Search Coverage

1
(No Transcript)
2
Air OperationsBranch Director Course

• Navigation Fundamentals Understanding GPS for
  Sortie Planning

3
Goals for understanding

• Prepare mission staff to be able to plan and
  brief missions that can be executed efficiently
  and conveniently with our equipment
• Navigation fundamentals
• Capabilities and limitations of GPS
• Capabilities of Apollo GX55 GPS units in
  Minnesota Wing aircraft
• What information is needed to program the GPS
  unit for search patterns
• What can and cannot be programmed in the GX55
• What can be improvised
• Learn about the gotchas using GPS

4
PART 1Navigation fundamentals

• Latitude and longitude
• Describing directions

5
Latitude

• Parallels
• Measure How Far North or South of Equator
• Zero Degrees is Equator
• 90 Degrees North is the North Pole
• 90 Degrees South is the South Pole

North Latitudes
Equator
South Latitudes
6
Longitude
East Longitude
West Longitude
Prime Meridian
Longitude

• Half Great Circles Intersecting at the Poles
• Measure How Far East or West of England
• Zero Degrees is Prime Meridian (England)
• Numbers between 0 and 180 are either East or West
  Longitude
• 180 Degrees is opposite side of globe from
  England
• near international date line in Pacific Ocean

7
Latitude and Longitude

• Latitude is Based on Earths motion
• Axis of rotation defines poles and Equator
• Longitude is Arbitrary
• Greenwich, England was chosen for prime
  meridian.

8
Wheres Minnesota?

• Twin Cities
• Northern Minneapolis is at 45 Degrees North (half
  way between the Equator and North Pole!)
• 93 Degrees West is roughly the Eastern edge of
  St. Paul.
• The Northwest corner of the state
• Exactly 49 Degrees North
• Roughly 97 Degrees West

9
How Big is One Degree?

• Degrees of Latitude are always the same distance
  apart, about 60 Nautical Miles
• Degrees of longitude vary in distance near the
  poles the lengths are quite small.
• In Minnesota, a degree of longitude is about 40
  to 44 Nautical Miles across

10
Dividing Degrees into Smaller Units

• A Minute 1/60th of a Degree
• roughly a mile in size
• Minutes are usually broken down into tenths of
  minutes
• Alternatively, a Second is 1/60th of a minute

11
Expressing Latitude and Longitude in Degrees and
Minutes

• Small high circle after number denotes degrees
• Apostrophe after number denotes minutes
• Example Minneapolis Flying Cloud Airport
• 44o 49.63 N 93o 27.43 Wread as44 degrees
  49.63 minutes North 93 degrees 27.43 minutes West

12
Expressing Latitude and Longitude in Degrees,
Minutes, and Seconds

• A double-quote after a number denotes seconds
• Example Minneapolis Flying Cloud Airport
• 44o 49 37.8 N 93o 27 25.8 Wread as44
  degrees 49 minutes 37.8 seconds North 93 degrees
  27 minutes 25.8 seconds West

13
Determining Coordinates from a Chart
14
Expressing Direction The Compass Rose
360
330
30
N
60
300
W
E
90
270
120
240
Directions are expressed as a number from 001 to
360
S
210
150
180
15
Magnetic Variation

• The Magnetic North Pole is located in Canada, not
  at the True North Pole.
• The difference in direction between the two poles
  is measured and referred to as magnetic variation

16
Magnetic Variation in the US
-15º
20º
15º
-10º
-5º
0º
10º
5º
Easterly Variation
Westerly Variation
Note These lines move over the years because
the magnetic north pole is in motion
Agonic Line
17
PART 2 - GPS

• Overview of GPS for SAR
• Motivation
• Potential uses for SAR
• How it works
• Accuracy
• Limitations and Gotchas
• Terminology
• Describing search patterns for the GX-55
• Improvising

18
Motivation

• GPS is a powerful tool for search and rescue
• Allows very precise search patterns
• Makes manageable what would otherwise be very
  difficult patterns
• Expanding square at any angle
• Creeping line along a course
• Offset route searches
• Grid searches over indistinct terrain
• GPS should be our primary tool for Search and
  Rescue navigation
• GPS is of course also very handy for general
  navigation

19
Potential uses of GPS for Air and Ground SAR

• Getting to/from a search area
• Going to a location designated on a map
• Going to a site identified by another SRU
• A ground team going to a site previously
  identified by an aircraft
• Navigation while conducting a search pattern
• Clue logging (and re-finding)

20
GPS for SAR Potential advantages

• More flexible search area partitioning
• More accurate logging
• More accurate search lines
• Easier and more accurate communication of
  location information

21
Other GPS SAR Uses

• Electronic distress signals
• PLBs Personal locator beacons
• ELTs Emergency locator transmitters
• EPIRBs Emergency Position Indicating Radio
  Beacons
• New 406 MHz digital beacons sometimes transmit
  GPS coordinates
• GPS then becomes a tool for both the rescuer and
  the rescued

