USB Universal Serial Bus

1
USBUniversal Serial Bus

• Omid Fatemi
• Interface Design

2
Motivations

• Connection of the PC to Telephone
• The USB provides a ubiquitous link that can be
  used across a wide range of PC-to-telephone
  interconnects.
• Ease of use
• Hot plug
• Port expansion
• The lack of a bi-directional, low-cost,
  low-to-mid speed peripheral bus has held back the
  creative proliferation of peripherals such as
  telephone/fax/modem adapters, answering machines,
  scanners, PDAs, keyboards, mice, etc.

3
USB

• Fast
• Bi-directional
• Isochronous
• low-cost
• dynamically attachable serial interface
• consistent with the requirements of the PC
  platform of today and tomorrow

4
Goals for USB

• The following criteria were applied in defining
  the architecture for the USB
• Ease-of-use for PC peripheral expansion
• Low-cost solution that supports transfer rates up
  to 12Mb/s
• Full support for real-time data for voice, audio,
  and compressed video
• Protocol flexibility for mixed-mode isochronous
  data transfers and asynchronous messaging
• Integration in commodity device technology
• Comprehension of various PC configurations and
  form factors
• Provision of a standard interface capable of
  quick diffusion into product
• Enabling of new classes of devices that augment
  the PCs capability.

5
Taxonomy of Application Space
6
Feature list

• Easy to use for end user
• Single model for cabling and connectors
• Electrical details isolated from end user (e.g.,
  bus terminations)
• Self-identifying peripherals, automatic mapping
  of function to driver, and configuration
• Dynamically attachable and re-configurable
  peripherals
• Wide range of workloads and applications
• Suitable for device bandwidths ranging from a few
  kb/s to several Mb/s
• Supports isochronous as well as asynchronous
  transfer types over the same set of wires
• Supports concurrent operation of many devices
  (multiple connections)
• Supports up to 127 physical devices
• Supports transfer of multiple data and message
  streams between the host and devices
• Allows compound devices (i.e., peripherals
  composed of many functions)
• Lower protocol overhead, resulting in high bus
  utilization

7
Feature list (con)

• Isochronous bandwidth
• Guaranteed bandwidth and low latencies
  appropriate for telephony, audio, etc.
• Isochronous workload may use entire bus bandwidth
• Flexibility
• Supports a wide range of packet sizes, which
  allows a range of device buffering options
• Allows a wide range of device data rates by
  accommodating packet buffer size and latencies
• Flow control for buffer handling is built into
  the protocol
• Robustness
• Error handling/fault recovery mechanism is built
  into the protocol
• Dynamic insertion and removal of devices is
  identified in user-perceived real-time
• Supports identification of faulty devices

8
Feature list (con)

• Relation with PC industry
• Protocol is simple to implement and integrate
• Consistent with the PC plug-and-play architecture
• Leverages existing operating system interfaces
• Low-cost implementation
• Low-cost sub-channel at 1.5Mb/s
• Optimized for integration in peripheral and host
  hardware
• Suitable for development of low-cost peripherals
• Low-cost cables and connectors
• Uses commodity technologies
• Upgrade path
• Architecture upgradeable to support multiple USB
  Host Controllers in a system

9
USB System Description

• USB interconnect
• USB devices
• USB host.

10
USB Interconnect

• Bus Topology Connection model between USB
  devices and the host.
• Inter-layer Relationships In terms of a
  capability stack, the USB tasks that are
  performed at each layer in the system.
• Data Flow Models The manner in which data moves
  in the system over the USB between producers and
  consumers.
• USB Schedule The USB provides a shared
  interconnect. Access to the interconnect is
  scheduled in order to support isochronous data
  transfers and to eliminate arbitration overhead.

11
BUS Topology
12
Physical Interface
13
Throughput

• Low speed
• 1.5 Mbps
• Full speed
• 12 Mbps
• High speed (in USB 2.0)
• 480 Mbps
• Dynamic mode switching
• Clock encoding scheme NRZI (Non Return to Zero
  Invert)

14
Power Distribution

• Devices
• Bus-powered devices
• Self-powered devices
• Power management
• Host based
• Power events
• Suspend
• Resume

15
Bus Protocol

• Polled bus
• Data transfers initiated only by host controller
• Three packets
• Token packet
• Type
• Direction
• Address
• End point number
• Data packet
• Handshake packet
• ACK
• NAK

16
Transfer Model

• Pipe
• Stream pipes
• No USB standard format
• Message pipes
• USB format
• Request
• Data
• Status
• End point zero
• Default control pipe
• Always exists

17
Data Flow Types

• Control Transfers
• Used to configure a device at attach time and can
  be used for other device-specific purposes,
  including control of other pipes on the device.
• Bulk Data Transfers
• Generated or consumed in relatively large and
  bursty quantities.
• Interrupt Data Transfers
• Used for characters or coordinates with
  human-perceptible echo or feedback response
  characteristics.
• Isochronous Data Transfers
• Occupy a pre-negotiated amount of USB bandwidth
  with a pre-negotiated delivery latency. (Also
  called streaming real time transfers).

