Ethernet Access Services Definition and Implementation

1

• Ethernet Access Services Definition and
  Implementation

2
Co-presented by
Arie Goldberg Omnitron CEO and Founder MEF Board
Member agoldberg_at_omnitron-systems.com
Ralph Santitoro Director of Carrier Ethernet
Solutions RSantitoro_at_TurinNetworks.com
3
Ethernet Service Delivery over Different Access
Network Technologies
10/100BaseT
10/100BaseT
Ethernet over Fiber (EoF)
EoDSL
Ethernet Service Provider
Ethernet over SDH (EoS)
10/100BaseT
Ethernet over PON/WDM
Ethernet over HFC
Ethernet over PDH (EoPDH)
10/100BaseT
Coax
10/100BaseT
Ethernet can be delivered over many different
types of access network technologies
4
Fundamental Ethernet Service Components
Access/Aggregation Network
Access/Aggregation Network
E-NNI
Metro Transport / Core Network

• UNI (User-to-Network Interface)
• Physical interface/demarcation between service
  provider and subscriber
• Service start/end point
• NNI (Network-to-Network Interface)
• Demarcation/peering point
• between service providers (E-NNI)
• between service provider internal networks
  (I-NNI)
• Ethernet Virtual Connection (EVC)
• Logical representation of an Ethernet service as
  defined by the associate between 2 or more UNIs

These Ethernet Service components are independent
of the Access or Transport Network Technology to
delivery the service
5
Example of Ethernet Service Delivery over
Different Access/Transport Technologies
Ethernet Service Provider
I-NNI
PDH (E1/T1) Access Network Provider
E-NNI
MPLS Transport Network
Fiber Access Network
10Mbps EVC

• PDH Access Network
• EoPDH N bonded E1s

• MPLS Transport Network
• Ethernet over MPLS

• Fiber Access Network
• Ethernet over Fiber (EoF)

• PDH Access/Aggregation Network
• UNI1 PDH access network bonds 5 E1s for 10Mbps
  EoPDH
• E-NNI 1Gbps Ethernet over Fiber (802.1ad /
  QinQ)
• MPLS Transport Network
• 802.1ad frames mapped to MPLS transport network
• I-NNI 1Gbps Ethernet over Fiber (802.1ad /
  QinQ)
• Fiber Access Network
• UNI2 10Mbps Ethernet over Fiber (EoF)

Subscriber is unaware of the various transport
network technologies used to deliver this 10Mbps
Ethernet Service
6
Ethernet Services and Ethernet Access to IP
Services

• Ethernet Services are Connectivity Services
• Multi-site E-LAN
• Ethernet Private LAN
• Transparent LAN Service
• VPLS
• Site-to-Site E-Line
• Ethernet Private Line
• Ethernet Virtual Private Line
• Ethernet Access to IP Services
• Provide Layer 2 connectivity to IP Service
  Networks
• Ethernet access to Internet
• Ethernet access to Managed VoIP service

E-LAN
E-Line
Internet
E-Line
VoIP
Ethernet Service Layer 2 Service
End-to-End Ethernet Access to IP Service Layer
2 access to IP Service
7
Comparison of Ethernet L2 VPN and IP VPN Services
in Access Network

• Ethernet L2 VPN Service
• UNI
• EVC (service) identified via VLAN ID
• CoS identified via PCP
• Forwarding on MAC or VLAN ID

• IP VPN Service
• Port
• Service identified via IP address
• CoS identified via DSCP
• Forwarding on IP Address

Service Provider
Fundamental difference between Ethernet and IP
Services in the access network is the information
used to identify, forward and process service
frames
8

• Ethernet Access Service Attributes

Ethernet Service Performance Metrics, Bandwidth
Profiles, CoS, Service Performance, and Fault
Management
9
Ethernet Service Performance Management

• Key Metrics
• Frame/Packet Delay (Latency)
• Frame/Packet Delay Variation (Jitter)
• Frame/Packet Loss Ratio
• Service Availability
• Frame/Packet Goodput
• ITU-T has defined measurement framework/metrics
  for items 1-3
• IP packet-based measurements
• ITU-T Y.1731 defines how to use 802.1ag to
  measure service performance
• MEF has defined measurement framework for items
  1-4
• Ethernet Frame-based measurements
• MEF 10.1 defines formulae for
• Frame Delay (FD), FD Variation, Frame Loss Ratio,
  Service Availability

