EKG Interpretation

1
EKG Interpretation

• Just the beginning

2
King County

• Introduction
• Cardiac monitoring has been routinely used in the
  Fire Service for many years
• Not without some liability
• Intent of this course is to provide the basics in
  cardiac rhythm interpretation

3
Introduction cont.

• This course is not intended to teach diagnosis of
  heart disease
• Lead II is not sufficient for EKG diagnosis
• Recognition of the cardiac cycle will aid in the
  understanding of EKGs
• In order to remain proficient it is necessary to
  commit time to ongoing training in EKG
  interpretation

4
Objectives

• Understand basic cardiac terminology
• Describe the anatomy of the heart
• Identify the electrical conduction system
• Identify abnormal electrical cardiac activity

5
Objectives

• Identify common cardiac rhythms
• Identify and effect appropriate therapy for the
  patient on a monitor

6
Course Completion

• Participants are expected to pass a written exam
  and achieve a 70 score
• Practical exam will include correct
  interpretation of static rhythms, 70 passing
  score

7
Primary Obligation

• It cannot be overemphasized that the primary
  obligation for non-cardiac arrest patients is
  ABCs
• Attention to the patients symptoms
• Vital Signs, physical exam
• Any necessary treatment with application of the
  monitor only when basic life support has been
  completed

8
Anatomy Physiology

• Heart is a muscle
• Divided into four chambers
• Receives blood from the body via the inferior and
  superior vena cavae
• Chambers separated by valves
• Coronary arteries supply blood to the myocardium

9
Electrical Conduction System

• Specialized system of interconnected cells spread
  throughout the entire heart
• Provides and conducts the signal to the heart
  muscle to contract in a coordinated fashion

10
Sinoatrial (SA) Node

• Collection of electrical tissue that is the
  normal point of origin of electrical activity
• Named because it is located in the sinus part of
  the atria
• Generates P waves

11
Atrioventricular (AV) Node

• A way station that receives the impulses from the
  atria
• Named because it is located between the atria and
  the ventricles
• Actually used to slow impulses from the atria to
  the ventricles

12
Bundle of His

• Receives impulses from the AV node and passes
  them through the left and right bundle branches
  in the ventricular septum

13
Purkinje Fibers

• Last receiving point of the electrical impulses
• Fibers located in the ventricular musculature
• Rapidly conducts impulses causing ventricular
  contraction

14
Automaticity

• Any portion of the conduction system or heart
  muscle may initiate an electrical impulse
• When the AV Node fails to generate an impulse,
  another cell/area of the heart will initiate
  electrical activity

15
Secondary Pacemakers

• Any portion of the heart may initiate an
  electrical impulse and becomes a secondary
  pacemaker
• Determining the location of a secondary pacemaker
  will become clearer as we proceed through this
  curriculum

16
Electrocardiographic paper
17
EKG paper

• Grid of standard dimensions
• Simply used as a measurement of time
• Each small box represents 0.04 seconds
• Larger bolded boxes are .20 seconds
• Important to remember these values as they aid in
  the identification of virtually all EKG strips

18
The Cardiac Cycle

• P wave- indicates atrial depolarization
• PR interval- the interval from the beginning of
  the P wave to the beginning of the QRS complex
• PR interval represents the time from atrial
  depolarization to the beginning of ventricular
  repolarization

19
Cardiac Cycle

• Normal PR interval should not exceed 0.2 seconds
  or one large bolded square on the EKG paper
• QRS complex- represents electrical depolarization
  of the ventricle
• Normal duration of the QRS complex is from
  0.08-0.10 seconds (2 to 3 small boxes on the EKG
  paper

20
Cardiac Cycle

• T wave- represents repolarization of the
  myocardium

21
Normal Sinus Rhythm

• Characteristics-
• P wave for each QRS
• PR interval normal, lt0.20 seconds
• QRS complex is normal, lt0.10 seconds
• Uniform in shape
• Rate is regular and is between 60-100

22
Normal Sinus Rhythm

• Most common rhythm seen in acute MI
• Does not indicate that the patient is stable or
  that there is an absence of heart disease
• Indicates that the origin of the impulse is from
  the SA Node
• Indicates normal function of the electrical system

23
Normal Sinus Rhythm
24
Normal Sinus Rhythm
25
Sinus Tachycardia

• Characteristics-
• P wave for each QRS
• PR interval is normal, lt 0.20 seconds
• QRS complex is narrow, lt 0.10 seconds
• Uniform in shape
• Rate is regular, gt 100/minute

26
Sinus Tachycardia

• Accelerated discharge of electrical impulses from
  the sinus node
• Treatment is attention to symptoms
• Underlying cause is the concern
• Causes include shock, stimulants, acute MI where
  decrease in cardiac output causes heart rate
  increase

27
Sinus Tachycardia
28
Sinus Tachycardia
29
Supraventricular Tachycardia

• P waves may not be seen due to accelerated rate
• QRS complex is narrow, lt 0.10 seconds
• Uniform in shape
• Rate is regular, gt 150/ minute
• Patients heart rate is too fast