22
How it Works The Basics

• Spaced-based system (unlike Loran or VOR)
• Constellation of 24 satellites in six orbital
  planes
• 21 active satellites plus 3 operating spares
• In High orbit of about 12,000 miles
• Each circles the Earth about every 12 hours

23
How it Works The Basics

• GPS satellites transmit information
• Pseudo-random code with time information
• Satellite orbital position data
• Almanac data
• Ephemeris data
• Updated atmospheric models
• GPS receiver uses this data to figure out what
  time it is and what time the signals were sent

24
How it Works The Basics

• GPS receiver measures distance to satellites by
  determining the amount of time that the radio
  signal takes to travel from each satellite
• Each distance measurement effectively defines a
  sphere around a satellite
• Multiple satellites must be used to determine a
  position
• Given two satellites, two sphere intersect to
  determine a circle
• Given three satellites, a sphere and a circle
  intersect to determine two points
• A fourth satellite can determine a positive 3D
  position

25
Accuracy

• A complex question
• DOD has a 66 page document describing the
  performance of GPS Standard Positioning Service
  (SPS)
• The short story
• Garmin states that their GPS receivers are
  accurate to within 15 meters on average
• Typically about 6 to 12 Meters accuracy can be
  seen

26
Accuracy

• Accuracy and reliability is actually a complex
  subject. There are many factors that can impact
  system.
• Receiver errors
• Atmospheric (ionosphere) errors
• Solar activity (sun spots and solar storms)
• Location of receiver
• (some parts of the Globe get better coverage than
  others)
• Orbital errors (inaccuracies in the reported
  orbital position)
• Poor satellite geometry (satellites lined up or
  bunched up)
• Limited number of satellites in view
• Satellite malfunctions (or satellites taken out
  of service)
• Multi-path errors (radio signal reflections)
• Results vary hour by hour, day by day

27
Accuracy

• There is a substantial difference between typical
  accuracy and worst-case accuracy
• Described as a statistic x had an error of y
  meters or less
• Typical 95 horizontal error results for a
  typical day

Errors worse than 30 meters are possible given
the potential for various atmospheric conditions
and receiver faults and the possibility that
satellites can be taken out of service
28
Accuracy andSelective Availability

• Past feature of GPS SPS that purposefully
  degraded accuracy of position determination for
  non US-military use
• Civilian accuracy was typically about 100 meters
  under Selective Availability
• SA was discontinued May 1, 2000
• Has not been used since
• It's been replaced by selective deniability,
  which allows the US military to geographically
  designate areas in which to degrade GPS quality.

29
Comparing Accuracy with and without SA A
sample

• The plots show that SA causes 95 of the points
  to fall within a radius of 60.7 yards. Without
  SA, 95 of the points fall within a radius of 7.9
  yards.

30
Comparing Accuracy with and without SA Recap

• Before, with 100 meter typical accuracy allowed
  you to identify what stadium you were in
• Now with 6-12 meter typical accuracy, you can
  tell about which yard line you are on

31
Accuracy WAAS

• Wide-Area Augmentation System
• Designed specifically for aviation
• Commissioned by FAA in 2003
• Uses ground stations and satellites
• 25 ground reference stations cover the entire US
  and parts of Canada and Mexico
• Augments GPS Standard Positioning Service
• Provides better integrity and accuracy
• Typical accuracy of 3-5 meters horizontal, 3-7
  meters vertical
• Can be used for precision approaches

32
Accuracy WAAS

• How it works
• Two master stations, located on either coast,
  collect data from the 25 reference stations and
  create a GPS correction message.
• This correction accounts for GPS satellite orbit
  and clock drift plus signal delays caused by the
  atmosphere and ionosphere.
• The corrected differential message is then
  broadcast through one of two geostationary
  satellites, and is then received by a
  WAAS-capable GPS receiver.

33
Accuracy Differential GPS

• Provides high accuracy for a small area
• Uses a local ground station transmitter
• Accuracy can be better than one inch

34
Limitations

• Requires good line-of-sight to satellites
• May occasionally have difficulty using GPS in
  vehicles
• Generally unusable inside a building (or cave)

35
Other concerns

• GPS can be subject to accidental and intentional
  interference
• Easily jammed using strategically placed
  low-power transmitters
• WAAS is also at risk
• Selective Availability (SA) or SCATANA could be
  instituted during a national emergency (but this
  is unlikely)
• Current plan calls for possible use of Selective
  Denial where GPS is degraded or denied to
  specific geographic areas

36
Gotchas

• True vs. Magnetic directions (a configuration
  option in some units)
• The Apollo GX 55 will always use magnetic
  directions
• Batteries!
• The need for training and practice
• Expressing coordinates
• Seconds vs. Decimal Minutes

37
Terminology

• Describing places
• Describing directions

38
Terminology Waypoint

• A specific named location either defined by the
  user or defined in the instruments database
• Waypoints sometimes come in flavors
• User defined waypoints
• Built-in database waypoints (example an airport)

