WШINK

1
BALUNS

• BY
• VIRGIL LEENERTS
• WØINK
• ARRL Technical Specialist
• Email w0ink_at_arrl.net

2
TOPICS

• The BALUN Antenna Problems
• What is a BALUN?
• The Current BALUN
• The Voltage BALUN
• Why How to use a BALUN?
• Selecting a BALUN

3
TYPICAL ANTENNA PROBLEMS

• Radio Interference to nearby devices.
• Transmission line radiation.
• The above are due to common mode currents on
  the transmission line.
• Loss of power to antenna due to mismatch between
  coax and antenna.
• BALUNS can address these problems.

4
BALUN A Coined Word

• Balun formed from BALance UNbalance.
• Name suggest device converts between Balance ltgt
  Unbalance.
• BALUN is name of device that can be many things
  like a common mode choke, unbalance to balance
  transformer, and a step up or down transformer.

5
A Typical BALUN
6
Common Mode Currents

• How are common mode currents generated?
• Why are common mode currents undesirable?

7
Generation of CM CurrentFrom an Antenna
8
Problems Caused By CM Current

• Pattern Distortion caused by radiation from
  transmission line due to common mode current on
  transmission line.
• RFI to nearby devices like TV sets and
  telephones.
• RF in the shack or transmitter location that can
  cause RF current to flow through the operator!

9
Types of BALUNS

• There are two general types of baluns.
• Current or choke type Baluns.
• gt Eliminates common mode currents.
• Voltage type Baluns.
• gt Provides for impedance matching of
  transmission line to antenna. An example is the
  TV antenna 300 ohm to 75 ohm matching
  transformer.

10
CURRENT BALUNS

• Current baluns are typically 11 -- Zout Zin
  but can have other ratios.
• Primary use is for reduction of common mode
  currents.
• Can be use for unbalanced to balanced loads like
  dipole antennas and beams.
• Typical construction is ferrite beads over
  coaxial cable or wires on ferrite core.

11
Balanced Load No Balun
Let Zcc be 0 ohms which shunts R1. Then E1 0
volts and E2 EG. No balanced voltage to load
R1R2.
12
Balanced Load Balun
Let Zcc be Hi-Z due to ferrite beads on cable and
R1 R2. Then R1 is not shunted by Zcc. Now E1
E2 balanced voltage across load due to
balanced load not balun.
13
Common Mode No Balun
Let Zcc be 0 ohms which is in series with
Zcm. Then Icm Eg/x / Zcm
14
Common Mode Balun
Let Zcc be Hi-Z due to ferrite beads on cable
which is in series with Zcm. The Icm Eg/x /
Zcm Zcc. Note if Zcm where infinite, then Icm
0 Amps
15
VOLTAGE BALUNS

• Voltage baluns have varied input to output ratios
  and have true balanced or unbalanced outputs as
  determined by the design.
• Primary use is for impedance matching of
  typically a transmission line to an antenna.
• Typical construction is the use of coaxial cable
  or wires on a ferrite core.

16
11 Voltage Balun
Example of a 11 unbalanced to balanced voltage
balun. Balanced output is due to transformer and
not the load. There is essentially no common mode
current rejection.
17
41 Voltage Baluns
Examples of 41 voltage baluns that can be
connected for either balanced or unbalanced
output.
18
WHY USE A BALUN?

• Baluns are used for two primary reasons.
• One Eliminate common mode current on the
  transmission line!
• Two Matching antenna impedance to the
  transmission line.

19
Matching Antenna

• Impedance matching antenna to transmission line
  improves power transfer and lowers SWR.
• Note! A high SWR on a transmission line does NOT
  cause the transmission line to radiate!

20
Balun Installation
21
Selecting A Balun

• ALWAYS use a current balun to eliminate common
  mode current and if matching is needed, current
  baluns can also have a ratio (41 or 91) as
  required to match antenna.
• Use a voltage balun only for impedance matching
  of antenna to transmission line.
• Becoming knowledgeable on how and why baluns
  work, will insure success.

22
Purchasing A Balun

• The description of a balun, may or may not,
  include that it is current or voltage balun.
• A 11 current balun is sometimes described as a
  choke balun.
• An example is the catalog description of the W2AU
  ferrite balun usually does not indicate that it
  is a voltage balun.

23
Make A Balun
A current balun can be made by winding several
turns of coax to form a inductor.
Another choice to make a current balun is to
place a number of ferrite beads over coax.
Need More Ideas GOOGLE for one that meets your
needs.
24
REFERENCES

• Baluns What They Do And How They Do It By Roy W.
  Lewallen, W7EL. Article in The ARRL Antenna
  Compendium Vol 1.
• Understanding, Building, and Using Baluns and
  Ununs By Jerry Sevick, W2FMI. A book published by
  CQ Communications.

25
END OF PRESENTATION
QUESTIONS?
THANK YOU!