30
Supraventricular Tachycardia
31
Supraventricular Tachycardia
32
Sinus Bradycardia

• Characteristics-
• P wave for each QRS
• PR interval is normal, lt 0.20 seconds
• QRS complex is normal, lt 0.10 seconds
• Uniform in shape
• Rate is regular, lt 60/ minute

33
Sinus Bradycardia

• Transmission of impulses from the SA node is
  slowed to lt 60/ minute
• Heart rates less than 50/ minute should never be
  considered to be normal
• Beta blockers, digoxin, hypoxia, being athletic
  or with history of a slow heart rate can be the
  cause
• Patients heart rate is too slow

34
Sinus Bradycardia
35
Sinus Bradycardia
36
Premature Ventricular Contractions

• Characteristics-
• Early occurring beats that have a characteristic
  compensatory pause
• Premature QRS complex that is wide and bizarre,
  conduction time gt 0.10 seconds
• Same shape except when from different focus in
  the heart

37
Premature Ventricular Contractions

• Can occur in a healthy individual
• Viewed with caution in the patient who presents
  with cardiac symptoms
• Significant if occur in 2s (couplets), 3s
  (triplets),run of 4 is Ventricular Tachycardia
• Frequent occurring with syncope be cautious

38
Premature Ventricular Contractions
39
Ventricular Tachycardia

• Characteristics-
• P waves are usually present but are obscured by
  wide, rapidly occurring QRS complex
• QRS complex is wide gt 0.10 and bizarre
• Uniform in shape typically
• Rate is regular and gt 150/ minute

40
Ventricular Tachycardia

• Life threatening arrythmia
• Rapid rate decreases cardiac output
• Place patient supine, anticipating shock
• Cause can be electrical and not always acute MI
• If patient unconscious and pulseless is a a
  shockable rhythm

41
Ventricular Tachycardia
42
Ventricular Tachycardia
43
Idioventricular Rhythm

• Characteristics-
• P waves typically obscured or follow the QRS
  complex
• QRS complex is wide, gt 0.10 seconds
• Sometimes uniform in shape
• Rate is irregular, most often seen with rate lt
  40/minute

44
Idioventricular Rhythm

• Observed after defibrillation can be endpoint
  in arrest resuscitation attempt
• Conduction system above the ventricles fails to
  generate an electricle impulse
• Inherent rate of 30-40/minute
• Will likely be in cardiac arrest
• If unconscious and B/P lt60, initiate CPR

45
Idioventricular Rhythm
46
Ventricular Fibrillation

• Characteristics-
• P waves are absent
• QRS complex absent
• Baseline wavy, chaotic and inconsistent
• Rhythm irregular
• Rate is not countable

47
Ventricular Fibrillation

• Sudden death cardiac arrest immediately follow
  the onset
• Immediately defibrillate with 200 joules and
  proceed with standing orders
• Remember that we now do CPR for 2 minutes between
  shocks

48
Asystole

• Characteristics-
• P waves are not present
• QRS complex is not present
• Absence of any complexes indicate complete
  cessation of electrical activity
• The heart is motionless

49
Asystole
50
Pacemakers

• Characteristics-
• P waves sometimes are visible but are not
  associated
• QRS complex of times is wide, gt 0.10 seconds
• Preceded by a small spike with either a negative
  or positive deflection

51
Pacemakers

• Presence of a pacemaker indicates that there is
  an underlying rhythm disturbance, usually heart
  block
• Technology makes it harder to see when they are
  present
• Failure can occur, look for pacer spikes without
  complex initiated

52
Pacemakers

• Look for the presence of Ventricular Fibrillation
  in the patient who is in cardiac arrest
• Spikes will appear even in the presence of
  fibrillatory waves

53
Paced Rhythm
54
Paced Rhythm (AV Sequential)
55
Atrial Pacemaker
56
Pacemaker Failure
57
Sinus Arrhythmia

• Characteristics-
• P waves for each QRS
• PR interval is lt 0.20 seconds
• QRS complex is narrow, lt 0.10 seconds
• Rate varies, will speed up during inhalation and
  slow down on expiration

58
Sinus Arrythmia

• This rhythm is commonly found in healthy children
  or athletic adults
• Treat specific complaint or injury

59
Sinus Arrythmia
60
Atrial Flutter

• Characteristics-
• P waves are referred to as flutter waves and are
  uniform in shape, resembling a sawtooth pattern,
  mirror effect
• QRS complex is narrow, lt 0.10 seconds
• Rate is both regular and irregular
• Can be rapid, often seen at 150/minute

61
Atrial Flutter

• This rhythm is rarely seen in patients with
  healthy hearts
• Can be seen in patients with heart disease, acute
  MI, lung disease and pulmonary embolism
• Likes to go fast, needs ALS eval and is never
  normal for patients

62
Atrial Flutter
63
Atrial Fibrillation

• Characteristics-
• P waves are not clearly visible or uniform for
  each QRS complex
• QRS complex is typically narrow, but can be wide
• Is irregular-irregular, depending on ventricular
  response can be rapid

64
Atrial Fibrillation

• Cells within the atria fire chaotically
• Will be observed to have a rapid ventricular
  response with new onset
• Digoxin, beta blockers, calcium channel blockers
  can be used to control rate
• Also coumadin prescribed to reduce the incidence
  of clots in the heart chambers

