much paper do you have?
  • Transfer rates
  • Slow, print everything?

5
Floppy
  • Pros
  • Ease of use
  • Pretty easy to use (if your system has one)
  • Ease of setup
  • Requires little or no setup.
  • Durability (MTBF)
  • Drive has 30000 power on hours / 3.2 years
  • Re-usable
  • Yes, but may cause failure sooner
  • Portable
  • Yes, but not if you have large amounts of data
  • Cons
  • Durability (MTBF)
  • Floppies fail often
  • Resilience
  • Only somewhat resilient
  • Susceptibility to EMI
  • Yes
  • Capacity

6
Zip Disks
  • Pros
  • Ease of use
  • Fairly easy to use (much like a floppy)
  • Durability (MTBF)
  • Disk is 100000 hours / Over 10 years on drive
    (est.)
  • Resilience
  • Only somewhat resilient about the same as a
    floppy
  • Capacity
  • Up to 750 Meg
  • Transfer rates
  • Up to 7.5 MB/sec
  • Reuse
  • Yes, but may cause failure sooner
  • Portable
  • Yes
  • Cons
  • Susceptibility to EMI
  • Yes
  • Ease of setup

7
USB Memory Stick
  • Pros
  • Ease of use
  • Very easy to use plug and play!
  • Ease of setup
  • In most cases requires no setup
  • Durability (MTBF)
  • Pretec --gt MTBF 500,000 hours (powered
    on)Simpletech --gt MTBF 1M hoursSanDisk --gt
    MTBF 3M hoursBitMicro --gt MTBF 2M hours 228
    years
  • Resilience
  • Very Resilient
  • Susceptibility to EMI
  • No
  • Capacity
  • Depends up to 16 Gig now (200.00)
  • Transfer rates
  • 30 MB/sec
  • Cost
  • Depends on size but use a size to cost ratio
    and it is fairly inexpensive
  • Reuse
  • Yes

8
Backup Partition
  • Pros
  • Ease of use
  • Yes, already in system, just requires creation
  • Ease of setup
  • Pretty easy, built in software will allow for
    this.
  • Durability (MTBF)
  • Depends of type of drive ATA, SCSI, SATA. One of
    western digitals 5-year warranty and 1.2 million
    hours MTBF
  • Resilience
  • Fairly Resilient
  • Susceptibility to EMI
  • Yes, but not as susceptible as a floppy or zip
    disk
  • Capacity
  • Very high now.
  • Transfer rates
  • 100MB per second data transfer rate.
  • Cost
  • No additional cost involved its a second
    partition!
  • Reuse
  • Yes

9
External Hard Drive
  • Pros
  • Ease of use
  • As easy as a flash drive
  • Ease of setup
  • No special setup required most of the time
  • Durability (MTBF)
  • Same as an internal hard drive (5 years)
  • Resilience
  • Fairly resilient
  • Susceptibility to EMI
  • Yes, but not as much as other media
  • Capacity
  • Very high now
  • Transfer rates
  • 100MB per second data transfer rate.
  • Cost
  • Depends on size and where you buy can be costly
    (250 GB HD 99.00)
  • Reuse
  • Yes

10
Tape
  • Pros
  • Ease of use
  • Not hard but not easy.
  • Ease of setup
  • Requires special hardware and software.
  • Durability (MTBF)
  • a Travan tape drive has a MTBF of 370000 hours
    45 years
  • Resilience
  • Worse than a disk, a tape is very mechanical.
  • Capacity
  • Huge - 320GB Compressed Data Capacity
  • Transfer rates
  • Ive seen anywhere from 2 40 MBps
  • Reuse
  • Yes, but I get worried about using them over and
    over again.
  • Portability
  • Yes
  • Cons
  • Durability (MTBF)

11
CD-R / CD-RW
  • Pros
  • Ease of use
  • Fairly easy especially now that software is
    built into Windows
  • Ease of setup
  • Most systems come with CDR/RW already installed.
  • Durability (MTBF)
  • Plextor 60000hrs MTBF 6 years
  • Susceptibility to EMI
  • No
  • Capacity
  • 700 MB
  • Transfer rates
  • Mitsumi, Data Transfer Rate, 33.0 MB/s
  • Cost
  • When purchased in bulk pennies per!
  • Reuse
  • RW yes, R no
  • Portability
  • Yes

12
DVD
  • Pros
  • Ease of use
  • Not much different than CD-R
  • Ease of setup
  • Not much different than CD-R
  • Durability (MTBF)
  • Plextor DVD MTBF 60 000h 6 years
  • Susceptibility to EMI
  • No
  • Capacity
  • Typically 4-8 GB, However Nanotech to increase
    DVD capacity to 850 GByte
  • Transfer rates
  • 8X DVD drive can transfer data at a whopping
    11.08MB
  • Cost
  • Anywhere from .30 to 1.45
  • Reuse
  • DVD-RW Yes, DVD-R No
  • Portability
  • Yes

13
Web Links
  • http//www.webopedia.com/TERM/R/RAID.html
  • http//www.sata-io.org/esata.asp
  • http//www.pc4usa.com/DetailSales.asp?productID12
    14parCatScatn29Catn6
  • http//electronics.howstuffworks.com/dvd3.htm
  • http//www.theeldergeek.com/hard_drives_10.htm