The combination of IEEE 802.1ag, ITU-T Y.1731 and
MEF 10.1 define Ethernet service performance
10
Ethernet Service Performance Metrics

• Frame Delay (FD) and Frame Delay Variation (FDV)
• Measured between UNI pairs via transmission and
  reception of a percentile of service OAM frames
  over a measurement period
• Example
• FD 30ms (99th percentile over 15 minute
  interval)
• FDV 10ms (99the percentile over 15 minute
  interval)
• FD and FDV measurements can be One Way or Round
  Trip
• Frame Loss Ratio (FLR)
• Percentage of Green (in-profile for CIR) Ingress
  frames received at Egress UNI over a measurement
  period
• Example FLR 2 ( over 15 minute interval)
• Service Availability
• Percentile Amount of time, FLR meets its service
  level objectives over a measurement period
• Example Availability 99.9 (over 1 month
  interval)

11
Bandwidth Profiles (BWP) and CoS

• Bandwidth Profiles per EVC (service) and per CoS
• CIR (Committed Information Rate)
• CIR assured via Bandwidth Reservation and Traffic
  Engineering
• EIR (Excess Information Rate)
• EIR bandwidth is considered excess
• Traffic dropped at congestion points in the
  network
• CBS/EBS (Committed/Excess Burst Size)
• Higher burst size results in improved performance

EVC-2
EVC-1
EIR
EIR
CIR
CIR
EVC-3
CIR
EIR
CoS 6
1Mbps CIR for VoIP

• BWPs can divide bandwidth per EVC (service) over
  a single UNI
• Multiple services over same port (UNI)
• CoS markings enable the network to determine the
  network QoS to provide

EVC1
CoS 2
6Mbps CIR for VPN data traffic
10Mbps UNI (port)
UNI
EVC2
3Mbps for Internet Access
CIR defines the assured bandwidth EIR improves
the networks Goodput
12
Ethernet Service Connectivity Fault Management

• IEEE 802.1ag for EVC Connectivity Fault
  Management
• For Protection/Restoration
• Connectivity Check Messages (CCMs) for heartbeats
• For diagnostic purposes
• Connectivity Check (Layer 2 Ping), Link Trace,
  Loopbacks
• CCMs initiated between
• Management Endpoints (MEPs / UNIs)
• Management Intermediate Points (MIPs / NNIs)
• Management Endpoints and Intermediate Points
  (UNI-NNI)

Connectivity Fault Management provided by Carrier
Ethernet network elements and NIDs
13
Ethernet Link Fault Management

• IEEE 802.3ah for Link Fault Management for (first
  mile) Ethernet access connection
• Link Fault Detection and Remote Loopbacks
• Layer 1 fault management used for transport
  connections used to deliver Ethernet services
• Ethernet over PDH
• Ethernet over SDH
• Ethernet over DSL
• Ethernet over HFC Coax

Ethernet Link Fault Management performed by
Carrier Ethernet network elements and NIDs
14
Ethernet Service Continuity Check
UNI
IP/MPLS Core Network
UNI
Metro Aggregation Network
Metro Aggregation Network
Access Network
Access Network
MEP 2
MEP1
MIP
MIP
MIP
MIP
Maintenance Association (MA)
MIP
MIP
MEP 2 Report on CC fault if no CCMs are received
from MEP 1 for 30ms
MEP 2 CCMs sent every 10ms Check for CCMs
received from MEP 1
Ethernet continuity check is analogous to IPs
Ping but does much more
15
Ethernet Link Trace
UNI
IP/MPLS Core Network
UNI
Metro Aggregation Network
Metro Aggregation Network
Access Network
Access Network
Link trace Reply
Ethernet Link Trace is analogous to IPs
Traceroute
16
Some Benefits of Ethernet L2 VPN versus IP VPN
17
Summary

• Ethernet Service are agnostic of the Access or
  Transport Network Technology
• Facilitates a common service portfolio for all
  markets
• Ethernet Service can be
• A Layer 2 Connectivity Service (E-Line or E-LAN
  L2 VPN)
• A Layer 1 Private Line Replacement (EPL)
• A Layer 2 access connection to an IP Service
• Ethernet Access to Internet
• Managed IP VPN or VoIP service

18
Presentation available for download at
http//MetroEthernetForum.org/Presentations