39
TerminologyDefining Different Directions

• Desired Track / Course
• Bearing
• Track
• Heading
• In general, you should take note whether your
  GPS is giving you directions as True or Magnetic
  directions
• The GX-55 always gives Magnetic directions

40
Describing LocationsA Choice to Understand

• We describe latitude and longitude normally using
  degrees and minutes
• When dealing with fractions of minutes there is,
  however, a choice
• There are essentially two options
• One can use seconds (of which there are 60 in
  one minute)
• One can use decimal-minutes (i.e. tenths and
  hundredths of a minute)
• Many GPS units can be configured to display one
  way or the other

41
Describing LocationsYet another option

• Sometimes, latitude and longitude are expressed
  in degrees only.
• Thus the following are equivalent expressions of
  longitude
• 93o 20 00
• 93.33333o

42
Describing LocationsCAP Standard Method

• The standard we will use in CAP is degrees and
  decimal minutes
• Example
• 45 degrees 35.4 minutes North
• 93 degrees 42.2 minutes West
• This is the standard way the Air Force provides
  coordinates to us for search and rescue
• This is also the way our GX-55 normally displays
  position information
• In CAP we will not usually use seconds unless
  working with another agency that wishes to do so.

43
Describing LocationsCommunicating with Others

• The seconds vs. decimal minutes question is a big
  source of confusion even within single
  organizations
• Some people erroneously say seconds when they
  mean hundredths of a minute
• Some people say point or decimal when they
  should have said minutes and seconds
• Take nothing for granted when getting information
• Be accurate and clear when giving information
• Especially when working with other-agencies,
  triple-check all coordinates to make sure were
  all speaking the same language
• Some organizations normally uses
  Degrees-Minutes-Seconds as their standard way of
  describing positions, but they will use the word
  decimal or point to separate the three parts
  of the coordinate

44
Describing LocationsYet Another Approach to be
Aware of

• Some GPS units also offer the option to display
  position information using Universal Transverse
  Mercator (UTM)
• An alternative to using degrees and minutes
• Beyond the scope of this course

45
GX-55 Search patterns

• Describing the patterns
• Parallel Line (Grid)
• Creeping Line
• Expanding Square
• Route and offset route

46
Parallel Line Search Patterna.k.a. Grid Search

• US Grids are areas 15 minute to a side,
  serially numbered for each sectional chart (MSP
  means Twin Cities sectional)
• 7.5 minute quarter grids are named A, B, C, and D
  in reading order, left to right, top to bottom

47
Parallel Line Search Patterna.k.a. Grid Search

• The GPS unit labels the four corners (and also
  four search pattern entry points) 1, 2, 3, and 4
  clockwise starting in northwest.

1
2
MSP 413 A
4
3
48
Describing a Parallel Line Pattern

• Grid identifier and starting waypoint (i.e.
  corner of quarter-grid)
• Track spacing
• Direction of tracks either E/W or N/S
• Note Search area for a parallel line pattern in
  the GX55 is always a quarter-grid

49
Parallel Line Pattern Example

• Quarter Grid MSP 413A1
• Northwest corner of grid MSP 413A
• Track spacing 1 NM
• Tracks running east to west

MSP 413 A
Track spacing
50
Creeping Line Search Pattern

• Shaped much like a parallel line pattern, but
  with legs aligned perpendicular to a route
  (rather than by ordinal directions)
• Descriptive parts
• Starting point (any waypoint)
• Direction
• Starting left or right side
• Track spacing
• Leg length
• Number of legs

Direction
Track spacing
Leg length
Starting Waypoint
Starting on left side
51
Expanding Square

• Descriptive parts
• Starting waypoint (at center of pattern)
• Initial direction
• Track spacing
• Number of legs

3s
s
s
2s
s
2s
3s
Initial Direction
52
Expanding Square

• Descriptive parts
• Starting waypoint (at center of pattern)
• Initial direction
• Track spacing
• Number of legs

3s
s
s
2s
s
2s
3s
Initial Direction
53
Offset Track Line Searcha.k.a. Route Search

• For a returning route search, 2 passes are made,
  each ½ track spacing offset from base course
• A non-returning route search will have a leg on
  the base course

TO Waypoint
Base Course
FROM Waypoint
54
Offset Track Line Searcha.k.a. Route Search

• For the purpose of using the GPS, we can program
  only one leg at a time
• A route leg will either be
• On the course line (in which case a simple flight
  plan will suffice)
• Offset from the course line
• Described as a distance offset and a direction
  offset (either right or left of course)

55
Improvising

• As a last resort, any GPS can display running
  latitude and longitude
• The crew fly the pattern watching the numbers
• This can be used to guide an arbitrary grid
  search
• Example usage we need to fly a grid which has
  non-standard boundaries
• This generally requires additional preflight
  preparation (to predetermine the lines of
  latitude and longitude)
