Chemgard Overview

• What is Photoacoustic Infrared and how does it
  compare with other technologies
• Review of traditional IR
• PIR Theory What happens when light meets sound?
• Comparison w/ traditional IR
• Electrochemical Sensors
• Flame Ionization Detectors
• Gas Chromatography
• Solid State Sensors
• Chemgard Markets Applications

3
Photoacoustic Infrared Gas Detection Technology

• To better understand the advantages of
  Photoacoustic Infrared Technology, we will
  briefly compare it to the older, more commonly
  used Absorptive Infrared Technology.
• How Does It Differ?

4
Infrared Detection Methodology

• Both absorptive and photoacoustic techniques
  utilize infrared energy of a selective
  wavelength.
• Majority of gases absorb infrared energy of
  various wavelengths.
• The wavelength selected for use in detection is
  determined by the gas in use and its specific
  characteristics.

5
Infrared Technology

• Red is representative of a typical gas absorption
  characteristic.
• Yellow is an infrared wavelength used to detect
  this specific gas.

6
Absorptive Technique

• All absorptive infrared detection methods differ
  from manufacturer-to-manufacturer. However, the
  basic principal remains the same.
• Sample and Reference measurements must be taken.
• The Sample cell is exposed to the gas to be
  detected.
• The Reference cell is either isolated from the
  gas to be detected or infrared energy outside the
  absorptive wavelength characteristics of the gas
  to be detected is used.
• The two measurements are compared. If they are
  equal, the instrument will indicate zero (0).

7
Absorptive Technique

• When the gas to be detected is present, it
  absorbs some portion of the Sample infrared
  energy.
• The Reference infrared energy is unaffected by
  the gas to be detected.
• The change in ratio of the Sample and Reference
  detectors is the actual concentration of gas
  present.

8
Photoacoustic Infrared Technology

• Has been in use since the 1960S
• MSA 10 Years of experience in PIR gas monitors
• Has replaced many traditional infrared analyzers
  as well as other sensing technologies

9
Advanced Technology

• Photoacoustic Infrared sensing technology differs
  from all other available detection techniques on
  the market.
• It has Two distinct advantages
• The ability to sense a leak as low as in the PPB
  level for some applications.
• The ability to operate long periods of time
  without adjustment or zero drift, a common
  problem with all other technologies in use today.

10
Basic PIR Cell Assembly
11
Photoacoustic IR Optical Bench

• IR source - wire filament emitting multiple
  wavelengths of light
• Chopper (not shown) - used to setup modulation
• Optical filters
• provide sensitivity and selectivity for a given
  gas
• selected for specific application
• Optical block - volume can be changed for
  specific ranges
• Detector-high sensitivity microphone
• Solenoid valves - sample inlet and outlet provide
  seal during photoacoustic gas detection
• Heater and thermostat - temperature control
  critical for low PPM or PPB detection

12
Photoacoustic Infrared Technology

• Sample Gas Enters the Cell..

13
Toxic Gas Sensors
14
Electrochemical Sensors
15
Flame Ionization Detectors
16
Gas Chromatographs
17
Solid State Sensors
18
Chemical Tape Technology
19
Technology Comparison
20
Gas Detection Comparison
21
Chemgard Applications

• Applications include
• CO, CO2, cleaning agents, solvents, heat transfer
  fluids many other common industrial chemicals
• Photoacoustic Infrared Gas Detection used in
• plastics, paint, automotive, pharmaceutical,
  semiconductor, rubber other general chemical
  industries

22
Some Chemgard Customers

• 3M
• Air Products
• BASF
• Chrysler
• Dow Chemical Co
• Dupont
• GE Plastics
• Kimberly Clark
• LA Municipal Authority
• Miller Brewing
• Mitsubishi
• Praxair
• Toshiba
• Walt Disney
• Xerox

23
The Chemgard Advantage
24
The Chemgard Advantage
25
The Chemgard Advantage
26
The Chemgard Advantage
27
Chemgard Industries
28
Petrochemical Industries
29
Plastics Paint Industry
30
Agricultural Industry
31
Rubber Industry
32
Medical Pharmaceutical Industry
33
Semiconductor Industry
34
Automotive Industry
35
The Chemgard Advantage

• Utilizes Photoacoustic Infrared Gas Detection
  Technology
• Can detect a wide range of industrial compounds
• Detection of Percent, PPM or in some cases PPB
  levels
• High Sensitivity and Selectivity to Gas of
  Interest