65
Atrial Fibrillation
66
Atrial Fibrillation
67
Atrial Fibrillation
68
Atrial Fibrillation
69
Nodal Rhythm

• Characteristics-
• P waves are absent
• QRS complex is narrow, lt 0.10 seconds
• Uniform in shape
• Rate is regular, typically gt 40/minute but may be
  in excess of 100/minute

70
Nodal Rhythm

• Nodal rhythm occurs when the SA node fails to
  function
• Expect to see narrow QRS complex, lt0.10 seconds
• Can be caused by Digitalis Toxicity, acute MI,
  hypoxia, diseased sinus node
• In some patients this may be their normal rhythm

71
Nodal Rhythm
72
Nodal Rhythm
73
Accelerated Nodal Rhythm
74
First Degree Heart Block

• Characteristics-
• P wave for each QRS
• PR interval is gt0.20 seconds
• Rate is regular
• QRS complex is narrow, lt 0.10 seconds
• Uniform in shape

75
First Degree Heart Block

• Occurs when there is delayed conduction of an
  impulse through the AV node
• Patients presentation dictates need for
  intervention
• Some patients may have first degree heart block
  as their primary rhythm

76
First Degree Block
77
First Degree Heart Block
78
First Degree Heart Block
79
First Degree Heart Block
80
Second Degree Heart BlockWenckebach, Mobitz Type
1

• Characteristics-
• P waves are present
• P wave occurs at a regular rate
• QRS complex is uniform in shape and narrow, lt0.10
  seconds
• PR interval progressively lengthens until QRS
  complex is dropped

81
Wenckebach, Mobitz Type 1

• Sinus impulse is progressively delayed through
  the AV node until no conduction occurs
• Causes include ischemic heart disease, acute MI,
  digitalis toxicity
• Patients presentation determines intervention,
  if ventricular rate is slow the patient may not
  have symptoms

82
Wenckebach, Mobitz Type 1
83
Wenckebach, Mobitz Type 1
84
Wenckbach, Mobitz Type 1
85
Second Degree Heart Block Mobitz Type II

• Characteristics-
• P waves are present
• P waves occur at a regular rate
• PR interval is fixed , may be prolonged
• On occasion there will be more than one P wave
  for each QRS complex

86
Mobitz Type II

• QRS complex may be narrow, lt 0.10 or may be wide,
  gt 0.10
• Series of non conducted P waves may be seen
  (atrial depolarization only)
• Ratio at which the QRS complex is conducted
  varies and is noted as a ratio, 21, 31, etc.
  (Ps for each QRS complex)

87
Mobitz Type II

• Most often seen in the setting of acute MI
• Frequently have syncope associated due to the
  slow rate
• Commonly progresses to complete heart block
• ALS evaluation paramount, since patient will
  often times be in shock

88
Mobitz Type II
89
Mobitz Type II
90
Mobitz Type II
91
Third or Complete Heart Block

• Characteristics-
• P waves occur at a regular interval, typically at
  a rate of 60-100 beats/min.
• P waves do not have a fixed, or constant
  relationship to the QRS complex
• PR interval abnormally prolonged, gt 0.20 and
  changing

92
Complete Heart Block

• QRS complex may be narrow, lt 0.10 or wide, gt 0.10
  depending on where in the heart the impulse
  originates
• QRS rate is usually constant, typically between
  20-40 beats/min.
• Indicates that there is no transmission of
  impulses between the atria and the ventricles

93
Complete Heart Block

• Often occurs in the setting of acute MI
• Can occur with Digitalis toxicity, elderly with
  conduction system problems
• May present with syncope
• This type of heart block may be transient
• ALS evaluation paramount, since patient will
  often times be in shock

94
Complete Heart Block
95
Complete Heart Block
96
Complete Heart Block
97
P.E.A.Pulseless Electrical Activity

• Characteristics-
• P waves may be present
• PR interval may be normal, lt 0.20 sec.
• QRS complex may be narrow, lt 0.10 or wide, gt 0.10
• Rate can be regular or irregular
• Can be normal rhythm

98
P.E.A

• Pulseless Electrical Activity is indicated by the
  absence of a detectable pulse and the presence of
  some type of electrical activity
• Seen during cardiac arrest secondary to acute MI,
  pulmonary embolus, cardiac tamponade, tension
  pneumothorax or a hypovolemic state

99
P.E.A. (sinus tachycardia)
100
Treatment Protocols

• Do not attempt to treat any patient from what is
  seen on the monitor alone, unless V. Tach with
  unconsciousness or V. Fib.
• Patient presentation will direct intervention
• Request ALS evaluation when possible lethal
  arrythmias are identified

101
Ongoing Education

• It is recommended that EMTs receive regular
  ongoing education to remain proficient at EKG
  recognition
• Quarterly review/refresher by a paramedic or
  equivalent
• Attach EKG strips to your MIRF forms for
  department reviewer for feedback and
  identification confirmation

102
EKG Interpretation

• Questions?
• The end or just the beginning?