18
USB Devices

• All have endpoint zero
• Hub
• Function
• Compound

19
Typical Configuration
20
Host Responsibility

• Detecting the attachment and removal of USB
  devices
• Managing control flow between the host and USB
  devices
• Managing data flow between the host and USB
  devices
• Collecting status and activity statistics
• Providing power to attached USB devices.

21
Implementer Viewpoints

• USB Physical Device A piece of hardware on the
  end of a USB cable that performs some useful end
  user function.
• Client Software Software that executes on the
  host, corresponding to a USB device. This client
  software is typically supplied with the operating
  system or provided along with the USB device.
• USB System Software Software that supports the
  USB in a particular operating system. The USB
  System Software is typically supplied with the
  operating system, independently of particular USB
  devices or client software.
• USB Host Controller (Host Side Bus Interface)
  The hardware and software that allows USB devices
  to be attached to a host.

22
USB Implementation Areas
23
Physical / Logical Bus Topology
24
USB Host / Device View
25
USB Communication Flow
26
Control Transfer Format

• Setup packet
• Data packet
• Acknowledge packet
• USB defined structure
• Setup packet 8 bytes
• Maximum data payload size
• Full speed 8, 16, 32 or 64 bytes
• Low speed 8 bytes

27
Control Transfer Constraints

• Best effort
• 10 frame time for control
• Use also remaining 90 if no interrupt or
  isochronous transfer

28
Full-Speed Control Transfer Limits
29
Low Speed Control Transfer Limits
30
Isochronous Transfers

• Guaranteed access to USB bandwidth with bounded
  latency
• Guaranteed constant data rate through the pipe as
  long as data is provided to the pipe
• In the case of a delivery failure due to error,
  no retrying of the attempt to deliver the data.
• Stream pipe
• Uni-directional
• Maximum data payload 1023 bytes
• Only in Full speed.
• No more 90 of frame for isochronous, interrupt

31
Isochronous Limits
32
Interrupt Transfers

• Guaranteed maximum service period for the pipe.
• Retry of transfer attempts at the next period, in
  the case of occasional delivery failure due to
  error on the bus.
• Max. Payload size
• Full speed 64 bytes
• Low speed 8 bytes
• If there is sufficient bus time, for requested
  payload size the pipe is established.

33
Full Speed Interrupt Limits
34
Low Speed Interrupt Limits
35
Bulk Transfers

• Large amount of data.
• Access to the USB on a bandwidth-available basis.
• Retry of transfers, in the case of occasional
  delivery failure due to errors on the bus.
• Guaranteed delivery of data, but no guarantee of
  bandwidth or latency.
• Stream pipe
• Only in full speed
• Max. Payload only 8, 16, 32 or 64 bytes

36
Bulk Transfer Limits
37
Connectors
38
Full Speed CMOS Driver
39
Evaluation Setup
40
NRZI Encoding
41
Bit Stuffing
42
Flow Diagram for Bit Stuffing
43
Signaling Levels
44
Signals

• Low and Full speed devices
• A differential 1 is transmitted by pulling D
  over 2.8V with a 15K ohm resistor pulled to
  ground and D- under 0.3V with a 1.5K ohm resistor
  pulled to 3.6V.
• A differential 0 on the other hand is a D-
  greater than 2.8V and a D less than 0.3V with
  the same appropriate pull down/up resistors.
• The receiver defines a differential 1 as D
  200mV greater than D- and a differential 0 as
  D 200mV less thanD-.
• The polarity of the signal is inverted depending
  on the speed of the bus. Therefore the terms J
  and K states are used in signifying the logic
  levels. In low speed a J state is a
  differential 0. In high speed a J state I s a
  differential 1.

45
Differential and Single Ended

• Differential signals mostly for data
• Certain bus states by single ended signals on D,
  D- or both.
• For example a single ended zero or SE0 can be
  used to signify a reset if held more than 10ms.
• SE0 is holding down both D- and D below .3V
• Low and Full speed
• 90 Ohms /- 15

46
Standard Chapters
47
Selected Problems
