The NAZO Solution

1
The NAZO Solution
Alex Nicoll
Senior Technology Research Fellow
College of Information Science and Technology
University of Nebraska at Omaha
2
Development Guidelines

• No complex languages
• No scripting
• User Friendly
• Flexible
• Secure
• Multi-platform
• Above all FAST

3
Components

• Security
• Web Interface
• Database
• Scheduler
• Job Execution Engine
• Inter-Cluster resource sharing

4
Architechture

• Master Node
• Scheduling Engine
• Web Server
• Small user base
• SSL key based communication
• Packet Filtering Bridge
• Nodes
• Job Execution Engine

5
Packet Filtering Bridge?

• IPSec Enabled
• Transparent
• Fast Response
• Removes Crypto Burden

To Internet
Packet Filtering Bridge
Client Node
Client Node
Master Node
Client Node
Client Node
6
Flow of Job Submission
Log In
Refresh
Select Application
Submit Job
View Submission Status
Log Out
7
Flow of Job Execution
SQL Application Table Updated
Job Submitted
Master SQL Table Updated
Job Placed In Queue
Job Executed
Input/ Output Files Deleted
Inputs Validated
Master SQL Table Updated
SQL Application Table Updated
Input Files Created
8
Job Deletion
Retrieve Job Status From Master Table
Delete Record From Application Table
Delete Record From Master Table
Done
Pending
Delete Job From Queue
9
Master Job Table

• Job ID (created when job is submitted)
• Job Type (application)
• User ID
• Queue ID (created when job is queued)
• Job Name (user specified)
• Time Queued
• Time Started
• Time Ended
• Job Status

10
Application Table

• Queue ID
• Job ID
• Inputs (files as globs)
• Outputs (files as globs)

11
Other Features

• User Initiated Database Updates
• Application Parameter Storage/Re-Use

12
Future Plans

• Applications as web templates
• More applications
• Partner cluster reservations for nodes
• Suggestions?
